TP-Link Omada SX6632YF V1, Switch, L3, Managed, 26 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit / 25 Gigabit SFP28, front to back airflow, rack-mountable
$8,126.42 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
Ships from: Auckland, Wellington, or Christchurch
- Allow 1–2 days for delivery
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The TP-Link Omada SX6632YF V1 is a high-capacity, rack-mountable switch designed to meet the demands of modern network environments. With its 26 1/10GBase-X SFP+ ports and 6 10/25GBase-X SFP28 ports, this switch offers extensive connectivity options for both 1 Gigabit and 10/25 Gigabit Ethernet, making it an ideal solution for businesses looking to upgrade their network infrastructure for improved speed and reliability. Engineered for performance, the SX6632YF V1 has a switching capacity of 820 Gbps and a forwarding bandwidth of 410 Gbps, ensuring efficient data transfer across the network. It supports advanced Layer 3 switching, providing robust tools for managing network traffic and optimizing performance. Security is a priority, with features like RADIUS, SSH, and SSL/TLS encryption safeguarding network data against unauthorized access. In addition to its performance and security features, the TP-Link Omada SX6632YF V1 is designed for durability and ease of management. It operates reliably in a wide range of environmental conditions, thanks to its comprehensive environmental parameters. With support for various remote management protocols, network administrators can easily monitor and manage the network, ensuring smooth operation and minimal downtime.
- 26 1/10GBase-X SFP+ and 6 10/25GBase-X SFP28 ports for flexible network configurations
- 820 Gbps switching capacity and 410 Gbps forwarding bandwidth for high-speed data processing
- Supports advanced Layer 3 switching for efficient network traffic management
- Robust security protocols including RADIUS, SSH, and SSL/TLS encryption
- Energy-efficient design with EEE and redundant power supply options
- Advanced connectivity
With 26 1/10GBase-X SFP+ ports and 6 10/25GBase-X SFP28 ports, this switch offers versatile connectivity options for a wide range of network demands, ensuring high-speed data transfer and efficient network operations. - Robust security features
Equipped with RADIUS, SSH, TACACS+, and support for SSL 3.0 and TLS 1.2, the TP-Link Omada SX6632YF V1 provides multiple layers of security to protect network integrity and prevent unauthorized access. - High performance
Featuring a switching capacity of 820 Gbps and a forwarding bandwidth of 410 Gbps, this switch is designed to handle substantial data traffic, ensuring smooth and reliable network performance even under heavy loads. - Comprehensive network management
Support for various remote management protocols, including SNMP, RMON, and HTTP/S, allows for efficient network monitoring and management, facilitating easy configuration and maintenance of the network infrastructure. - Environmental resilience
Designed to operate in a wide range of temperatures and humidity levels, with front to back airflow ensuring optimal cooling, the TP-Link Omada SX6632YF V1 is built to maintain performance stability in diverse environmental conditions.
What’s in the Box
- TP-Link Omada SX6632YF V1
- Rubber feet
- Rack mounting kit
Main Specifications
Product Description | TP-Link Omada SX6632YF V1 – switch – 26 ports – Managed – rack-mountable |
Device Type | Switch – 26 ports – L3 – Managed – stackable |
Enclosure Type | Front to back airflow rack-mountable |
Subtype | 10 Gigabit Ethernet |
Ports | 26 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit / 25 Gigabit SFP28 |
