Thermalright SG1000, Power supply (internal), ATX12V 3.1/ EPS12V, 80 PLUS Gold, AC 100-240 V, 1000 Watt
$219.66 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Thermalright SG1000 power supply offers performance with a power output of 1000 watts, ensuring reliable power delivery for high-performance PCs and servers. Equipped with a fully modular design, it allows for customizable cable management, reducing clutter and improving airflow within the case. It features a range of protection mechanisms, including overheat, overcurrent, and short-circuit protection, ensuring stable operation even under demanding conditions. With an 80 PLUS Gold certification, the SG1000 promotes energy efficiency, making it a choice for both gamers and professionals.
- Fully modular design for customizable cable management
- 1000 watts of reliable power output
- 80 PLUS Gold certification enhances energy efficiency
- Multiple protection features for safe operation
- Cooling system with a 120 mm fan for optimal airflow
- Power Output
Delivers consistent power with 1000 watts to support high-performance components and demanding applications. - Versatile Connectivity
Includes a variety of connectors such as 8-pin PCI Express, 24-pin ATX, and SATA power to accommodate different hardware setups. - Enhanced Protection Features
Incorporates multiple safety mechanisms including overheat, overcurrent, and short-circuit protection to safeguard internal components. - Efficient Cooling System
Equipped with a 120 mm fan that operates quietly while ensuring effective heat dissipation during heavy usage. - Modular Cable Design
The fully modular configuration allows users to attach only the cables needed for their setup, promoting better airflow and less cable clutter in the case.
Main Specifications
Product Description | Thermalright SG1000 – power supply – 1000 Watt |
Device Type | Power supply – internal |
Specification Compliance | ATX12V 3.1/ EPS12V |
80 PLUS Certification | 80 PLUS Gold |
Input Voltage | AC 100-240 V |
Output Voltage | +3.3, +5, ±12 V, +5Vsb V |
Power Capacity | 1000 Watt |
Output Current | +3.3V – 20 A +5V – 20 A +12V – 83 A -12V – 0.3 A +5VSB – 2.5 A |
Output connectors | 1 x power 24 pin ATX 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section 6 x 2 x 8 pin PCI Express power with detachable 2 pin section 4 x 15 pin Serial ATA power 7 x 4 PIN internal power 1 x 16 pin PCI Express power |
Modular Cable Management | Yes |
Cooling System | 120 mm fan |
Dimensions (WxDxH) | 15 cm x 14 cm x 8.6 cm |
Extended Specifications
General
Device Type | Power supply – internal |
|---|---|
Specification Compliance | ATX12V 3.1/ EPS12V |
PSU Form Factor | ATX |
Power Device
Input Voltage | AC 100-240 V |
|---|---|
Frequency Required | 47 – 63 Hz |
Power Output Connectors Details | 1 x power 24 pin ATX 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section 6 x 2 x 8 pin PCI Express power with detachable 2 pin section 4 x 15 pin Serial ATA power 7 x 4 PIN internal power 1 x 16 pin PCI Express power |
Output Voltage | +3.3, +5, ±12 V, +5Vsb V |
Power Capacity | 1000 Watt |
Output Current | +3.3V – 20 A +5V – 20 A +12V – 83 A -12V – 0.3 A +5VSB – 2.5 A |
Modular Cable Management | Yes |
80 PLUS Certification | 80 PLUS Gold |
Miscellaneous
Cables Included | AC power cable Power 24 pin ATX with detachable 4 pin section modular cable 60 cm 2 x power 8 pin +12V with detachable 4 pin section modular cable 65 cm 3 x 2x 8 pin PCI Express power with detachable 2 pin section modular cable 80 cm 16-pin 12VHPWR power modular cable 60 cm 3 x power 15 pin SATA cable / 4 pin internal power cable 90 cm 4 pin power modular cable 90 cm |
|---|---|
MTBF | 100,000 hours |
Cooling System | 120 mm fan |
Features | Fully modular, Smart Zero Fan, LLC resonant converter technology, DC-DC technology, over current protection, overheat protection, overpower protection, over voltage protection, short-circuit protection, undervoltage protection |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Dimensions & Weight
Width | 15 cm |
|---|---|
Depth | 14 cm |
Height | 8.6 cm |
