MSI PRO B850M-A WIFI, Motherboard, micro ATX, Socket AM5, AMD B850 Chipset, USB 3.2 Gen 2, USB-C 3.2 Gen2, USB 3.2 Gen 1, 5 Gigabit Ethernet, Wi-Fi 7, Bluetooth, onboard graphics (CPU required), HD Audio (8-channel)
$363.85 inc GST
30 in stock
Ships from Auckland or Christchurch
- Allow 1-2 days for delivery
- add 1-2 days if you are rural
- No Collections
Description
The MSI PRO B850M-A WIFI motherboard delivers comprehensive features for building a powerful system. Designed with a micro ATX form factor, it supports Ryzen processors and offers connectivity options. With capabilities for high-speed memory and multiple expansion slots, this motherboard is built to handle demanding applications and facilitate smooth multitasking.
Equipped with audio technology, the Realtek ALC897 codec ensures high definition audio output for an immersive sound experience. The motherboard also supports PCIe 5.0, providing performance for graphics and storage devices. Its integrated Wi-Fi 6E connectivity, alongside extensive USB support, allows for fast and efficient connections to peripherals, ensuring a seamless computing experience.
- Supports Ryzen processors for versatile performance
- High definition audio output for enhanced sound clarity
- Multiple PCIe slots for extensive expansion capabilities
- Robust USB connectivity including USB-C options
- Wi-Fi 6E support for faster wireless networking
- High performance connectivity
The motherboard offers multiple PCIe slots including PCIe 5.0 and PCIe 4.0, facilitating high-performance connectivity for graphics cards and storage solutions. - Enhanced audio experience
Powered by the Realtek ALC897 codec, the motherboard delivers high definition audio output with support for 8 channels, ensuring a rich sound environment. - Robust memory support
Featuring four DIMM slots for DDR5 SDRAM, the motherboard can accommodate high-speed memory options up to 8200 MT/s when overclocked. - Advanced wireless capabilities
Integrated Wi-Fi 6E and Bluetooth 5.4 provide users with speedy wireless connectivity and the option to connect multiple devices without hassle. - Durable construction
Constructed with a 6 Layer PCB and MSI Steel Armor technology, the motherboard is designed for durability and stability during operation.
Main Specifications
Product Description | MSI PRO B850M-A WIFI – motherboard – micro ATX – Socket AM5 – AMD B850 |
Product Type | Motherboard – micro ATX |
Chipset Type | AMD B850 |
Processor Socket | 1 x Socket AM5 |
Compatible Processors | Ryzen (supports Ryzen 7000/8000/9000 Series) |
Max RAM Size | 256 GB |
RAM Supported | 4 DIMM slots – DDR5, non-ECC, on-die ECC, unbuffered |
Storage Ports | 4 x SATA-600 (RAID), 2 x M.2 |
USB / FireWire Ports | 2 x USB-C 3.2 Gen 2 + 3 x USB 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + (1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers) |
Audio | HD Audio (8-channel) |
LAN | 5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4 |
Extended Specifications
General
Product Type | Motherboard – micro ATX |
|---|---|
Chipset Type | AMD B850 |
Processor Socket | Socket AM5 |
Max Processors Qty | 1 |
Compatible Processors | Ryzen (supports Ryzen 7000/8000/9000 Series) |
Supported RAM
Max Size | 256 GB |
|---|---|
Technology | DDR5 |
Bus Clock | 4800 MT/s, 5600 MT/s, 5600 MT/s (O.C.), 6000 MT/s (O.C.), 6400 MT/s (O.C.), 8200 MT/s (O.C.) |
Supported RAM Integrity Check | Non-ECC, on-die ECC |
Registered or Buffered | Unbuffered |
Features | AMD EXPO technology, dual channel memory architecture |
Audio
Type | HD Audio (8-channel) |
|---|---|
Audio Codec | Realtek ALC897 |
Compliant Standards | High Definition Audio |
LAN
Network Controller | Realtek RTL8126VB |
|---|---|
Network Interfaces | 5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4 |
Expansion / Connectivity
Expansion Slots | 1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x PCIe 3.0 x16 (x1 mode) 1 x PCIe 4.0 x16 (x4 mode) 2 x M.2 socket (2260/2280 M.2 Key M slot) |
|---|---|
Storage Interfaces | SATA-600 -connectors: 4 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 PCIe 5.0 -connectors: 1 x M.2 – RAID 0 / RAID 1 PCIe 4.0 -connectors: 1 x M.2 – RAID 0 / RAID 1 |
Interfaces | 1 x HDMI 2 x USB-C 3.2 Gen 2 3 x USB 3.2 Gen 1 3 x USB 3.2 Gen 2 1 x DisplayPort 1 x LAN (5Gigabit Ethernet) 1 x audio line-in – mini-jack 1 x microphone – mini-jack 1 x audio line-out – mini-jack 2 x aerial |
Internal Interfaces | 4 x USB 2.0 – header 2 x USB 3.2 Gen 1 – header 1 x USB-C 3.2 Gen 2 – header 1 x audio – header 1 x serial – header 1 x SPI – header |
Power Connectors | 24-pin main power connector, 2 x 8-pin ATX12V connectors |
Features
BIOS Type | AMI |
|---|---|
BIOS Features | MSI ClickBIOS |
Hardware Features | MSI EZ DIY, 8+2+1 Phase Power Design, MSI EZ OC, Extended Heatsink Design, M.2 Shield FROZR, pre-mounted I/O shield, MSI Steel Armor, MSI Audio Boost, MSI Mystic Light, EZ PCie Clip II, 6 Layer PCB, 2oz Copper PCB, MSI AI Engine, MSI AI LAN Manager, Frozr AI Cooling, EZ Debug LED, Surface Mount Technology (SMT), transient voltage suppressors, MSI Stainless Steel Back I/O |
Miscellaneous
Included Accessories | EZ Wi-Fi antenna, 2 x EZ M.2 clip II, EZ M.2 clip II remover |
|---|---|
Cables Included | 1 x Serial ATA cable |
Software Included | MSI Center |
Width | 24.384 cm |
Depth | 24.384 cm |
