ASUS ExpertCenter D5 D501SERES 714700044X, SFF Core i7 i7-14700 / up to 5.4 GHz, RAM 16 GB, SSD 256 GB, NVMe, UHD Graphics 770, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.4, Win 11 Pro, monitor: none, black
$2,356.47 inc GST
✓ In Stock - 10 available
✓ Free NZ Delivery
10 in stock
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The ASUS ExpertCenter D5 D501SERES combines performance and efficiency in a compact design, making it an ideal choice for professionals seeking stability and power. Featuring a 20-core Intel Core i7 processor with a maximum turbo speed of 5.4 GHz, this personal computer is designed to handle demanding tasks with ease. The system supports 16 GB of DDR5 RAM, ensuring smooth multitasking and enhanced responsiveness, while the 256 GB SSD provides fast storage and quick boot times.
Equipped with high definition audio output in a 7.1 channel surround format, the ASUS ExpertCenter D5 offers an immersive audio experience. With comprehensive connectivity options including HDMI, DisplayPort, and USB 3.2, users can easily connect multiple devices and displays. This EPEAT Gold certified system is designed with energy efficiency in mind, featuring an 80 PLUS Platinum certified power supply, making it a responsible choice for environmentally-conscious consumers.
- 20-core Intel Core i7 processor for powerful performance
- Supports up to 16 GB of DDR5 RAM for efficient multitasking
- 256 GB SSD with NVMe technology for rapid data access
- 7.1 channel surround sound output for enhanced audio experience
- EPEAT Gold certified and ENERGY STAR certified for energy efficiency
- Efficient performance
The ASUS ExpertCenter D5 features a powerful Intel Core i7 processor with a clock speed of 2.1 GHz and a maximum turbo speed of 5.4 GHz, ensuring reliability for demanding applications. - Fast data access
The 256 GB SSD utilizes PCIe 4.0 and NVMe technology, providing rapid data retrieval and storage capabilities to enhance overall system efficiency. - Versatile connectivity
With various ports including HDMI, DisplayPort, and USB 3.2, the system offers flexible connectivity for multiple devices and peripherals. - High quality audio
Enjoy an immersive sound experience with 7.1 channel surround audio output, ideal for multimedia applications and entertainment. - Environmentally responsible
Certified with EPEAT Gold and equipped with an 80 PLUS Platinum power supply, the system combines performance with sustainable practices.
Main Specifications
Product Description | ASUS ExpertCenter D5 D501SERES 714700044X – SFF Core i7 i7-14700 2.1 GHz – 16 GB – SSD 256 GB |
Type | Personal computer – SFF |
Processor | Intel Core i7 (14th Gen) i7-14700 / 2.1 GHz (up to 5.4 GHz, (20-core) |
Processor Main Features | Intel Smart Cache |
Cache Memory | 33 MB |
Cache Per Processor | 33 MB |
RAM | 16 GB (installed) / 64 GB (max) – DDR5 SDRAM |
Storage Controller | SATA (SATA 6Gb/s) |
Hard Drive | SSD 256 GB – PCI Express 4.0 – M.2 2280 – NVM Express (NVMe) |
Optical Storage | No optical drive |
Graphics Controller | Intel UHD Graphics 770 |
Audio Output | 7.1 channel surround |
Networking | 1GbE, 802.11a, Wi-Fi 5, Wi-Fi 6E, 802.11b/g/n, Bluetooth |
OS Provided | Windows 11 Pro |
Software Included | ASUS Business Manager, MyASUS, Adobe Creative Cloud All Apps (1 month membership), McAfee (30 days trial) |
Colour | Black |
