Description
The Lenovo ThinkStation P3 Gen 2 is designed for professionals who require a powerful workstation. Equipped with a 24-core Intel Core Ultra 9 processor, this tower workstation delivers robust performance for demanding applications. Featuring 64 GB of DDR5 SDRAM with dual-channel memory architecture, the system ensures smooth multitasking and efficient data processing. The installed 1 TB NVMe SSD provides quick access to data, bolstered by TCG Opal encryption for enhanced security. With a diverse range of connectivity options, including USB-A, USB-C, HDMI, and DisplayPort, users can easily connect to peripherals and displays, making this workstation a versatile choice for any professional environment. The Lenovo ThinkStation P3 Gen 2 meets stringent compliance standards such as FIPS 140-2 and MIL-STD 810H, ensuring reliability and security for sensitive tasks. The integrated Realtek ALC623-CG audio codec delivers high definition audio output for an immersive experience. Additionally, the system features a Kensington security slot and padlock loop to safeguard against theft and unauthorized access. With a powerful 750-watt power supply certified by 80 PLUS Platinum, this workstation is built to handle demanding workloads efficiently.
- Powerful 24-core Intel Core Ultra 9 processor
- 64 GB of DDR5 SDRAM for efficient multitasking
- 1 TB NVMe SSD with TCG Opal encryption for secure data
- Wide range of connectivity options for enhanced versatility
- Robust compliance with security standards
- Robust Processing Power
Equipped with a 24-core Intel Core Ultra 9 processor, the Lenovo ThinkStation P3 Gen 2 delivers performance for intensive applications, allowing users to tackle complex tasks with ease. - High-Speed Memory
With 64 GB of DDR5 SDRAM operating at 5600 MT/s, the workstation is optimized for high-performance computing and seamless multitasking, ensuring that even the most demanding applications run smoothly. - Secure Storage Solution
The 1 TB NVMe SSD offers speedy data access and incorporates TCG Opal encryption, providing peace of mind for users handling sensitive information. - Comprehensive Connectivity
Featuring multiple ports including USB-C, HDMI, and DisplayPort, the Lenovo ThinkStation P3 Gen 2 allows users to connect a variety of peripherals and displays, enhancing its adaptability in a professional setting. - Rigorous Security Compliance
Designed to meet FIPS 140-2 and MIL-STD 810H standards, this workstation ensures reliability and security, making it suitable for environments where data integrity is paramount.
Main Specifications
Product Description | Lenovo ThinkStation P3 Gen 2 – tower – AI Workstation – Core Ultra 9 285K – vPro Enterprise – 64 GB – SSD 1 TB, HDD 2 TB – US English |
Type | Workstation – tower – AI Workstation |
Bundled Services | 3 Years Lenovo Premier Support |
EU Data Act | Https://www.lenovo.com/us/en/compliance/eu-data-act-transparency-declaration/ |
Platform Technology | Intel vPro Enterprise |
Processor | 1 x Intel Core Ultra 9 (Series 2) 285K (up to 5.7 GHz, (24-core) |
Processor Socket | FCLGA1851 Socket |
Neural Processor Unit (NPU) | Intel AI Boost – up to 13 TOPS |
Cache Memory | 36 MB |
Cache Per Processor | 36 MB |
RAM | 64 GB (installed) / 256 GB (max) – DDR5 SDRAM – non-ECC |
Storage Controller | NVMe; SATA |
Hard Drive | SSD 1 TB – PCI Express 5.0 x4 – M.2 2280 – TCG Opal Encryption, NVM Express (NVMe), Performance |
Hard Drive (2nd) | HDD 2 TB – SATA 6Gb/s – 7200 rpm |
Optical Storage | DVD-Writer |
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
Graphics Controller | NVIDIA RTX 4000 Ada / Intel Graphics – up to 8 TOPS |
Video Memory | 20 GB GDDR6 SDRAM |
Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Wi-Fi 6, Bluetooth, Wi-Fi 7 |
Keyboard | US English |
Power | (50/60 Hz) |
