Description
The StarTech.com N6PAT25CMBKS patch cable is designed for high-speed data transmission, supporting up to 10 Gbps. With its slim design and pure bare copper conductors, this cable minimizes interference, ensuring reliable connectivity. This cable features flame-retardant material and is halogen-free, making it a safe choice for various environments. The low smoke zero halogen (LSZH) jacket material provides extra protection and complies with several standards, including RoHS and WEEE.
Constructed with a strain relief feature, this cable reduces stress on the connectors, which helps maintain signal integrity over time. The RJ-45 connectors are plated with gold to enhance durability and improve performance. With 100 W PoE++ support, this patch cable is suitable for modern networking applications, providing both power and data transmission efficiently.
- Supports data rates of up to 10 Gbps
- Features slim design with low smoke zero halogen jacket
- Includes flame-retardant properties for safety
- Compliant with IEEE 802.3bt standards
- Strain relief design minimizes wear on connectors
- High-speed performance
This patch cable supports data rates of up to 10 Gbps, ensuring rapid data transfer and reliable connectivity for various applications. - Environmentally friendly
Made with a low smoke zero halogen jacket, this cable meets stringent environmental standards, reducing harmful emissions during use. - Robust design
The use of pure bare copper conductors and gold-plated RJ-45 connectors enhances durability and ensures a stable connection. - Protection features
Flame-retardant properties and a strain relief design provide additional security against electrical hazards and physical stress on the cable. - Compliance assured
This patch cable adheres to multiple standards, including RoHS and WEEE, ensuring it meets quality and safety requirements.
Main Specifications
Product Description | Startech patch cable – 25 cm – black |
Type | Patch cable – CAT 5/5e/6 – IEEE 802.3bt |
Technology | Unshielded twisted pair (UTP) |
Wiring Scheme | T568B |
Wires per Cable | 8 wires |
Features | Halogen-free, snagless, straight, Slim, flame retardant, strain relief, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), pure bare copper conductors, up to 10 Gbps, 100W PoE++ support |
Cable Length | 25 cm |
Diameter | 3.6 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Black |
Extended Specifications
General
Network Cable Type | Patch cable – CAT 5/5e/6 – IEEE 802.3bt |
|---|
Technology | Unshielded twisted pair (UTP) |
|---|
Wiring Scheme | T568B |
|---|
Jacket Material | Low Smoke Zero Halogen (LSZH) |
|---|
American Wire Gauge (AWG) | 28 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
Plated Connector | Gold |
|---|
Features | Halogen-free, snagless, straight, Slim, flame retardant, strain relief, minimised Near-End Crosstalk (NEXT), reduced Return Loss (RL), pure bare copper conductors, up to 10 Gbps, 100W PoE++ support |
|---|
Cable Length | 25 cm |
|---|
Diameter | 3.6 mm |
|---|
Colour | Black |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, WEEE, ANSI/TIA-568-C.2, TIA/EIA-568-B.1-2001 – up to 250 MHz |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 17 cm |
|---|
Shipping Depth | 12 cm |
|---|
Shipping Height | 1.5 cm |
|---|
Shipping Weight | 25.5 g |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
