Description
The HPE ProLiant DL385 Gen11 server is a 2U 2P solution that delivers exceptional compute performance, upgraded high-speed data transfer rate and memory depth at 2P compute capability. Powered by 4th Generation AMD EPYC 9004 Series Processors, increased memory bandwidth and capacity, high-speed PCIe Gen5 I/O, enhanced GPU support, and EDSFF storage, the HPE ProLiant DL385 Gen11 server is a superb accelerator-optimized 2U 2P solution. Enhanced security features with the silicon root of trust from HPE are built into the firmware, creating a digital fingerprint for the AMD Secure Processor to validate safe operation prior to boot. HPE ProLiant DL385 Gen11 server is an excellent choice for compute and data storage demanding workloads requiring increased core count, and storage and I/O scalability.
- Intuitive cloud operating experience: simple, self-service, and automated
- Trusted security by design: uncompromising, fundamental, and protected
- Customized performance for your workloads: accelerated, open, and efficient
- Intuitive cloud operating experience: simple, self-service, and automated
HPE ProLiant DL385 Gen11 servers are engineered for your hybrid world. The HPE ProLiant Gen11 servers simplify the way you control your business’s compute – from edge to cloud – with a cloud operating experience. Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console. Automate tasks for efficiency in deployment and instant scalability for seamless, simplified support and lifecycle management, reducing tasks and shortening maintenance windows. These experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consumed as-a-service using HPE GreenLake as your compute and storage demands grow. Simplify and secure server management from edge to cloud with HPE GreenLake for Compute Ops Management. HPE GreenLake for Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally. - Trusted security by design: uncompromising, fundamental, and protected
The HPE ProLiant DL385 Gen11 server is tied into the silicon root of trust and the AMD Secure Processor, a dedicated security processor embedded in the AMD EPYC system on a chip (SoC), to manage secure boot, memory encryption, and secure virtualization. HPE ProLiant Gen11 servers use the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the AMD Secure Processor that must be matched exactly before the server will boot. This verifies that malicious code is contained, and healthy servers are protected. HPE ProLiant Gen11 servers continuously protect healthy servers at the edge by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, with IDevID certificates installed by default. HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, data connections, and providing a fast path to bring a server back online and into normal operations. From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into their DNA. - Customized performance for your workloads: accelerated, open, and efficient
Harness major computer performance. The HPE ProLiant DL385 Gen11 server is powered by the 4th Generation AMD EPYC 9004 Series Processors with 5 nm technology that supports up to 96 cores, 400W, and 384 MB of L3 cache. Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with PCIe Gen5 and two OCP slots, improve I/O throughput and reduce latency. Increased memory bandwidth and performance, and lower power requirements with 12 DIMM channels per processor for DDR5 memory. Provide real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
Main Specifications
Product Description | HPE ProLiant DL385 Gen11 – rack-mountable EPYC 9135 3.65 GHz – 64 GB – SSD 4 x 960 GB |
Type | Server – rack-mountable |
Height (Rack Units) | 1U |
Server Scalability | 2-way |
Processor | 1 x AMD EPYC 9135 / 3.65 GHz (up to 4.3 GHz, (16-core) |
Cache Memory | 64 MB L3 Cache |
Cache Per Processor | 64 MB |
RAM | 64 GB (installed) / 6 TB (max) – DDR5 SDRAM – Advanced ECC |
Storage Controller | RAID OCP (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 4 x SSD 960 GB |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Yes |
OS Provided | No operating system |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE iLO Advanced |
Dimensions (WxDxH) | 8.75 cm x 43.47 cm x 64.64 cm |
Weight | 42.82 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 1U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 2-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | AMD EPYC 9135 |
|---|
Clock Speed | 3.65 GHz |
|---|
Max Turbo Speed | 4.3 GHz |
|---|
Number of Cores | 16-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 2 |
|---|
CPU Upgradability | Upgradable |
|---|
Cache Memory
Installed Size | L3 Cache – 64 MB |
|---|
Cache Per Processor | 64 MB |
|---|
RAM
Installed Size | 64 GB (installed) / 6 TB (max) |
|---|
Technology | DDR5 SDRAM – Advanced ECC |
|---|
Effective Memory Speed | 6400 MT/s |
|---|
Rated Memory Speed | 6400 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 24 (Total) / 22 (empty) |
|---|
Features | HPE SmartMemory, registered, slots 13 – 24 are available in two-processor configuration only |
|---|
Configuration Features | 2 x 32 GB |
|---|
Hard Drive
Type | SSD |
|---|
Capacity | 4 x 960 GB |
|---|
Storage Controller
Type | 1 x RAID – OCP |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Remote Management Protocol | IPMI 2.0, SNMP 3 |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | Wake on LAN (WoL), PXE support |
|---|
Expansion / Connectivity
Bays | 8 (total) / 6 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 (full-height, half-length) 2 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0 |
|---|
Interfaces | 1 x HPE iLO (1 in front) (service port) 5 x USB 3.1 Gen 1 (1 front, 2 rear, 2 internal) 1 x VGA |
|---|
Miscellaneous
Compliant Standards | ACPI 6.1, PCIe 4.0, SMBIOS 3.1, UEFI 2.7, Redfish API, AES, Triple DES, TLS v1.2, DMTF, APML 1.0, Active Directory v1.0, ASHRAE Class A3, ASHRAE Class A4, WEEE 2002/95/EC, ErP Lot 9, FIPS 140-3 |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-120/200-240 V |
|---|
Power Provided | 1600 Watt |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE iLO Advanced |
|---|
Sustainability Information
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 8.75 cm |
|---|
Depth | 43.47 cm |
|---|
Height | 64.64 cm |
|---|
Weight | 42.82 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 99.8 cm |
|---|
Shipping Depth | 60 cm |
|---|
Shipping Height | 27 cm |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
