Description
The HPE ProLiant ML110 Gen11 server is an enhanced single processor tower with performance, expansion, and security at an affordable price. It supports the 4th Gen Intel Xeon Scalable processor, HPE DDR5 Smart Memory with a maximum capacity of 1024 GB, 4 x16 PCIe Gen5 slots, 1 x16 OCP3 slot, eight large form factor (LFF) or 16 small form factor (SFF) disk drives. It can easily be converted to a rack using 5.5U of rack space.
- Increased memory bandwidth, performance and lower power requirements
- Advanced data transfer rates from the PCIe Gen5 serial expansion bus
- Includes HPE Integrated Lights-Out 6 server management software
- Enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly from anywhere
- Supports hot-pluggable, high-availability, RAID1 protected M.2 NVMe boot option
- Embedded Intel VROC SATA
- Intuitive cloud operating experience: simple, unified, and automated
HPE ProLiant ML110 Gen11 servers are engineered for your hybrid world. HPE ProLiant Gen11 servers simplify the way you control your business’s compute – from edge to cloud – with a cloud operating experience. Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a single console. - Trusted security by design: uncompromising, fundamental, and protected
HPE ProLiant ML110 Gen11 server uses the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel Processor that must be matched exactly before the server will boot. This verifies that malicious code is contained, and healthy servers are protected. HPE ProLiant Gen11 servers continuously protect healthy servers at the edge by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, with IDevID certificates installed by default. HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, data connections, and providing a fast path to bring a server back online and into normal operations. - Customized performance for your workloads: accelerated, open, and efficient
The HPE ProLiant ML110 Gen11 server is an excellent choice for compute and data storage balanced workloads requiring outstanding performance, network and I/O bandwidth. Harness advanced compute performance. HPE ProLiant ML110 Gen11 server is powered by 4th Gen Intel Xeon Scalable Processors that support up to 32 cores at 185W TDP. Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 4 x16 PCIe Gen5 and 1 x16 OCP slots to improve I/O throughput and reduce latency. Utilize 16 DIMM slots for up to 1 TB DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
What’s in the Box
- HPE ProLiant ML110 Gen11
- 2 x standard fans
Main Specifications
Product Description | HPE ProLiant ML110 Gen11 – tower Xeon Silver 4514Y 2 GHz – 32 GB – SSD 960 GB |
Type | Server – tower |
Height (Rack Units) | 4.5U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon Silver 4514Y / 2 GHz (up to 3.4 GHz, (16-core) |
Cache Memory | 30 MB L3 Cache |
Cache Per Processor | 30 MB |
RAM | 32 GB (installed) / 1 TB (max) – DDR5 SDRAM – Advanced ECC |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | SSD 960 GB |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Yes |
OS Provided | No operating system |
Software Included | HPE iLO Advanced, HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
Dimensions (WxDxH) | 19.5 cm x 58.7 cm x 46.2 cm |
Weight | 12.3 kg |
Environmental Standards | ENERGY STAR Qualified EPEAT Bronze |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Tower – 4.5U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon Silver 4514Y |
|---|
Clock Speed | 2 GHz |
|---|
Max Turbo Speed | 3.4 GHz |
|---|
Number of Cores | 16-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Chipset Type | Intel C741 |
|---|
Cache Memory
Installed Size | L3 Cache – 30 MB |
|---|
Cache Per Processor | 30 MB |
|---|
RAM
Installed Size | 32 GB (installed) / 1 TB (max) |
|---|
Technology | DDR5 SDRAM – Advanced ECC |
|---|
Effective Memory Speed | 4400 MT/s |
|---|
Rated Memory Speed | 5600 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 16 (Total) / 15 (empty) |
|---|
Features | Registered, HPE SmartMemory |
|---|
Configuration Features | 1 x 32 GB |
|---|
Hard Drive
Type | SSD |
|---|
Capacity | 1 x 960 GB |
|---|
Storage Controller
Type | 1 x RAID |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Remote Management Protocol | SNMP 3, IPMI 2.0, SMASH CLP |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | Wake on LAN (WoL), PXE support |
|---|
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x external 5.25″
8 (total) / 6 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 2 (total) / 2 (free) x PCIe 5.0 x16
1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode) |
|---|
Interfaces | 1 x VGA
2 x LAN (Gigabit Ethernet)
1 x HPE iLO – RJ-45 (1 rear)
3 x USB 3.0 (1 front, 2 rear)
1 x HPE iLO – Type A (1 in front) |
|---|
Miscellaneous
Included Accessories | 2 x standard fans |
|---|
Compliant Standards | AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, Redfish API, FIPS 140-3, ErP Lot 9, ACPI 6.4, PCIe 5.0, SMBIOS 3.4, UEFI 2.7, DMTF, Active Directory v1.0, UEFI Class 3, APML, MCTP |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 1 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-120/200-240 V |
|---|
Power Provided | 800 watt |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
Software | HPE iLO Advanced, HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
|---|
Sustainability Information
EPEAT Compliant | EPEAT Bronze |
|---|
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 19.5 cm |
|---|
Depth | 58.7 cm |
|---|
Height | 46.2 cm |
|---|
Weight | 12.3 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
