LG 86UH5Q-E, 86" Diagonal Class UH5Q Series LED-backlit LCD display, digital signage with Integrated Pro:Idiom, webOS, 4K UHD (2160p) 3840 x 2160, Edge LED, black
$5,465.91 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
Ships from: Auckland or Christchurch
- Allow 1–2 days for delivery
- Add 1–2 days if you are rural
- No collections
Description
The LG 86UH5Q-E is designed for commercial use, delivering performance with a 4K UHD resolution of 3840 x 2160. Its 86-inch LED-backlit LCD flat panel display ensures vibrant colors and clear pictures, perfect for digital signage. Equipped with a slim bezel design and multiple mounting options, this display fits seamlessly into various environments and settings.
With connectivity options including HDMI, DisplayPort, USB, and LAN, the display is easy to integrate into existing systems. The 20-watt audio system with built-in speakers enhances the overall viewing experience, while features such as Local Contents Scheduling and SuperSign CMS compatibility provide flexibility in content management. The device’s long lifespan, rated with a backlight life of up to 50,000 hours, ensures consistent performance for years to come.
- 4K UHD resolution for detailed viewing
- Designed for commercial environments with robust features
- Multiple connectivity options for versatile integration
- Energy-efficient with ENERGY STAR certification
- Long backlight life of 50,000 hours for extended use
- Display quality
The LG 86UH5Q-E features an LED-backlit LCD display with a resolution of 3840 x 2160, delivering visuals with precise color accuracy, ideal for digital signage applications. - Flexible connectivity options
Equipped with multiple inputs including three HDMI ports and one DisplayPort, the display can connect to various devices, enhancing versatility for different environments. - Commercial-grade reliability
This display is designed for continuous operation with an operating hour capacity of 24 hours, making it suitable for high-demand commercial settings. - User-friendly features
The device supports Local Key Operation and includes features like Local Contents Scheduling and SuperSign Control+, allowing for easy management of displayed content. - Energy-efficient performance
With ENERGY STAR certification and smart energy-saving features, the LG 86UH5Q-E minimizes power consumption while delivering performance.
Main Specifications
Product Description | LG 86UH5Q-E UH5Q Series – 86″ with Integrated Pro:Idiom LED-backlit LCD display – 4K – for digital signage |
Product Type | LED-backlit LCD flat panel display with Integrated Pro:Idiom |
EU Data Act | Https://www.lg.com/uk/privacy/ |
Diagonal Class | 86″ |
Commercial Use | Yes – digital signage |
Colour | Black |
Country Kits | Australia |
Platform | webOS |
Resolution | 3840 x 2160 |
Display Format | 4K UHD (2160p) |
Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
Video Interface | HDMI |
HDMI Ports Qty | 3 ports |
Connectivity | Wi-Fi, LAN, Bluetooth |
PC Interface | DisplayPort |
Technology | ADS |
LCD Backlight Technology | LED backlight – Edge LED |
Image Aspect Ratio | 16:9 |
TV Tuner | No tuner |
Commercial Features | Local Key Operation, Local Contents Scheduling, Group Manager, FailOver, booting logo image, No Signal image, Video Tag, play via URL, SNMP support, ISM Method, Auto Set ID, Control Manager, SI Server Setting, Real Time Communication (webRTC), SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign WB compatible, SuperSign Cloud, Mobile CMS, LG ConnectedCare, conformal coating, 30-degrees tilting installation |
Settings Cloning Capability | Yes |
Picture Enhancements | 95% BT.709 colour gamut |
Speaker System | 2 speakers |
Storage Capacity | 16 GB |
USB | 2 ports |
Included Accessories | Remote control, phone to RS232C gender, cable holder |
Voltage | AC 100-240 V (50/60 Hz) |
