Allied Telesis CentreCOM FS980M/28, Switch, L3, Managed, 24 x 10/100 + 4 x 1000Base-X SFP (uplink), rack-mountable
$190.60 inc GST
✓ In Stock - 30 available
✓ Free NZ Delivery
30 in stock
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The FS980M/28 features 24x 10/100TX ports and 4x 100/1000X SFP uplink/stacking ports. CentreCOM FS980M switches are cost-effective, fully managed, and can be stacked for increased resiliency and port density at the edge of the network. As part of an Allied Telesis Management Framework (AMF) network, the FS980M switches utilize automated management and zero-touch recovery to lower running costs.
- Allied Telesis Management Framework (AMF)
- Ethernet Protection Switched Ring (EPSRing)
- IPv6 support
- Eco-friendly
- Stacking
Main Specifications
Product Description | Allied Telesis CentreCOM FS980M/28 – switch – 24 ports – Managed – rack-mountable |
Device Type | Switch – 24 ports – L3 – Managed – stackable |
Enclosure Type | Rack-mountable |
Subtype | Fast Ethernet |
Ports | 24 x 10/100 + 4 x 1000Base-X SFP (uplink) |
Performance | Switching fabric bandwidth: 12.8 Gbps Forwarding performance: 9.52 Mpps Stacking bandwidth: 4 Gbps |
Capacity | QoS hardware queues per port: 8 |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 10000 bytes |
Routing Protocol | RIP-1, RIP-2, IGMPv2, IGMP, IGMPv3, static IPv4 routing, MLDv2, MLD, CIDR |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI, SNMP 6, SSH 6 |
Features | ARP support, Syslog support, port mirroring, DiffServ support, WRR queuing, SNTP support, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, PVST+, STP Root Guard, UDLD, fanless, LLDP support, LACP, DHCP client, MIB, GVRP, NAC, loop prevention, SP, 802.1x authentication, IP source guard, EPSRing, VCStack, BPDU, Logical Link Control, ICMP, CPP, SCP, AMF, MIB II, DDM, NTP, AAA, DNS client, NTP client |
Compliant Standards | IEEE 802.2, IEEE 802.3, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, X.509, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1AX |
Power | (50/60 Hz) |
Dimensions (WxDxH) | 44 cm x 25.7 cm x 4.32 cm |
Weight | 3.2 kg |
Extended Specifications
General
Device Type | Switch – 24 ports – L3 – Managed – stackable |
|---|---|
Enclosure Type | Rack-mountable |
Subtype | Fast Ethernet |
Ports | 24 x 10/100 + 4 x 1000Base-X SFP (uplink) |
Performance | Switching fabric bandwidth: 12.8 Gbps Forwarding performance: 9.52 Mpps Stacking bandwidth: 4 Gbps |
Capacity | QoS hardware queues per port: 8 |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 10000 bytes |
Routing Protocol | RIP-1, RIP-2, IGMPv2, IGMP, IGMPv3, static IPv4 routing, MLDv2, MLD, CIDR |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI, SNMP 6, SSH 6 |
Encryption Algorithm | DES, Triple DES, RSA, MD5, TLS, SHA-1, SSL 3.0, SSL 2.0, PEAP, TTLS, TLS 1.2 |
Authentication Method | Secure Shell (SSH), RADIUS, Secure Shell v.2 (SSH2) |
Features | ARP support, Syslog support, port mirroring, DiffServ support, WRR queuing, SNTP support, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, PVST+, STP Root Guard, UDLD, fanless, LLDP support, LACP, DHCP client, MIB, GVRP, NAC, loop prevention, SP, 802.1x authentication, IP source guard, EPSRing, VCStack, BPDU, Logical Link Control, ICMP, CPP, SCP, AMF, MIB II, DDM, NTP, AAA, DNS client, NTP client |
Compliant Standards | IEEE 802.2, IEEE 802.3, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, X.509, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1AX |
RAM | 512 MB |
Flash Memory | 128 MB |
Status Indicators | Status |
Expansion / Connectivity
Interfaces | 24 x 100Base-TX RJ-45 4 x 1000Base-X SFP uplink/stacking 1 x console RJ-45 |
|---|
Power
Power Device | Internal power supply |
|---|---|
Voltage Required | (50/60 Hz) |
Power Consumption Operational | 19 Watt |
Miscellaneous
Compliant Standards | TUV, C-Tick, EN55024, EN 55022 Class A, FCC Part 15 B, UL 60950-1 Second Edition, cULus, CSA C22.2 No. 60950-1, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, AS/NZS CISPR22:2006, RoHS |
|---|
Dimensions & Weight
Width | 44 cm |
|---|---|
Depth | 25.7 cm |
Height | 4.32 cm |
Weight | 3.2 kg |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 50 °C |
Humidity Range Operating | 5 – 90% (non-condensing) |
Min Storage Temperature | -20 °C |
Max Storage Temperature | 60 °C |
Humidity Range Storage | 5 – 95% (non-condensing) |
