Description
The HPE ProLiant DL360 Gen11 server offers performance and flexibility for modern data centers. With support for up to 2 Intel Xeon Silver processors and 32 slots for DDR5 SDRAM memory, it ensures efficient data processing and enhanced multitasking capabilities. This server accommodates hot-swap drives, making it easy to manage storage without downtime. The 1U rack-mountable form factor allows for streamlined integration into existing systems, maximizing space utility.
Designed with operational efficiency in mind, the server includes an 80 PLUS Titanium certified power supply to reduce energy costs while maintaining high performance. Its compliance with various environmental standards highlights its commitment to energy efficiency, contributing to a more sustainable IT infrastructure. Additionally, features like remote management protocols and integrated security measures offer management options and data protection, ensuring a solid foundation for virtualized environments and demanding workloads.
- Supports up to 2 Intel Xeon Silver processors for efficient performance
- 32 DDR5 SDRAM memory slots for enhanced scalability
- Hot-swap bays allow for flexible storage management
- 80 PLUS Titanium certified power supply for reduced energy costs
- Integrated security with Trusted Platform Module (TPM 2.0)
- High-performance processing
Designed to support up to 2 Intel Xeon Silver processors, the HPE ProLiant DL360 Gen11 server delivers powerful performance suitable for various workloads. The inclusion of Intel Turbo Boost Technology optimizes processor speed to enhance efficiency. - Versatile memory options
Equipped with 32 slots for DDR5 SDRAM, this server accommodates significant memory, enabling superior data handling and efficient multitasking capabilities for data-intensive applications. - Efficient power management
Featuring an 80 PLUS Titanium certified power supply, the server operates with high energy efficiency, reducing operational costs while maintaining stability under load. - Flexible storage capabilities
The HPE ProLiant DL360 Gen11 includes multiple hot-swap bays that support SATA, SAS, and PCI Express interfaces, facilitating easy upgrades and maintenance without the need for downtime. - Robust remote management
The server comes with various remote management protocols, including SNMP 3 and IPMI 2.0, allowing for effective system monitoring and management, enhancing operational oversight.
Main Specifications
Product Description | HPE ProLiant DL360 Gen11 – rack-mountable Xeon Silver 4514Y 2 GHz – 64 GB – SSD 2 x 480 GB |
Type | Server – rack-mountable |
Height (Rack Units) | 1U |
Server Scalability | 2-way |
Processor | 1 x Intel Xeon Silver 4514Y / 2 GHz (up to 3.4 GHz, (16-core) |
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology |
Cache Memory | 30 MB L3 Cache |
Cache Per Processor | 30 MB |
RAM | 64 GB (installed) / 8 TB (max) – DDR5 SDRAM |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) – OCP (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 2 x SSD 480 GB |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Power Redundancy | Yes |
OS Provided | No operating system |
Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Server UEFI |
Dimensions (WxDxH) | 43.46 cm x 75.31 cm x 4.29 cm |
Weight | 14.56 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 1U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 2-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon Silver 4514Y |
|---|
Clock Speed | 2 GHz |
|---|
Max Turbo Speed | 3.4 GHz |
|---|
Number of Cores | 16-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 2 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology |
|---|
Chipset Type | Intel C741 |
|---|
Cache Memory
Installed Size | L3 Cache – 30 MB |
|---|
Cache Per Processor | 30 MB |
|---|
RAM
Installed Size | 64 GB (installed) / 8 TB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 32 (Total) / 30 (empty) |
|---|
Features | HPE SmartMemory, registered, slots 17 – 32 are available in two-processor configuration only |
|---|
Configuration Features | 2 x 32 GB |
|---|
Hard Drive
Type | SSD |
|---|
Capacity | 2 x 480 GB |
|---|
Storage Controller
Type | 1 x RAID – OCP |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Expansion / Connectivity
Bays | 8 hot-swap 2.5″ SFF |
|---|
Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 (full-height)
1 (total) / 1 (free) x PCIe 5.0 x16 (low-profile)
1 (total) / 0 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0
1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (2 processors must be installed)
1 (total) / 1 (free) x PCIe 5.0 x16 (2 processors must be installed) |
|---|
Interfaces | 1 x HPE iLO – Type A (1 in front)
1 x HPE iLO – RJ-45
4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal)
1 x VGA
1 x USB 2.0 |
|---|
Miscellaneous
Compliant Standards | ASHRAE Class A3, ASHRAE Class A4, TLS v1.2, AES, FIPS 140-2, IPv6 Ready, PCI DSS, WEEE 2002/95/EC, ACPI 6.4, Active Directory v1.0, Redfish API, SMBIOS 3.4, Triple DES |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-240 V |
|---|
Power Provided | 800 Watt |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
OS Certified | Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware vSphere 7.0 (ESXi) Update 3, VMware vSphere 8.0 (ESXi) Update 1, VMware vSphere 8.0 (ESXi) Update 2, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP5 QU1, SUSE Linux Enterprise Micro 5.5, Canonical Ubuntu 20.04.5 LTS, Canonical Ubuntu 22.04 LTS, Oracle Linux 9 |
|---|
Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Server UEFI |
|---|
Sustainability Information
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 43.46 cm |
|---|
Depth | 75.31 cm |
|---|
Height | 4.29 cm |
|---|
Weight | 14.56 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