Performance | Switching capacity: 820 Gbps Forwarding bandwidth: 410 Gbps Stacking bandwidth: 300 Gbps Packet forwarding rate: 610.1 Mpps Packet buffer size: 8 MB |
Capacity | Priority queues: 8 IPv6 interfaces: 256 IPv4 interfaces: 256 IPv4 routes (static): 2048 IPv6 routes (static): 1024 Maximum host route table: 15300 RIP routes: 102400 OSPFv2 routes: 102400 OSPFv3 routes: 51200 VRRP groups: 64 ECMP entries: 256 ECMP next hops per route: 32 Static ARP entries: 1024 Dynamic ARP: 24576 Dynamic IP pool: 8000 Binding entries: 1000 LAG groups: 120 Multiple Spanning Tree Protocol instances: 64 IGMP groups: 4093 ERPS rings: 64 IP multicast entries: 4093 Multicast VLANs: 4093 Layer 2 multicast filtering profiles: 256 Layer 2 multicast filtering entries per profile: 16 IPv4 routes (Multicast): 1024 VLAN groups: 4000 MAC VLAN address entries: 200 VLAN VPN (QinQ) entries: 256 VLAN templates: 16 VLAN entries: 12 IP MAC port binding entries: 1024 IPv6 MAC port binding entries: 1024 Port security entries: 64 |
MAC Address Table Size | 128K entries |
Jumbo Frame Support | 9KB |
Routing Protocol | Static IP routing, RIP, OSPF, ECMP, VRRP, PIM-DM, RIP-1, RIP-2, RIPng, OSPFv2, OSPFv3, IGMP, IGMPv2, IGMPv3, STP, MLD, L2PT, VRRPv2, VRRPv3, PPPoE, RSTP, MSTP, MLDv2 |
Remote Management Protocol | DHCP, CLI, RMON, SSH, Telnet, SNMP, SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, BOOTP, TFTP, ICMP, NTP, MIB, HTTP, HTTPS, RSTP, IPv4, IPv6, TCP/IP, UDP, SSH-2, RADIUS |
Features | DHCP server, DHCP relay, ACL support, Port Security, DoS attack prevention, 802.1x authentication, VRRP support, ERPS, cloud managed, 4 fans, security lock slot (cable lock sold separately), CoS, port-based priority, DSCP prioritisation, scheduler, bandwidth control, rate limit, Voice VLAN, ARP support, DHCPv6 relay, DHCP snooping, DHCPv6 snooping, SPAN, RSPAN, port mirroring, loopback detection, trunking, LAG, BPDU protection, BPDU Filter, IGMP snooping, MLD snooping, MVR, fast leave, multicast mode, Multicast filtering function, Automatic Device Recognition, firmware upgradable, network monitoring, schedule reboot, DLDP support, DDM, sFlow, VLAN Tagging, VLAN support, VPN support, Private VLAN, GARP, GVRP, port isolation, cpu defend policy, IP-MAC binding, ARP inspection, IP source guard, NDP, ND snooping, DoS protection, AAA, ZTP, LLDP-MED, Cable Diagnostics Function, SNTP support, system log, store and forward, 15KV ESD Protector (air-gap discharge), 6KV Surge protection, 8KV ESD Protector (contact discharge), VCT technology, Broadcast Storm Control, Multicast Storm Control, Unknown Storm Control, Guest VLAN, MAB, QoS, DSCP support, RSPAN, proxy ARP, flow control, EEE |
Compliant Standards | IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ah, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1ab (LLDP) |
Power | AC 100-240 V (50/60 Hz) |
Power Redundancy | Yes |
Dimensions (WxDxH) | 44 cm x 38 cm x 4.4 cm |
System Requirements | Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/8.1/10/11, Apple MacOS, Novell NetWare, UNIX, Linux |
Extended Specifications
General
Device Type | Switch – 26 ports – L3 – Managed – stackable |
|---|---|
Enclosure Type | Front to back airflow rack-mountable |
Subtype | 10 Gigabit Ethernet |
Ports | 26 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit / 25 Gigabit SFP28 |
Performance | Switching capacity: 820 Gbps Forwarding bandwidth: 410 Gbps Stacking bandwidth: 300 Gbps Packet forwarding rate: 610.1 Mpps Packet buffer size: 8 MB |