OS Provided | Windows 11 Pro |
Dimensions (WxDxH) | 18 cm x 37 cm x 41.5 cm |
Weight | 14.38 kg |
Manufacturer Selling Program | Lenovo TopSeller |
Environmental Standards | TCO Certified, generation 10, for desktops |
Documents
Extended Specifications
General
Platform Technology | Intel vPro Enterprise |
|---|
Type | Workstation |
|---|
AI Level | AI Workstation |
|---|
Bundled Services | 3 Years Lenovo Premier Support |
|---|
EU Data Act | Https://www.lenovo.com/us/en/compliance/eu-data-act-transparency-declaration/ |
|---|
Product Form Factor | Tower |
|---|
Embedded Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Processor / Chipset
CPU | Intel Core Ultra 9 (Series 2) 285K |
|---|
Max Turbo Speed | 5.7 GHz |
|---|
Number of Cores | 24-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Socket | FCLGA1851 Socket |
|---|
Chipset Type | Intel W880 |
|---|
Neural Processor Unit (NPU)
Neural Processor Unit (NPU) | Intel AI Boost |
|---|
NPU Performance Up To (TOPS) | 13 TOPS |
|---|
Total Processor Performance Up To (TOPS) | 36 TOPS |
|---|
AI Datatype Support on NPU | INT8 |
|---|
Sparsity Support | Yes |
|---|
AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
|---|
Windows Studio Effects Support | Yes |
|---|
Cache Memory
Installed Size | 36 MB |
|---|
Cache Per Processor | 36 MB |
|---|
RAM
Installed Size | 64 GB (installed) / 256 GB (max) |
|---|
Technology | DDR5 SDRAM – non-ECC |
|---|
Effective Memory Speed | 5600 MT/s |
|---|
Rated Memory Speed | 5600 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 4 (Total) / 2 (empty) |
|---|
Features | Dual channel memory architecture |
|---|
Configuration Features | 2 x 32 GB |
|---|
Hard Drive
Type | SSD – M.2 2280 |
|---|
Capacity | 1 x 1 TB |
|---|
Interface Type | PCI Express 5.0 x4 |
|---|
Features | TCG Opal Encryption, NVM Express (NVMe), Performance |
|---|
Hard Drive (2nd)
Type | HDD |
|---|
Interface Class | Serial ATA |
|---|
Capacity | 1 x 2 TB |
|---|
Interface Type | SATA 6Gb/s |
|---|
Spindle Speed | 7200 rpm |
|---|
Storage Controller
Storage Controller (2nd)
Optical Storage
Type | DVD±RW DVD-Writer – SATA |
|---|
Monitor
Graphics Controller
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
|---|
Graphics Processor | NVIDIA RTX 4000 Ada / Intel Graphics – up to 8 TOPS |
|---|
Video Memory | 20 GB GDDR6 SDRAM |
|---|
Audio Output
Compliant Standards | High Definition Audio |
|---|
Input Device
Keyboard
Keyboard Name | Lenovo Calliope Keyboard |
|---|
Interface | USB |
|---|
Localization & Layout | US English |
|---|
Mouse
Mouse Name | Lenovo Calliope Mouse |
|---|
Interface | USB |
|---|
Networking
Ethernet Controller | Intel I219-LM |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | Intel WI-FI 7 BE200 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) |
|---|
Features | Dual stream (2×2), Intel Active Management Technology (AMT) 16 |
|---|
Expansion / Connectivity
Interfaces | 1 x USB-C 3.2 Gen 2×2 (1 front) (data only)
3 x USB 3.2 Gen 1 (2 front, 1 rear)
2 x USB 3.2 Gen 2 (2 front)
1 x headphones/microphone (1 front)
1 x microphone (1 front)
2 x USB 2.0 (2 rear)
1 x HDMI (1 rear) (TMDS compatible)
2 x DisplayPort 1.4 (2 rear)
1 x LAN (Gigabit Ethernet) (1 rear)
1 x audio line-out (1 rear) |
|---|
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | FIPS 140-2, TCG Certified, MIL-STD 810H |
|---|
Manufacturer Selling Program | Lenovo TopSeller |
|---|
Power
Device Type | Power supply |
|---|
Voltage Required | AC 100-240 V (50/60 Hz) |
|---|
Power Provided | 1100 watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
OS Provided | Windows 11 Pro English |
|---|
Sustainability Information
TCO Certified | TCO Certified, generation 10, for desktops |
|---|
Dimensions & Weight
Width | 18 cm |
|---|
Depth | 37 cm |
|---|
Height | 41.5 cm |
|---|
Weight | 14.38 kg |
|---|
