Description
Re-engineered to get all the power of a full-size tower at a fraction of the size. The Z2 SFF AI workstation delivers high performance for intensive workflows-from 3D design to real time ray tracing-now and in the future. When demands change, you have the impressive ability to upgrade and expand.
- Small form. Big power. Impressive expandability. Design, simulate, and real-time ray trace on the Z2 SFF AI workstation, with low-profile NVIDIA RTXTM graphics and an Intel Core Ultra processor, including K-Series. Easily upgrade memory and storage as work evolves with tool-less access.
- Smaller design. Big impact. Whether placed horizontally or vertically, the Z2 SFF defies space constraints. Its smaller size allows for 4 units across a 7U rack. Stylish yet purposeful venting improves airflow to enable powerful K-series CPUs and NVIDIA low profile GPUs.
- Power AI-accelerated workflows. Accelerate AI workflows with the Z2 SFF AI workstation. Iterate and problem solve faster on your local device with a powerful discrete GPU delivering AI TOPS while a built-in NPU takes on productivity tasks.
- Help protect our shared future. At HP, we care about the impact our products have on our people, communities, and planet. That’s why this device is EPEAT Gold with Climate+ and the outer box packaging is 100% sustainably sourced.
- HP recommends Windows 11 Pro for business
Work anywhere without compromising on performance with Windows 11 and HP collaboration, security, and connectivity technology. Summarize and rewrite content, get relevant content recommendations, and stay organized with Microsoft Copilot. - Smaller, Functional Design
The stunning new design features front and rear ledges, so you can easily move your system from location to location. - Independent Software Vendor Certifications
Work with confidence knowing your PC is certified by leading software vendors to ensure peak performance even on complex projects.
Main Specifications
Product Description | HP Workstation Z2 G1i – SFF – AI PC, AI Workstation – Core Ultra 9 285 – 32 GB – SSD 1 TB |
Type | Workstation – SFF – AI PC, AI Workstation |
Processor | 1 x Intel Core Ultra 9 (Series 2) 285 (up to 5.6 GHz, (24-core) |
Processor Main Features | Intel Turbo Boost Technology, 24 Threads |
Neural Processor Unit (NPU) | Intel AI Boost – up to 13 TOPS |
Cache Memory | 36 MB L3 Cache |
Cache Per Processor | 36 MB |
RAM | 32 GB DDR5 SDRAM |
Hard Drive | SSD 1 TB – PCI Express 4.0 – M.2 – HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
Optical Storage | No optical drive |
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
Graphics Controller | NVIDIA RTX A1000 / Intel Graphics – up to 8 TOPS |
Video Memory | 8 GB GDDR6 SDRAM |
Networking | 1GbE |
OS Provided | Windows 11 Pro |
Software Included | HP Support Assistant, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Client Catalogue (free download), HP Image Assistant (free download), HP Documentation, HP Notifications, HP System Software Manager (free download), HP Sure Click, HP Sure Run, HP Sure Recover, HP Manageability Integration Kit, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, WPS Office, HP Client Security Manager Gen6, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customiser for Commercial, HP Desktop Support Utilities, HP PC Hardware Diagnostics Windows, HP Sure Start, HP Driver Packs (free download), HP UEFI BIOS Certification level 2.7B |
Colour | Black |
Dimensions (WxDxH) | 10 cm x 30.8 cm x 30.3 cm |
Weight | 4 kg |
Manufacturer Selling Program | HP Smart Buy |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Type | Workstation |
|---|
AI Level | AI PC, AI Workstation |
|---|
Product Form Factor | SFF |
|---|
Sensors | HP Tamper Lock |
|---|
Colour | Black |
|---|
Processor / Chipset
CPU | Intel Core Ultra 9 (Series 2) 285 |
|---|
Max Turbo Speed | 5.6 GHz |
|---|
Number of Cores | 24-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
Processor Main Features | Intel Turbo Boost Technology, 24 Threads |
|---|
Chipset Type | Intel W880 |
|---|
Neural Processor Unit (NPU)
Neural Processor Unit (NPU) | Intel AI Boost |
|---|
NPU Performance Up To (TOPS) | 13 TOPS |
|---|
Total Processor Performance Up To (TOPS) | 36 TOPS |
|---|
AI Datatype Support on NPU | INT8 |
|---|
Sparsity Support | Yes |
|---|
AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
|---|
Windows Studio Effects Support | Yes |
|---|
Cache Memory
Installed Size | L3 Cache – 36 MB |
|---|
Cache Per Processor | 36 MB |
|---|
RAM
Installed Size | 32 GB |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 5600 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 4 (Total) / 2 (empty) |
|---|
Features | Unbuffered |
|---|
Configuration Features | 2 x 16 GB |
|---|
Hard Drive
Type | SSD – M.2 |
|---|
Capacity | 1 x 1 TB |
|---|
Interface Type | PCI Express 4.0 |
|---|
Features | HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
|---|
Optical Storage
Monitor
Graphics Controller
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
|---|
Graphics Processor | NVIDIA RTX A1000 / Intel Graphics – up to 8 TOPS |
|---|
Video Memory | 8 GB GDDR6 SDRAM |
|---|
Input Device
Keyboard
Keyboard Name | HP 320K v2 |
|---|
Interface | USB |
|---|
Mouse
Mouse Name | HP 320M |
|---|
Interface | USB |
|---|
Networking
Ethernet Controller | Intel I219-LM, Intel I226-T1 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Expansion / Connectivity
Bays | 1 external 5.25″ Slim Line |
|---|
Slots | 2 M.2 Card – 2280 (PCIe 4.0 x4 mode)
1 M.2 Card – 2230 (for WLAN)
1 PCIe 5.0 x16
1 PCIe 4.0 x4 |
|---|
Interfaces | 2 x USB-C 3.2 Gen 2×2 (2 front)
6 x USB 3.2 Gen 2 (4 front, 2 rear)
1 x headphones/microphone (1 front)
2 x DisplayPort 1.4 (2 rear)
1 x LAN – RJ-45 (1 rear)
1 x audio line-out/line-in (1 rear)
3 x USB 2.0 (3 rear) |
|---|
Miscellaneous
Theft/Intrusion Protection | Chassis intrusion sensor |
|---|
Compliant Standards | Low halogen |
|---|
Manufacturer Selling Program | HP Smart Buy |
|---|
Power
Device Type | Power adapter |
|---|
Power Provided | 500 watt |
|---|
Efficiency | 92% |
|---|
Power Factor Correction | Yes (active) |
|---|
Operating System / Software
OS Provided | Windows 11 Pro |
|---|
Software | HP Support Assistant, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Client Catalogue (free download), HP Image Assistant (free download), HP Documentation, HP Notifications, HP System Software Manager (free download), HP Sure Click, HP Sure Run, HP Sure Recover, HP Manageability Integration Kit, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, WPS Office, HP Client Security Manager Gen6, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customiser for Commercial, HP Desktop Support Utilities, HP PC Hardware Diagnostics Windows, HP Sure Start, HP Driver Packs (free download), HP UEFI BIOS Certification level 2.7B |
|---|
Sustainability Information
Dimensions & Weight
Width | 10 cm |
|---|
Depth | 30.8 cm |
|---|
Height | 30.3 cm |
|---|
Weight | 4 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 49.9 cm |
|---|
Shipping Depth | 20 cm |
|---|
Shipping Height | 39.4 cm |
|---|
Shipping Weight | 6.5 kg |
|---|
