APC Easy UPS On-Line, UPS (rack-mountable), extended runtime, AC 220/230/240 V, 1800 Watt, 2000 VA, 1-phase, Lead Acid, USB, serial, output connectors: 4, 4U, Europe, black, RAL 7010
$1,689.00 inc GST
✓ In Stock - 2 available
✓ Free NZ Delivery
2 in stock
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 2000VA double-conversion on-line 4U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRV comes with IEC 320 C20 input and 4x IEC 320 C13 outlets. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The UPS and the built-in lead-acid battery has a 2-year warranty. Ideal for small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunication, and healthcare IT.
- 2000VA/1800W double-conversion on-line pure sine wave 4U rackmount UPS
- High operating efficiency in energy-saving ECO mode
- Add up to 4 external battery packs (SRV72RLBP-9A) for extended runtime
- Easy-to-read LCD interface for detailed and accurate information on UPS status
- Intelligent Card Slot
Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS.
Main Specifications
Product Description | APC Easy UPS On-Line – UPS – extended runtime – 1800 watt – 2000 VA – Lead Acid |
Device Type | UPS – rack-mountable |
Rack Size | 4U |
Weight | 51.4 kg |
Input Wiring | 1-phase |
Input Voltage | AC 220/230/240 V |
Output Voltage | AC 220/230/240 V |
Power Capacity | 1800 watt / 2000 VA |
Input Connectors | 1 x power IEC 60320 C20 |
Output connectors | 4 x power IEC 60320 C13 |
Battery | Lead Acid |
Run Time (Up To) | 26 min at full load |
Networking | USB, serial |
Included Accessories | Rail kit, battery pack |
Colour | Black, RAL 7010 |
Dimensions (WxDxH) | 43.7 cm x 63.2 cm x 17.2 cm |
Documents
Extended Specifications
General
Device Type | UPS – rack-mountable |
|---|---|
Height (Rack Units) | 4U |
Colour | Black, RAL 7010 |
Power Device
UPS Technology | On-line |
|---|---|
Input Voltage | AC 220/230/240 V |
Input Voltage Range | AC 105 – 300 V |
Frequency Provided | 50/60 Hz ± 3Hz |
Input Wiring | 1-phase |
Frequency Required | 40 – 70 Hz |
Input Connectors | 1 x power IEC 60320 C20 |
Power Output Connectors Details | 4 x power IEC 60320 C13 |
Output Voltage | AC 220/230/240 V 50/60 Hz |
Power Capacity | 1800 watt / 2000 VA |
Output Waveform | Sinewave |
Surge Suppression | Yes |
Surge Energy Rating | 600 joules |
Circuit Protection | Circuit breaker |
Efficiency | 88% at 100% Load, 94% Eco mode |
Total Harmonic Distortion (THD) | 3 % |
Battery
Technology | Lead Acid |
|---|---|
Voltage Provided | 72 V |
Run Time (Up To) | 21.55 min at 1800 Watts |
Recharge Time | 5.5 hours |
Features | Maintenance free, sealed, leak-proof |
Networking
Remote Management Interface | USB, serial |
|---|
Expansion / Connectivity
Interfaces | USB Serial |
|---|---|
Expansion Slots | Intelligent Slot |
Miscellaneous
Included Accessories | Rail kit, battery pack |
|---|---|
Cables Included | Power cable 1.5 m USB cable – external Serial cable – external Power cable (C13-C19) – external Power cable (C19) – external Battery cable – external |
Rack Mounting Kit | Included |
Features | Horizontal orientation, audible alarm, emergency power off, LCD display, internal bypass, cold-start function, Eco-Mode, generator compatible, Intelligent Battery Management, double conversion, low battery alarm, overload alarm |
Compliant Standards | WEEE, REACH, IP20, China RoHS, TISI, EN 62040-2:2006+AC:2006, EU RoHS, Mercury-free, UKCA, EN/IEC 62040-2:2018, EN IEC 62040-1:2019 + A11:2021 |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Humidity Range Operating | 0 – 95% RH (non-condensing) |
Sound Emission | 53 dBA |
Dimensions & Weight
Width | 43.7 cm |
|---|---|
Depth | 63.2 cm |
Height | 17.2 cm |
Weight | 51.4 kg |
Dimensions & Weight (Shipping)
Shipping Width | 60 cm |
|---|---|
Shipping Depth | 70 cm |
Shipping Height | 48 cm |
Shipping Weight | 66.2 kg |
