The Cooler Master Elite 690 Wood is a mid-tower chassis that combines style and functionality with a wooden front panel and meshed top and bottom for optimal airflow. Its 270-degree panoramic glass display offers an impressive view of internal components, further elevating its sleek design. The chassis accommodates a maximum video card length of 425 mm, allowing for the installation of powerful GPUs, while the CPU cooler can reach up to 170 mm in height, ensuring compatibility with various cooling solutions. With multiple internal bays for storage, including support for 2.5-inch and 3.5-inch drives, this case is designed for versatility. Front panel connectors, including USB 3.0 and USB-C 3.2 Gen 2×2, provide access to peripherals. Equipped with ARGB fans and customizable cooling options, the Cooler Master Elite 690 Wood offers support for radiators, making it a choice for builders who prioritize aesthetics without compromising on performance.
- Wooden front panel for a unique look
- 270-degree panoramic glass display for showcasing components
- Supports powerful GPUs with a max length of 425 mm
- Cooling support with room for multiple radiators
- Front panel connectors including USB-C
- Versatile cooling solutions
The case supports various cooling configurations with two ARGB PWM fans for intake and exhaust, alongside multiple radiator options, including 120/240/360 mm compatibility, ensuring efficient thermal management. - Ample storage capacity
With two internal bays for 2.5-inch and 3.5-inch drives, the chassis provides space for extensive storage needs, catering to both HDDs and SSDs. - Enhanced connectivity options
Featuring a range of front panel connectors, including dual USB 3.0 ports, a USB-C 3.2 Gen 2×2, and headphone/microphone inputs, the chassis prioritizes user convenience. - Robust construction materials
Built with a combination of wood, steel, and tempered glass, the Cooler Master Elite 690 Wood ensures durability while providing a visually appealing aesthetic. - Spacious interior design
The chassis supports ATX, microATX, and Mini-ITX motherboards, along with seven expansion slots, offering flexibility for various builds and upgrades.
Main Specifications
Product Description | Cooler Master Elite 690 Wood – mid tower – ATX |
Product Type | System cabinet |
Form Factor | Mid tower |
Windowed Side Panel | Yes, tempered glass |
Colour | White |
I/O Connectors | 2 x USB 3.0
1 x USB-C 3.2 Gen 2×2
1 x headphone/microphone |
Supported Motherboards | microATX, Mini-ITX, ATX |
System Cabinet Features | Front wooden panel, meshed top, meshed bottom, ARGB fans, 270-degree panoramic glass display |
Power Device | No power supply (ATX) |
Dimensions (WxDxH) | 21.8 cm x 43.4 cm x 45.4 cm |
Weight | 6.3 kg |
Extended Specifications
General
Power
Expansion / Connectivity
General
Internal Bays Qty | 2 |
|---|
Form Factor | Mid tower |
|---|
Dimensions & Weight
Dimensions & Weight (Shipping)
Dimensions & Weight
Height | 45.4 cm |
|---|
Width | 21.8 cm |
|---|
Dimensions & Weight (Shipping)
General
Windowed Side Panel | Yes |
|---|
Max Mainboard Size | ATX |
|---|
Power
Specification Compliance | ATX |
|---|
Dimensions & Weight (Shipping)
Dimensions & Weight
General
CPU Cooler Max Height | 170 mm |
|---|
Video Card Max Length | 425 mm |
|---|
Power Supply Max Length | 250 mm |
|---|
Dimensions & Weight (Shipping)
General
Windowed Side Panel Material | Tempered glass |
|---|
Power
Power Device | No power supply |
|---|
Expansion / Connectivity
Expansion Bays | 1 (total) / 1 (free) x internal – 3.5″
1 (total) / 1 (free) x internal – 2.5″ |
|---|
General
Supported Motherboards | microATX, Mini-ITX, ATX |
|---|
Cooling System | Rear: 120 mm fan x 1 / exhaust / ARGB PWM fan
Side: 120 mm fan x 2 / intake / ARGB PWM fan, supports 120/240 mm radiator, reverse blade
Bottom: 120 mm fan mount x 3 / 120/240/360 mm radiator supported
Top: 120 mm fan mount x 3 / 2 x 140 mm fan or 120/140/240/280/360 mm (max height 45 mm) radiator supported |
|---|
Product Material | Steel, tempered glass, wood |
|---|
System Cabinet Features | Front wooden panel, meshed top, meshed bottom, ARGB fans, 270-degree panoramic glass display |
|---|
Expansion / Connectivity
Interfaces | 2 x USB 3.0
1 x USB-C 3.2 Gen 2×2
1 x headphone/microphone – mini-jack |
|---|