Power Consumption Operational | 205 watt |
Power Consumption Stand by | 0.5 watt |
Dimensions (WxDxH) – without stand | 192.88 cm x 2.97 cm x 109.98 cm |
Weight | 53 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Product Type | LED-backlit LCD flat panel display with Integrated Pro:Idiom |
|---|---|
EU Data Act | Https://www.lg.com/uk/privacy/ |
Power Consumption (Max) | 297 watt |
Power Consumption Operational | 205 watt |
Diagonal Class | 86″ |
Commercial Use | Yes – digital signage |
Series | UH5Q Series |
Model Year | 2025 |
Platform | webOS |
Operating System | webOS 8.0 |
TV Tuner | No tuner |
TV Tuner Presence | No |
Sensors | Temperature sensor, auto brightness sensor, acceleration sensor |
Video Interface | HDMI |
HDMI Ports Qty | 3 ports |
PC Interface | DisplayPort |
Modes | Portrait mode, landscape mode, Tiling Mode (15 x 15), PM mode |
Picture Enhancements | 95% BT.709 colour gamut |
Design | Slim Bezel Design |
Dimensions | Without stand |
Width | 192.88 cm |
Depth | 2.97 cm |
Height | 109.98 cm |
Weight | 53 kg |
Enclosure Colour | Black |
Country Kits | Australia |
Display
LCD Display Technology | ADS |
|---|---|
Colour Support | 1070000000 colours |
Resolution | 3840 x 2160 |
Display Format | 4K UHD (2160p) |
Image Aspect Ratio | 16:9 |
Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
LCD Backlight Technology | LED backlight – Edge LED |
Coating | 25% haze |
Image Contrast Ratio | 1200:1 |
Dynamic Contrast Ratio | 1000000:1 |
Brightness | 700 cd/m² |
Viewing Angle | 178 degrees |
Viewing Angle (Vertical) | 178 degrees |
Response Time | 8 ms |
Display Menu Language | Multilingual |
Backlight Life | 50,000 hour(s) |
Commercial Features | Local Key Operation, Local Contents Scheduling, Group Manager, FailOver, booting logo image, No Signal image, Video Tag, play via URL, SNMP support, ISM Method, Auto Set ID, Control Manager, SI Server Setting, Real Time Communication (webRTC), SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign WB compatible, SuperSign Cloud, Mobile CMS, LG ConnectedCare, conformal coating, 30-degrees tilting installation |
Settings Cloning Capability | Yes |
Operation Hours / Days | 24 / 7 |
Features | 10-bit support, picture in picture (no tuner), picture by picture (no tuner), Cisco Certified, Crestron Connected Compatible, Wake On LAN, BEACON technology |
Stands & Mounts
Flat Panel Mount Interface | 600 x 400 mm |
|---|---|
VESA Compatibility | Yes |
Media Player
USB Port | Yes |
|---|---|
USB Ports Qty | 2 |
Configuration | 16 GB |
Remote Control
Type | Remote control |
|---|---|
Battery Included | Yes |
Battery Included Qty | 2 |
Battery Required Qty | 2 |
Audio System
Speaker System | 2 speakers |
|---|---|
Output Power / Total | 20 watt |
Speakers | 2 x main channel speaker – 10 watt |
Network & Internet Multimedia
Connectivity | Wi-Fi, LAN, Bluetooth |
|---|---|
LAN Protocol | Ethernet |
Connect & Share | Screen Share |
Connections
Connector Type | 3 x HDMI input DisplayPort input RS-232C input LAN input 2 x USB 2.0 Infrared input Audio line-out RS-232C output |
|---|
Miscellaneous
Included Accessories | Phone to RS232C gender, cable holder |
|---|---|
Compliant Standards | Plug and Play, CEC, CB, NRTL, ERP, EMC, FCC Class B certified, KC, IP5X, HDCP 2.2, HDCP 1.4 |
Sustainability Information
ENERGY STAR Certified | Yes |
|---|
Power
Power Device | Power supply |
|---|---|
Input Voltage | AC 100-240 V (50/60 Hz) |
Power Consumption Stand by | 0.5 watt |
Power Consumption (Off Mode) | 0.5 watt |
Heat Generation Details | Cabinet – typical – 699 BTU/h Cabinet – max – 1013 BTU/h |
Features | Smart energy saving, WOL (Wake on LAN) |
Dimensions & Weight (Shipping)
Width (Shipping) | 210 cm |
|---|---|
Depth (Shipping) | 25.3 cm |
Height (Shipping) | 125 cm |
Weight (Shipping) | 66.7 kg |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 – 80% |
