Description
The Lenovo ThinkStation P3 Tiny Gen 2 offers a powerful and compact solution for personal computing needs. Designed with an ultra small form factor, this workstation provides exceptional performance without compromising on space. Equipped with a 14-core Intel Core Ultra 5 processor and 24 MB of cache memory, it is capable of handling demanding tasks efficiently. The use of DDR5 SDRAM technology enhances speed and responsiveness, making it suitable for both professional and casual users.
This model features an NVM Express SSD with PCI Express 4.0 x4 interface, ensuring fast data access and reliable performance. The Lenovo Calliope Keyboard and Mouse come included, providing a seamless user experience right out of the box. With multiple connectivity options such as HDMI, USB 3.2 Gen 2, and DisplayPort 1.4, users can easily connect to various devices and peripherals. In addition, security features including a chassis intrusion switch and tool-less chassis access ensure data protection and ease of maintenance.
- Compact design with ultra small form factor
- Equipped with a 14-core Intel Core Ultra 5 processor
- Fast NVM Express SSD for quick data access
- Includes Lenovo Calliope Keyboard and Mouse
- Multiple connectivity options for versatility
- Efficient processing power
The Lenovo ThinkStation P3 Tiny Gen 2 is powered by a 14-core Intel Core Ultra 5 processor, providing versatile performance for a range of applications. Its efficient architecture ensures tasks are processed smoothly, suitable for professionals across various fields. - High-speed storage
With an NVM Express SSD and PCI Express 4.0 x4 interface, this workstation delivers fast data transfer and access speeds. This allows users to quickly load applications and manage large files without delays, enhancing overall productivity. - Enhanced memory capability
Featuring DDR5 SDRAM technology, the system supports dual-channel memory architecture with a data transfer rate of 5600 MT/s. This ensures that the workstation can multitask easily, providing a smooth user experience. - Robust security features
The ThinkStation includes a chassis intrusion switch and tool-less chassis access, enhancing security while allowing for easy maintenance. Compliance with FIPS 140-2 and TCG standards provides assurance of data protection. - Comprehensive connectivity options
The multiple input and output interfaces, including HDMI, USB 3.2 Gen 2, and DisplayPort 1.4, allow seamless connections to various peripherals and displays. This flexibility supports various workflows and enhances productivity.
Main Specifications
Product Description | Lenovo ThinkStation P3 Tiny Gen 2 – tiny – AI Workstation – Core Ultra 5 225 – 16 GB – SSD 1 TB – US English |
Type | Personal computer – tiny – AI Workstation |
Processor | Intel Core Ultra 5 (Series 2) 225 (up to 4.9 GHz, (10-core) |
Processor Socket | FCLGA1851 Socket |
Neural Processor Unit (NPU) | Intel AI Boost – up to 13 TOPS |
Cache Memory | 20 MB |
Cache Per Processor | 20 MB |
RAM | 16 GB (installed) / 128 GB (max) – DDR5 SDRAM – non-ECC |
Storage Controller | NVMe |
Hard Drive | SSD 1 TB – PCI Express 5.0 x4 – M.2 2280 – TCG Opal Encryption, NVM Express (NVMe), Performance |
Optical Storage | No optical drive |
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
Graphics Controller | NVIDIA RTX A400 / Intel Graphics – up to 4 TOPS |
Video Memory | 4 GB GDDR6 SDRAM |
Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Wi-Fi 6, Bluetooth, Wi-Fi 7 |
Keyboard | US English |
Power | (50/60 Hz) |
OS Provided | Windows 11 Pro |
Colour | Black |
Dimensions (WxDxH) | 17.9 cm x 18.29 cm x 3.7 cm |
Weight | 1.4 kg |
Environmental Standards | TCO Certified, generation 10, for desktops EPEAT Gold |
Documents
Extended Specifications
Networking
Ethernet Controller | Intel I219-LM |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | Intel WI-FI 7 BE200 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) |
|---|
Features | Dual stream (2×2) |
|---|
Expansion / Connectivity
Interfaces | 1 x USB-C 3.2 Gen 2×2 (1 front) (data only)
1 x USB 3.2 Gen 2 (1 front) (Always On)
3 x USB 3.2 Gen 2 (1 front, 2 rear)
1 x headphones/microphone (1 front)
1 x USB 3.2 Gen 1 (1 rear)
1 x HDMI (1 rear) (TMDS compatible)
1 x DisplayPort 1.4 (1 rear)
1 x LAN (Gigabit Ethernet) (1 rear)
1 x USB 3.2 Gen 2 (1 rear) (supports SmartPower On) |
|---|
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion switch |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | FIPS 140-2, TCG Certified, MIL-STD 810H |
|---|
Power
Device Type | Power adapter |
|---|
Voltage Required | AC 100-240 V (50/60 Hz) |
|---|
Power Provided | 230 watt |
|---|
Efficiency | 89% |
|---|
Operating System / Software
OS Provided | Windows 11 Pro English |
|---|
Sustainability Information
TCO Certified | TCO Certified, generation 10, for desktops |
|---|
EPEAT Compliant | EPEAT Gold |
|---|
Dimensions & Weight
Width | 17.9 cm |
|---|
Depth | 18.29 cm |
|---|
Height | 3.7 cm |
|---|
Weight | 1.4 kg |
|---|
General
Type | Personal computer |
|---|
AI Level | AI Workstation |
|---|
Product Form Factor | Tiny |
|---|
Embedded Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Colour | Black |
|---|
Processor / Chipset
CPU | Intel Core Ultra 5 (Series 2) 225 |
|---|
Max Turbo Speed | 4.9 GHz |
|---|
Number of Cores | 10-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Socket | FCLGA1851 Socket |
|---|
Chipset Type | Intel Q870 |
|---|
Neural Processor Unit (NPU)
Neural Processor Unit (NPU) | Intel AI Boost |
|---|
NPU Performance Up To (TOPS) | 13 TOPS |
|---|
Total Processor Performance Up To (TOPS) | 23 TOPS |
|---|
AI Datatype Support on NPU | INT8 |
|---|
Sparsity Support | Yes |
|---|
AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
|---|
Windows Studio Effects Support | Yes |
|---|
Cache Memory
Installed Size | 20 MB |
|---|
Cache Per Processor | 20 MB |
|---|
RAM
Installed Size | 16 GB (installed) / 128 GB (max) |
|---|
Technology | DDR5 SDRAM – non-ECC |
|---|
Effective Memory Speed | 6400 MT/s |
|---|
Form Factor | SO-DIMM 262-pin |
|---|
Slots | 2 (Total) / 1 (empty) |
|---|
Features | Dual channel memory architecture |
|---|
Configuration Features | 1 x 16 GB |
|---|
Hard Drive
Type | SSD – M.2 2280 |
|---|
Capacity | 1 x 1 TB |
|---|
Interface Type | PCI Express 5.0 x4 |
|---|
Features | TCG Opal Encryption, NVM Express (NVMe), Performance |
|---|
Storage Controller
Optical Storage
Monitor
Graphics Controller
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
|---|
Graphics Processor | NVIDIA RTX A400 / Intel Graphics – up to 4 TOPS |
|---|
Video Memory | 4 GB GDDR6 SDRAM |
|---|
Audio Output
Compliant Standards | High Definition Audio |
|---|
Input Device
Keyboard
Keyboard Name | Lenovo Calliope Keyboard |
|---|
Interface | USB |
|---|
Localization & Layout | US English |
|---|
Mouse
Mouse Name | Lenovo Calliope Mouse |
|---|
Interface | USB |
|---|