Dimensions (WxDxH) | 9.3 cm x 29.6 cm x 30.9 cm |
Weight | 6 kg |
Environmental Standards | ENERGY STAR Qualified EPEAT Gold |
Documents
Extended Specifications
General
Type | Personal computer |
|---|---|
Product Form Factor | SFF |
Built-in Devices | Air cooling solution |
Embedded Security | Trusted Platform Module (TPM 2.0) and firmware (TPM) |
Colour | Black |
Processor / Chipset
CPU | Intel Core i7 (14th Gen) i7-14700 |
|---|---|
Clock Speed | 2.1 GHz (P-core) / 1.5 GHz (E-core) |
Max Turbo Speed | 5.4 GHz (P-core) / 4.2 GHz (E-core) |
Number of Cores | 20-core |
CPU Qty | 1 |
Max CPU Qty | 1 |
Processor Main Features | Intel Smart Cache |
Chipset Type | Intel B760 |
Cache Memory
Installed Size | 33 MB |
|---|---|
Cache Per Processor | 33 MB |
RAM
Installed Size | 16 GB (installed) / 64 GB (max) |
|---|---|
Technology | DDR5 SDRAM |
Rated Memory Speed | 5600 MHz |
Form Factor | DIMM 288-pin |
Slots | 2 (Total) / 1 (empty) |
Features | Unbuffered |
Configuration Features | 1 x 16 GB |
Hard Drive
Type | SSD – M.2 2280 |
|---|---|
Capacity | 256 GB |
Interface Type | PCI Express 4.0 |
Features | NVM Express (NVMe) |
Storage Controller
Type | SATA |
|---|---|
Controller Interface Type | SATA 6Gb/s |
Channel Qty | 4 |
Optical Storage
Type | No optical drive |
|---|
Monitor
Monitor Type | None. |
|---|
Graphics Controller
Graphics Processor | Intel UHD Graphics 770 |
|---|---|
Video Interfaces | HDMI, DisplayPort, VGA |
Audio Output
Sound Output Mode | 7.1 channel surround |
|---|---|
Compliant Standards | High Definition Audio |
Input Device
Type | Keyboard, mouse |
|---|
Keyboard
Interface | USB |
|---|
Mouse
Interface | USB |
|---|
Networking
Ethernet Controller | Intel WGI219V |
|---|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 5.4 |
Features | Dual stream (2×2) |
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x internal 2.5″ 1 (total) / 1 (free) x internal 3.5″ |
|---|---|
Slots | 1 (total) / 0 (free) x M.2 Card – 2280 (for SSD) 1 (total) / 1 (free) x PCIe 4.0 x16 2 (total) / 2 (free) x PCIe 3.0 x1 1 M.2 Card (for wireless module) 1 (total) / 1 (free) x M.2 Card – 2230 (for SSD) |
Interfaces | 1 x LAN (Gigabit Ethernet) – RJ-45 (1 rear) 1 x HDMI (1 rear) 1 x VGA (1 rear) 1 x audio line-in – mini-jack (1 rear) 1 x microphone – mini-jack (1 rear) 2 x audio line-out – mini-jack (1 front, 1 rear) 4 x USB 2.0 (2 front, 2 rear) 2 x USB 3.2 Gen 1 (2 rear) 1 x DisplayPort (1 rear) 1 x headphones/microphone – mini-jack (1 front) 2 x USB 3.2 Gen 2 (2 front) |
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
|---|---|
Security Slot Type | Kensington security slot |
Compliant Standards | WEEE, DisplayPort 1.4, REACH, RoHS |
Power
Device Type | Power supply |
|---|---|
Power Provided | 330 Watt |
80 PLUS Certification | 80 PLUS Platinum |
Operating System / Software
OS Provided | Windows 11 Pro |
|---|---|
Software | ASUS Business Manager, MyASUS, Adobe Creative Cloud All Apps (1 month membership), McAfee (30 days trial) |
Sustainability Information
EPEAT Compliant | EPEAT Gold |
|---|---|
ENERGY STAR Certified | Yes |
ENERGY STAR Version | 8.0 |
Dimensions & Weight
Width | 9.3 cm |
|---|---|
Depth | 29.6 cm |
Height | 30.9 cm |
Weight | 6 kg |
Additional information
| Manufacturer | |
|---|---|
| Colour | |
| Installed Memory | |
| CPU | |
| Installed Storage | |
| Graphics Processor |