Capacity | Priority queues: 8 IPv6 interfaces: 256 IPv4 interfaces: 256 IPv4 routes (static): 2048 IPv6 routes (static): 1024 Maximum host route table: 15300 RIP routes: 102400 OSPFv2 routes: 102400 OSPFv3 routes: 51200 VRRP groups: 64 ECMP entries: 256 ECMP next hops per route: 32 Static ARP entries: 1024 Dynamic ARP: 24576 Dynamic IP pool: 8000 Binding entries: 1000 LAG groups: 120 Multiple Spanning Tree Protocol instances: 64 IGMP groups: 4093 ERPS rings: 64 IP multicast entries: 4093 Multicast VLANs: 4093 Layer 2 multicast filtering profiles: 256 Layer 2 multicast filtering entries per profile: 16 IPv4 routes (Multicast): 1024 VLAN groups: 4000 MAC VLAN address entries: 200 VLAN VPN (QinQ) entries: 256 VLAN templates: 16 VLAN entries: 12 IP MAC port binding entries: 1024 IPv6 MAC port binding entries: 1024 Port security entries: 64 |
MAC Address Table Size | 128K entries |
Jumbo Frame Support | 9KB |
Max Units In A Stack | 8 |
Routing Protocol | Static IP routing, RIP, OSPF, ECMP, VRRP, PIM-DM, RIP-1, RIP-2, RIPng, OSPFv2, OSPFv3, IGMP, IGMPv2, IGMPv3, STP, MLD, L2PT, VRRPv2, VRRPv3, PPPoE, RSTP, MSTP, MLDv2 |
Remote Management Protocol | DHCP, CLI, RMON, SSH, Telnet, SNMP, SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, BOOTP, TFTP, ICMP, NTP, MIB, HTTP, HTTPS, RSTP, IPv4, IPv6, TCP/IP, UDP, SSH-2, RADIUS |
Encryption Algorithm | SSL 3.0, TLS 1.2 |
Authentication Method | RADIUS, TACACS+, Secure Shell (SSH), Secure Shell v.2 (SSH2) |
Features | DHCP server, DHCP relay, ACL support, Port Security, DoS attack prevention, 802.1x authentication, VRRP support, ERPS, cloud managed, 4 fans, security lock slot (cable lock sold separately), CoS, port-based priority, DSCP prioritisation, scheduler, bandwidth control, rate limit, Voice VLAN, ARP support, DHCPv6 relay, DHCP snooping, DHCPv6 snooping, SPAN, RSPAN, port mirroring, loopback detection, trunking, LAG, BPDU protection, BPDU Filter, IGMP snooping, MLD snooping, MVR, fast leave, multicast mode, Multicast filtering function, Automatic Device Recognition, firmware upgradable, network monitoring, schedule reboot, DLDP support, DDM, sFlow, VLAN Tagging, VLAN support, VPN support, Private VLAN, GARP, GVRP, port isolation, cpu defend policy, IP-MAC binding, ARP inspection, IP source guard, NDP, ND snooping, DoS protection, AAA, ZTP, LLDP-MED, Cable Diagnostics Function, SNTP support, system log, store and forward, 15KV ESD Protector (air-gap discharge), 6KV Surge protection, 8KV ESD Protector (contact discharge), VCT technology, Broadcast Storm Control, Multicast Storm Control, Unknown Storm Control, Guest VLAN, MAB, QoS, DSCP support, RSPAN, proxy ARP, flow control, EEE |
Compliant Standards | IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ah, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1ab (LLDP) |
Processor | : 1.2 GHz |
RAM | 8 GB DDR4 SDRAM |
Flash Memory | 8 GB |
Expansion / Connectivity
Interfaces | 26 x 1/10GBase-X SFP+ 6 x 10/25GBase-X SFP28 2 x USB 3.0 Type A 1 x console RJ-45 1 x management RJ-45 1 x USB-C console |
|---|
Power
Power Device | Internal power supply – hot-plug |
|---|---|
Installed Qty | 1 |
Max Supported Qty | 2 |
Power Redundancy | Yes |
Voltage Required | AC 100-240 V (50/60 Hz) |
Power Consumption Stand by | 31.4 watt |
Miscellaneous
Included Accessories | Rubber feet |
|---|---|
Rack Mounting Kit | Included |
MTBF | 724,732 hours |
Compliant Standards | FCC, RoHS |
Software / System Requirements
OS Required | Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/8.1/10/11, Apple MacOS, Novell NetWare, UNIX, Linux |
|---|
Dimensions & Weight
Width | 44 cm |
|---|---|
Depth | 38 cm |
Height | 4.4 cm |
Environmental Parameters
Min Operating Temperature | -5 °C |
|---|---|
Max Operating Temperature | 50 °C |
Humidity Range Operating | 10 – 90% RH (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 70 °C |
Humidity Range Storage | 5 – 90% RH (non-condensing) |
