Lian Li SP850, V2, power supply (internal), SFX12V 3.42/ EPS12V 2.92, 80 PLUS Gold, AC 100-240 V, 850 watt, active PFC, Australia, black
$255.46 inc GST
✓ In Stock - 30 available
✓ Free NZ Delivery
30 in stock
- Allow 1–2 days for delivery
- Add 1–2 days if you are rural
- No collections
Description
The Lian Li SP850 power supply delivers performance and reliability for your PC or server. Certified with 80 PLUS Gold, it achieves up to 93.53% efficiency, significantly reducing power waste and operational costs. Its 92 mm fan, equipped with a hydraulic bearing, ensures cooling is both effective and quiet, especially with the Zero RPM fan mode that minimizes noise during low to medium loads.
Designed for versatility, the fully modular system with braided cords allows for a clean and organized build, making cable management easy. The SP850 is not just about power; it’s also about protection. With features like overcurrent, overheat, overpower, overvoltage, short-circuit, and undervoltage protection, your components are safeguarded against a wide array of electrical issues.
Whether you’re building a new PC or upgrading an existing one, the Lian Li SP850 offers the power, efficiency, and reliability you need to fuel your system.
- 80 PLUS Gold certified for high energy efficiency
- 92 mm hydraulic bearing cooling fan operates quietly
- Fully modular design simplifies cable management
- 850 Watt power output supports demanding systems
- Comprehensive protection features ensure system safety
- Efficient power supply
With an 80 PLUS Gold certification, this power supply ensures up to 93.53% efficiency, reducing electricity usage and operating costs. - Advanced cooling
Features a 92 mm fan with hydraulic bearing cooling and Zero RPM fan mode for quiet operation during low to medium loads. - Comprehensive protection
Equipped with overcurrent, overheat, overpower, overvoltage, short-circuit, and undervoltage protection to safeguard your components. - Flexible installation
Fully modular with braided cords for easy cable management and a clean build. The SFX form factor is perfect for PC/Server compatibility. - High compatibility
Supports a wide range of power output connectors including 24-pin ATX, 8 pin +12V, PCI Express power, and 15 pin Serial ATA power for broad device connectivity.
Main Specifications
Product Description | Lian Li SP850 – v2 – power supply – 850 watt |
Device Type | Power supply – active Power Factor Correction (PFC) – internal |
Specification Compliance | SFX12V 3.42/ EPS12V 2.92 |
80 PLUS Certification | 80 PLUS Gold |
Input Voltage | AC 100-240 V |
Output Voltage | +3.3, +5, ±12 V, +5Vsb V |
Power Capacity | 850 watt |
Output Current | +3.3V – 20 A +5V – 20 A +12V – 70 A -12V – 0.3 A +5VSB – 3 A |
Output connectors | 1 x power 24 pin ATX with detachable 4 pin section 1 x power 8 pin +12V with detachable 4 pin section 1 x power 8 pin +12V 2 x 8 pin PCI Express power with detachable 2 pin section 6 x 15 pin Serial ATA power 1 x 12VHPWR 1 x 12V 2×6 PCIE 5.0 1 x 4 PIN internal power |
Modular Cable Management | Yes |
Cooling System | 92 mm fan |
Included Accessories | Power cable, cable combs |
Colour | Black |
Dimensions (WxDxH) | 12.5 cm x 10 cm x 6.35 cm |
Extended Specifications
General
Device Type | Power supply – active Power Factor Correction (PFC) – internal |
|---|---|
Specification Compliance | SFX12V 3.42/ EPS12V 2.92 |
PSU Form Factor | SFX |
Colour | Black |
Power Device
Input Voltage | AC 100-240 V |
|---|---|
Frequency Required | 50 – 60 Hz |
Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section 1 x power 8 pin +12V with detachable 4 pin section 1 x power 8 pin +12V 2 x 8 pin PCI Express power with detachable 2 pin section 6 x 15 pin Serial ATA power 1 x 12VHPWR 1 x 12V 2×6 PCIE 5.0 1 x 4 PIN internal power |
Output Voltage | +3.3, +5, ±12 V, +5Vsb V |
Power Capacity | 850 watt |
Output Current | +3.3V – 20 A +5V – 20 A +12V – 70 A -12V – 0.3 A +5VSB – 3 A |
Power Factor (PF) | 0.9 |
Modular Cable Management | Yes |
80 PLUS Certification | 80 PLUS Gold |
Miscellaneous
Included Accessories | Power cable, cable combs |
|---|---|
Cooling System | 92 mm fan |
Features | SECC steel metal housing, fully modular, Zero RPM fan mode, fluid dynamic bearing cooling fan, over current protection, over voltage protection, overheat protection, overpower protection, short-circuit protection, undervoltage protection, no load operation protection, Surge & Inrush Protection (SIP) |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Sound Emission | 40 dBA |
Dimensions & Weight
Width | 12.5 cm |
|---|---|
Depth | 10 cm |
Height | 6.35 cm |
