Description
Empower your teams with rich, immersive collaborative experiences across town and around the world in an instant. The HP Presence Mini Conferencing PC with Zoom Rooms is designed to work with your existing audiovisual infrastructure, including touch-control panels and up to three displays.
- Setting up your conferencing space is fast and easy with an Intel processor driven PC that has Zoom Rooms preinstalled and broad device compatibility.
- Seamlessly deploy this PC into your existing Zoom Rooms environment, where it can drive up to three displays. Mount it on a wall or under a table with the integrated VESA plate.
- Get a highly secure and manageable PC that has the self-healing protection of HP Sure Start Gen7 and easy device management with HP Manageability Integration Kit.
- Conference room ready
Get powerful performance from Windows IoT and an Intel processor. - Expand your solution
Easily connect your certified audio, video, and Poly TC10 controller to the HP Mini Conferencing PC with Zoom Rooms for a great conference room experience. - Automatic recovery from firmware attacks
Firmware attacks can completely devastate your PC. Stay protected with HP’s self-healing BIOS-HP Sure Start Gen7 automatically recovers the BIOS from malware, rootkits, or corruption. - Easy management with Poly Lens
Easily manage the system and connected Poly peripherals remotely using Poly Lens, providing IT professionals with efficient control and maintenance capabilities. - Get PC images right the first time
Improve the quality and security of custom Windows images with HP Image Assistant which assists ITDMs with image creation, identifies problems, and provides recommendations and remediation. - Built-in durability
Rest easy with a PC that goes the distance and is designed to pass 120,000 hours of HP Total Test Process and undergoes MIL-STD 810 testing. Help protect your PC from dust ingress with an optional removable dust filter.
What’s in the Box
- 90W External Power Adapter
- DisplayPort to HDMI Video Adapter
- Dual VESA Sleeve V3
- External Power Adapter AC Power cable(1.8 m regional)
- HP Mini Conference G9 PC with Zoom Rooms
- Power Supply Holder V4
Main Specifications
Product Description | HP Mini Conference G9 – mini desktop Core i7 12700T 1.4 GHz – vPro – 16 GB – SSD 256 GB |
Type | Personal computer – mini desktop |
Platform Technology | Intel vPro Platform |
Processor | Intel Core i7 (12th Gen) 12700T / 1.4 GHz (up to 4.7 GHz, (12-core) |
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0 |
Cache Memory | 25 MB L3 Cache |
Cache Per Processor | 25 MB |
RAM | 16 GB (installed) / 64 GB (max) – DDR5 SDRAM |
Storage Controller | SATA/NVMe (SATA-600 / NVMe) |
Hard Drive | SSD 256 GB – PCI Express 4.0 x4 – M.2 2280 – NVM Express (NVMe), triple-level cell (TLC) |
Optical Storage | No optical drive |
Graphics Controller | Intel UHD Graphics 770 |
Audio Output | Stereo |
Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Bluetooth 5.2, Wi-Fi 6E |
Power | (50/60 Hz) |
OS Provided | Windows 10 IoT Enterprise |
Software Included | HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP DriveLock, myHP, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Touchpoint Customizer, HP Easy Clean, HP Smart Support, HP Connect for Microsoft Endpoint Manager, HP SureRun Gen5, HP Sure Recover Gen5, HP Wolf Security for Business, HP Sure Start Gen7 |
Dimensions (WxDxH) | 17.7 cm x 17.5 cm x 3.4 cm |
Weight | 1.42 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Platform Technology | Intel vPro Platform |
|---|
Type | Personal computer |
|---|
Product Form Factor | Mini desktop |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Processor / Chipset
CPU | Intel Core i7 (12th Gen) 12700T |
|---|
Clock Speed | 1.4 GHz (P-core) / 1 GHz (E-core) |
|---|
Max Turbo Speed | 4.7 GHz (P-core) / 3.4 GHz (E-core) |
|---|
Number of Cores | 12-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
L2 cache | 12 MB |
|---|
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0 |
|---|
Chipset Type | Intel Q670 |
|---|
Cache Memory
Installed Size | L3 Cache – 25 MB |
|---|
Cache Per Processor | 25 MB |
|---|
RAM
Installed Size | 16 GB (installed) / 64 GB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 4800 MHz |
|---|
Rated Memory Speed | 4800 MHz |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 2 (Total) / 0 (empty) |
|---|
Configuration Features | 2 x 8 GB |
|---|
Hard Drive
Type | SSD – M.2 2280 |
|---|
Capacity | 1 x 256 GB |
|---|
Interface Type | PCI Express 4.0 x4 |
|---|
Features | NVM Express (NVMe), triple-level cell (TLC) |
|---|
Storage Controller
Type | 1 x SATA/NVMe |
|---|
Controller Interface Type | SATA-600 / NVMe |
|---|
Optical Storage
Monitor
Graphics Controller
Graphics Processor | Intel UHD Graphics 770 |
|---|
Video Interfaces | HDMI, DisplayPort |
|---|
HDCP Compatible | Yes |
|---|
Audio Output
Sound Output Mode | Stereo |
|---|
Max Sampling Rate | 192 kHz |
|---|
Compliant Standards | High Definition Audio |
|---|
Networking
Interface (Bus) Type | PCI Express Mini Card (M.2) |
|---|
Ethernet Controller | Intel I219-LM |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | Intel Wi-Fi 6E AX 211 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) |
|---|
Remote Management Protocol | SNMP 2 |
|---|
Features | Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2×2) |
|---|
Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.3az |
|---|
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x internal 2.5″ |
|---|
Slots | 1 (total) / 0 (free) x M.2 Card – 2230 (for wireless module)
2 (total) / 1 (free) x M.2 Card – 2280 (for internal storage) |
|---|
Interfaces | 1 x USB-C 3.2 Gen 2×2 (charging)
5 x USB 3.2 Gen 2 (2 front, 3 rear) (two of them with wake functionality, one of them is charging)
1 x headphones/microphone (CTIA and OMTP headset support)
2 x DisplayPort 1.4a
1 x HDMI (with adapter)
1 x LAN (Gigabit Ethernet)
2 x USB 2.0 |
|---|
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1 |
|---|
Power
Device Type | Power adapter |
|---|
Voltage Required | AC 100-240 V (50/60 Hz) |
|---|
Power Provided | 90 watt |
|---|
Efficiency | 89% (230VAC), 88% (115VAC) |
|---|
Power Factor Correction | Yes (active) |
|---|
Operating System / Software
OS Provided | Windows 10 IoT Enterprise |
|---|
Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP DriveLock, myHP, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Touchpoint Customizer, HP Easy Clean, HP Smart Support, HP Connect for Microsoft Endpoint Manager, HP SureRun Gen5, HP Sure Recover Gen5, HP Wolf Security for Business, HP Sure Start Gen7 |
|---|
Sustainability Information
Dimensions & Weight
Width | 17.7 cm |
|---|
Depth | 17.5 cm |
|---|
Height | 3.4 cm |
|---|
Weight | 1.42 kg |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 49.8 cm |
|---|
Shipping Depth | 13.2 cm |
|---|
Shipping Height | 23.5 cm |
|---|
Shipping Weight | 2.95 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 10 – 90% (non-condensing) |
|---|
