Description
The HPE ProLiant DL365 Gen11 server is a rack-optimized 1U 2P dense solution that delivers exceptional compute performance, upgraded high-speed data transfer rate and memory depth at 2P compute capability. Powered by 4th Generation AMD EPYC Processors with up to 96 cores, increased memory bandwidth, and high-speed PCIe Gen5 I/O, the HPE ProLiant DL365 Gen11 server is a superb rack-optimized, 1U 2P, dense solution. The silicon root of trust anchors the server firmware to an HPE-exclusive ASIC, creating an immutable fingerprint for the AMD Secure Processor that must be matched exactly before the server boots. The HPE ProLiant DL365 Gen11 server is an excellent choice for those who require increased compute density with built-in security and flexibility.
Main Specifications
Product Description | HPE ProLiant DL365 Gen11 – rack-mountable EPYC 9135 3.65 GHz – 64 GB – SSD 4 x 960 GB |
Type | Server – rack-mountable |
Height (Rack Units) | 1U |
Server Scalability | 2-way |
Processor | 1 x AMD EPYC 9135 / 3.65 GHz (up to 4.3 GHz, (16-core) |
Cache Memory | 64 MB L3 Cache |
Cache Per Processor | 64 MB |
RAM | 64 GB (installed) / 6 TB (max) – DDR5 SDRAM – Advanced ECC |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 4 x SSD 960 GB |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Yes |
OS Provided | No operating system |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE iLO Advanced |
Dimensions (WxDxH) | 44.89 cm x 64.94 cm x 4.29 cm |
Weight | 29.36 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 1U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 2-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | AMD EPYC 9135 |
|---|
Clock Speed | 3.65 GHz |
|---|
Max Turbo Speed | 4.3 GHz |
|---|
Number of Cores | 16-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 2 |
|---|
CPU Upgradability | Upgradable |
|---|
Cache Memory
Installed Size | L3 Cache – 64 MB |
|---|
Cache Per Processor | 64 MB |
|---|
RAM
Installed Size | 64 GB (installed) / 6 TB (max) |
|---|
Technology | DDR5 SDRAM – Advanced ECC |
|---|
Effective Memory Speed | 6400 MT/s |
|---|
Rated Memory Speed | 6400 MT/s |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 24 (Total) / 22 (empty) |
|---|
Features | HPE SmartMemory, registered, slots 13 – 24 are available in two-processor configuration only |
|---|
Configuration Features | 2 x 32 GB |
|---|
Hard Drive
Type | SSD |
|---|
Capacity | 4 x 960 GB |
|---|
Storage Controller
Type | 1 x RAID |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Remote Management Protocol | IPMI 2.0, SNMP 3 |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | Wake on LAN (WoL), PXE support |
|---|
Expansion / Connectivity
Bays | 8 (total) / 6 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 (x16 mode)
2 (total) / 0 (free) x Open Compute Project mezzanine (OCP) 3.0 |
|---|
Interfaces | 1 x HPE iLO (1 in front) (service port)
5 x USB 3.1 Gen 1 (1 front, 2 rear, 2 internal)
1 x VGA
2 x LAN (1/10 Gigabit Ethernet) |
|---|
Miscellaneous
Compliant Standards | ACPI 6.4, PCIe 5.0, SMBIOS 3.1, UEFI 2.7, UEFI Class 3, Redfish API, AES, Triple DES, TLS v1.2, DMTF, Active Directory v1.0, ASHRAE Class A3, ASHRAE Class A4, APML 1.0, FIPS 140-3, ErP Lot 9, WEEE 2002/95/EC |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-240 V |
|---|
Power Provided | 1600 Watt |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE iLO Advanced |
|---|
Sustainability Information
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Dimensions & Weight Details | 60 cm – 24.2 cm – 91.6 cm |
|---|
Width | 44.89 cm |
|---|
Depth | 64.94 cm |
|---|
Height | 4.29 cm |
|---|
Weight | 29.36 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
