LG 86BH5F, 86" Diagonal Class LED-backlit LCD display, digital signage, webOS 3840 x 600, black
$6,519.03 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
We are currently experiencing 1-2 day shipping delays from this supplier warehouse
Description
The LG 86BH5F offers an extraordinary viewing experience. It is a unique wide screen with 58:9 bar type which provides much more flexibility in playing content than the conventional display of 32:9 ratio.
- Ultra HD resolution
- Effective content delivery
- Immersive view
- Dustproof design
- Powerful SoC
- Ultra HD resolution
Ultra HD resolution delivers an immersive viewing experience with vivid colors and clear images. - Effective content delivery
It is very useful and convenient to deliver various advertisements or pieces of information at the same time without calibration. - Immersive view
The 86BH5F can show a tiled scene. This will be the best choice if you want to use a large screen, or provide visual impact to your customers in a different way. - Dustproof design
Ensures that the product is completely protected from dust, eliminating the risk of performance degradation. - Powerful SoC
Built-in SoC can execute several tasks at once while providing smooth content playback without the need for a media player.
Main Specifications
Product Description | LG 86BH5F 86″ LED-backlit LCD display – for digital signage |
Product Type | LED-backlit LCD flat panel display |
Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/359384 |
Diagonal Class | 86″ |
Commercial Use | Yes – digital signage |
Colour | Black |
Platform | webOS |
Resolution | 3840 x 600 |
Max Number of Screens | 225 |
Video Interface | HDMI |
HDMI Ports Qty | 3 ports |
Connectivity | Wi-Fi, LAN |
PC Interface | DVI, DisplayPort |
Technology | IPS |
LCD Backlight Technology | LED backlight |
Image Aspect Ratio | 58:9 |
TV Tuner | No tuner |
Commercial Features | Local Contents Scheduling, Sync Mode, SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign Control compatible, Real Time Communication (webRTC), FailOver |
Settings Cloning Capability | Yes |
Storage Drive Capacity | 8 GB |
Storage Capacity | 8 GB |
USB | Yes |
Included Accessories | Remote control, infrared / light sensor receiver |
Voltage | AC 120/230 V (50/60 Hz) |
Energy Class | Class G |
Power Consumption Operational | 240 Watt |
Power Consumption (On mode) | 142.6 W |
Power Consumption Stand by | 0.5 Watt |
Energy Consumption per Year | 208 kWh |
Dimensions (WxDxH) – without stand | 215.83 cm x 8.17 cm x 34.85 cm |
Weight | 20.5 kg |
Documents
Extended Specifications
General
Product Type | LED-backlit LCD flat panel display |
|---|---|
Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/359384 |
Energy Class | Class G |
Power Consumption Operational | 240 Watt |
Power Consumption (On mode) | 142.6 W |
Power Consumption SDR (On mode) | 142.6 kWh/1000h |
Energy Consumption per Year | 208 kWh |
Diagonal Class | 86″ |
Commercial Use | Yes – digital signage |
Platform | webOS |
Video Processor | Quad-Core |
TV Tuner | No tuner |
TV Tuner Presence | No |
Sensors | Temperature sensor, auto brightness sensor |
Video Interface | HDMI |
HDMI Ports Qty | 3 ports |
PC Interface | DVI, DisplayPort |
Modes | Portrait mode, landscape mode, Tile Mode |
Protection | Dustproof |
Dimensions | Without stand |
Width | 215.83 cm |
Depth | 8.17 cm |
Height | 34.85 cm |
Weight | 20.5 kg |
Enclosure Colour | Black |
Display
LCD Display Technology | IPS |
|---|---|
Resolution | 3840 x 600 |
Image Aspect Ratio | 58:9 |
LCD Backlight Technology | LED backlight |
Image Contrast Ratio | 1100:1 |
Brightness | 500 cd/m² |
Viewing Angle | 178 degrees |
Viewing Angle (Vertical) | 178 degrees |
Response Time | 8 ms |
Backlight Life | 50,000 hour(s) |
Commercial Features | Local Contents Scheduling, Sync Mode, SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign Control compatible, Real Time Communication (webRTC), FailOver |
Settings Cloning Capability | Yes |
Operation Hours / Days | 24 / 7 |
Features | Crestron Connected Compatible, Daisy Chain, picture by picture (no tuner) |
Video Wall
Max Number of Screens | 225 |
|---|
Stands & Mounts
Flat Panel Mount Interface | 600 x 200 mm |
|---|---|
VESA Compatibility | Yes |
Media Player
USB Port | Yes |
|---|---|
USB Ports Qty | 1 |
Configuration | 8 GB |
Storage Drive Capacity | 8 GB |
Remote Control
Type | Remote control |
|---|
Network & Internet Multimedia
Connectivity | Wi-Fi, LAN |
|---|
Connections
Connector Type | Audio line-in Audio line-out DisplayPort output DisplayPort input DVI-D input 3 x HDMI input Infrared (IrDA) USB 2.0 RS-232C input RS-232C output 2 x LAN |
|---|
Miscellaneous
Included Accessories | Infrared / light sensor receiver |
|---|---|
Cables Included | DisplayPort cable Serial cable |
Compliant Standards | Plug and Play, FCC Class A certified, CB, EMC, KC, NRTL, IP5X |
Power
Power Device | Power supply |
|---|---|
Input Voltage | AC 120/230 V (50/60 Hz) |
Power Consumption Stand by | 0.5 Watt |
Features | Smart energy saving, WOL (Wake on LAN) |
Dimensions & Weight (Shipping)
Width (Shipping) | 229 cm |
|---|---|
Depth (Shipping) | 22.8 cm |
Height (Shipping) | 59.9 cm |
Weight (Shipping) | 38.2 kg |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 – 80% |
