TP-Link Omada EAP603-Outdoor V1, Radio access point, 1GbE, Wi-Fi 6, Bluetooth, 2.4 GHz, 5 GHz, cloud-managed, wall / pole mountable
$238.93 inc GST
1 in stock (can be backordered)
Ships from Auckland or Christchurch
- Allow 1-2 days for delivery
- add 1-2 days if you are rural
- No Collections
Description
The TP-Link Omada EAP603-Outdoor V1 is designed for outdoor environments, featuring a ruggedized design that allows for durability in extreme weather conditions. With an operating temperature range of -40°C to 70°C, this access point ensures reliable performance regardless of the climate. It supports both 2.4 GHz and 5 GHz Wi-Fi bands, providing versatile connectivity options to meet various networking needs. This outdoor access point utilizes wireless connectivity technology to deliver consistent and stable Internet access in outdoor settings. Its robust design and temperature resilience make it an ideal solution for businesses and organizations that require reliable network performance in challenging conditions.
- Ruggedized design for outdoor durability
- Operates in temperatures from -40°C to 70°C
- Supports dual-band Wi-Fi at 2.4 GHz and 5 GHz
- Wireless connectivity for versatile networking
- Ideal for demanding outdoor environments
- Rugged design
The EAP603-Outdoor V1 features a tough, ruggedized design that allows it to withstand harsh outdoor environments, making it suitable for various installations. - Extreme temperature tolerance
This access point operates effectively within a wide temperature range of -40°C to 70°C, ensuring stable performance in fluctuating weather conditions. - Dual-band connectivity
Offering both 2.4 GHz and 5 GHz Wi-Fi bands, this product provides flexibility and improved bandwidth. - Wireless technology
The use of wireless connectivity technology facilitates easy deployment and reduces the need for cumbersome wiring.
What’s in the Box
- TP-Link Omada EAP603-Outdoor V1
- Power cable
- Pole/wall mount kit, passive PoE adapter
Main Specifications
Product Description | TP-Link Omada EAP603-Outdoor V1 – radio access point – Wi-Fi 6, Bluetooth – cloud-managed |
Device Type | Radio access point |
Form Factor | Wall / pole mountable – outdoor, indoor |
RAM | 4096 MB |
Flash Memory | 1024 MB |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax (Wi-Fi 6), Bluetooth |
Frequency Band | 2.4 GHz, 5 GHz |
Performance | Maximum data rate (2.4 GHz): 573 Mbps Maximum data rate (5 GHz): 1201 Mbps Bandwidth: 20 / 40 / 80 MHz |
Capacity | Concurrent clients: 250+ Maximum number of configured SSIDs: 16 SSIDs per wireless band: 8 |
Included Accessories | Passive PoE adapter, pole/wall mount kit |
Power Over Ethernet (PoE) Supported | PoE+ |
Dimensions (WxDxH) | 23 cm x 20.75 cm x 6.97 cm |
Weight | 1.41 kg |
Extended Specifications
General
Device Type | Radio access point |
|---|---|
Ruggedized Design | Outdoor, indoor |
Width | 23 cm |
Depth | 20.75 cm |
Height | 6.97 cm |
Weight | 1.41 kg |
Processor / Memory / Storage
RAM | 4096 MB |
|---|---|
Flash Memory | 1024 MB |
Networking
Form Factor | Wall / pole mountable |
|---|---|
Connectivity Technology | Wireless |
Data Transfer Rate | 1.8 Gbps |
Line Coding Format | 1024 QAM, 256 QAM, 64 QAM, 16 QAM, OFDMA, OFDM, HE80, BPSK, QPSK |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax (Wi-Fi 6), Bluetooth |
Spread Spectrum Method | OFDM, OFDMA |
Network / Transport Protocol | IPv4, IPv6 |
Routing Protocol | Static IP routing |
Remote Management Protocol | SNMP 1, SNMP 2c, SNMP 3, SSH, NTP |
Cloud-Managed | Yes |
Frequency Band | 2.4 GHz, 5 GHz |
Max Range Open Space | 300 m |
Performance | Maximum data rate (2.4 GHz): 573 Mbps Maximum data rate (5 GHz): 1201 Mbps Bandwidth: 20 / 40 / 80 MHz |
Capacity | Concurrent clients: 250+ Maximum number of configured SSIDs: 16 SSIDs per wireless band: 8 |
Wi-Fi Rating | AX1800 |
Status Indicators | Status, error, firmware, power, uplink |
Features | Reset button, 6KV lightning protection, packet aggregation A-MPDU, packet aggregation A-MSDU, Target Wait Time (TWT), DFS support, Cyclic Delay Diversity (CDD), cyclic shift diversity (CSD), Low Density Parity Check (LDPC), Space Time Blocking Code (STBC), frame aggregation, MAC-based Access Control (MAC), Captive Portal, Guest Network, automatic channel selection, Airtime Fairness, band steering, rogue AP detection, URL filtering, Wireless Intrusion Detection System (WIDS), Wireless Intrusion Prevention System (WIPS), RSSI Threshold, LDAP server, external portal server support, Access Point management, Mesh networking, seamless roaming, 8×8 MU-MIMO technology, system log, backup/restore, email alert notification, firmware upgradable, LED control, NTP support, schedule reboot, WLAN scheduling, DHCP client, VLAN management, LLDP, mDNS, cloud managed, Maximum Ratio Combining (MRC), Transmit Beam-forming (TxBF) ready, WPA3 encryption |
Encryption Algorithm | WPA2-Personal, WPA3-Personal, WPA-Personal, WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise, OWE |
Authentication Method | RADIUS, PEAPv0, PEAPv1, EAP-TLS, EAP-TTLS, EAP-PEAP, CHAP, EAP-SIM, EAP-AKA, EAP-GTC, EAP-FAST, EAP-MD5, EAP-MSCHAPv2 |
Compliant Standards | IEEE 802.1x, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax, IEEE 802.3x, IEEE 802.1Q |
Aerial
Antenna | External detachable and internal |
|---|---|
Antenna Qty | 3 |
Directivity | Omni-directional |
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|---|
Communications Technology | Bluetooth 5.2 LE |
Expansion / Connectivity
Interfaces | 1 x 10/100/1000Base-T (PoE+) – RJ-45 |
|---|
Miscellaneous
Included Accessories | Passive PoE adapter, pole/wall mount kit |
|---|---|
Cables Included | 1 x power cable |
Compliant Standards | IP65, IEEE 802.11k, IEEE 802.11v, IEEE 802.11r, IEEE 802.11e, IEEE 802.11i, IEEE 802.1Q, ETSI EN 300 328, EN 62368-1, IEC 62368-1, EN/IEC 63000:2018, ROHS Directive 2011/65/EU, ROHS Directive 2015/863/EU, FCC |
Power
Power Over Ethernet (PoE) Supported | PoE+ |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 32.4 cm |
|---|---|
Shipping Depth | 10.4 cm |
Shipping Height | 24.5 cm |
Shipping Weight | 1.83 kg |
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|---|
Max Operating Temperature | 70 °C |
Humidity Range Operating | 10 – 90% (non-condensing) |
