Milesight IR Mini MS-C2964-(R)PD, Network surveillance camera, bullet, vandal / weatherproof, colour (Day&Night), 2 MP, 1920 x 1080, Ethernet 10Base-T/100Base-T, H.265+, H.265, HEVC, H.264+, H.264, MJPEG, PoE
$361.35 inc GST
✓ In Stock - 8 available
✓ Free NZ Delivery
8 in stock
Ships from: Christchurch
- Allow 2–3 days for delivery to the North Island
- Allow 1–2 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Milesight IR Mini MS-C2964-(R)PD offers reliable surveillance with its robust design and environmental adaptability. Capable of functioning in extreme temperatures ranging from -40°C to 60°C, this network surveillance camera ensures continuous monitoring in various conditions. With a multi-sensor system and multiple focal lengths, users can achieve the perfect angle and clarity for specific surveillance needs, complemented by a 1920 x 1080 maximum digital video resolution and 60 frames per second for smooth video capture.
The durable construction of this camera, rated IP67 and IK10, ensures weather and vandal resistance, suitable for outdoor and high-security environments. Integrated features such as Advanced Motion Detection, privacy masking, and region detection enhance its functionality, providing versatile options for monitoring and security. With Power over Ethernet (PoE) capabilities and a variety of network protocols for seamless connectivity, the Milesight IR Mini is a practical choice for comprehensive surveillance solutions.
- Operates in extreme temperatures from -40°C to 60°C
- Provides a maximum digital video resolution of 1920 x 1080
- Features advanced motion detection and privacy masking
- Weather and vandal-proof design with IP67 and IK10 ratings
- Includes Power over Ethernet for easy installation
- Environmental adaptability
This camera operates effectively in temperatures ranging from -40°C to 60°C, ensuring reliability in various climate conditions. - High-quality video capture
With a maximum resolution of 1920 x 1080 and a frame rate of 60 frames per second, the camera delivers clear and fluid video output. - Protection features
The IP67 and IK10 ratings provide protection against dust, water, and vandalism, making it suitable for challenging environments. - Detection capabilities
Equipped with multiple motion detection features, including line-crossing and loitering detection, the camera enhances security and monitoring efficiency. - Connectivity options
Supports PoE for simplified power management and features a wide range of network protocols ensuring seamless integration into existing systems.
Main Specifications
Product Description | Milesight IR Mini MS-C2964-(R)PD – network surveillance camera – bullet |
Device Type | Network surveillance camera – fixed – bullet – vandal / weatherproof |
Dimensions (WxDxH) | 6.4 cm x 16 cm x 6.4 cm |
Weight | 450 g |
Connectivity Technology | Wired |
Camera | Colour – Day&Night |
Max Resolution | 1920 x 1080 |
Frame Rate (max) | 60 frames per second |
Motion Detection | Yes |
Optical Sensor Type | 1 x Progressive Scan CMOS – 1/2.8″ 1 x Progressive Scan CMOS – 1/2.8″ 1 x Progressive Scan CMOS – 1/2.8″ |
Lens System | 1 x fixed focal – 2.8 mm – M12 mount – f/1.6 1 x fixed focal – 4 mm – M12 mount – f/1.6 1 x fixed focal – 6 mm – M12 mount – f/1.6 |
Minimum Illumination | 0.005 lux – colour – F1.6 0 lux – B&W |
Interfaces | Ethernet 10Base-T/100Base-T |
Voltage | PoE |
Features | 120 dB wide dynamic range, >55 dB SNR, Constant Bitrate (CBR), Variable Bitrate (VBR), privacy masking (up to 4 areas), Region of Interest (ROI), up to 8 view areas, brightness control, contrast control, saturation control, sharpness control, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), Backlight Compensation (BLC), Highlight Compensation (HLC), Defog, Automatic Whiteness Balance (AWB), IP address filtering, Automatic Gain Control (AGC), anti-flicker, Corridor mode, deblur, region entrance detection, region exiting detection, Advanced Motion Detection, line-crossing detection, loitering detection, Object Left detection, Object Removed, object line crossing counting, people counting, VoIP support, ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, metal housing, reset button |
Environmental Parameters (operating) | -40 °C – 60 °C; 0 – 90% (non-condensing) relative humidity |
Documents
Extended Specifications
General
Device Type | Network surveillance camera |
|---|---|
Form Factor | Bullet |
Connectivity Technology | Wired |
Width | 6.4 cm |
Depth | 16 cm |
Height | 6.4 cm |
Weight | 450 g |
Camera
Type | Colour – Day&Night – fixed – vandal / weatherproof |
|---|---|
Digital Video Format | H.265+, H.265, HEVC, H.264+, H.264, MJPEG |
Max Digital Video Resolution | 1920 x 1080 |
Motion Detection | Yes |
Exposure Range | 1 sec – 1/100000 sec |
Minimum Illumination | 0.005 lux – colour – F1.6 0 lux – B&W |
Infrared LEDs | Yes |
Infrared Distance | 30 m |
Digital Video Capture Resolution | 1920 x 1080, 1280 x 960, 1280 x 720, 704 x 576, 640 x 480, 640 x 360, 352 x 288 |
Frame Rate (max) | 60 frames per second |
Features | 120 dB wide dynamic range, >55 dB SNR, Constant Bitrate (CBR), Variable Bitrate (VBR), privacy masking (up to 4 areas), Region of Interest (ROI), up to 8 view areas, brightness control, contrast control, saturation control, sharpness control, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), Backlight Compensation (BLC), Highlight Compensation (HLC), Defog, Automatic Whiteness Balance (AWB), IP address filtering, Automatic Gain Control (AGC), anti-flicker, Corridor mode, deblur, region entrance detection, region exiting detection, Advanced Motion Detection, line-crossing detection, loitering detection, Object Left detection, Object Removed, object line crossing counting, people counting, VoIP support, ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, metal housing, reset button |
Image Sensor
Type | 1 x Progressive Scan CMOS 1/2.8″ 1 x Progressive Scan CMOS 1/2.8″ 1 x Progressive Scan CMOS 1/2.8″ |
|---|
Lens Construction
Lens System | 1 x fixed focal – 2.8 mm – M12 mount – f/1.6 – 111° (H) / 61° (V) / 128° (D) 1 x fixed focal – 4 mm – M12 mount – f/1.6 – 91° (H) / 50° (V) / 106° (D) 1 x fixed focal – 6 mm – M12 mount – f/1.6 – 55° (H) / 32° (V) / 63° (D) |
|---|
Interfaces
Network Interface | Ethernet 10Base-T/100Base-T |
|---|---|
Network Protocols | IPv4, IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, LLDP, SIP, PPPoE, QOS, IGMP, ICMP, SSL, TLS |
Expansion / Connectivity
Ports | LAN/power – RJ-45 |
|---|---|
Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
Encryption Algorithm | TLS 1.2 |
Miscellaneous
Compliant Standards | IEEE 802.3af, IP67, IK10, NDAA |
|---|
Power
Power Requirements | PoE |
|---|---|
Power Device | 3.1 Watt |
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|---|
Max Operating Temperature | 60 °C |
Relative Humidity (operating) | 0 – 90% (non-condensing) |
