Description
The UniFi Video Camera is designed for use indoors or outdoors under an overhang. The camera has infrared LEDs with automatic IR cut filter. Accessible from a web browser, the UniFi video interface was designed to be easy to use yet packed with advanced features. The UniFi video interface is incredibly intuitive and loaded with powerful features such as detailed statistical reporting, multiple views, versatile camera settings, advanced analytics, and customizable event recordings.
- Scalable day or night surveillance
- Advanced hardware with Full HD video
- Powerful features and analytic capabilities
- Feature-packed user interface
Accessible from a web browser, the UniFi video interface was designed to be easy to use yet packed with advanced features. The UniFi video interface is incredibly intuitive and loaded with powerful features such as detailed statistical reporting, multiple views, versatile camera settings, advanced analytics, and customizable event recordings. - Camera-based motion detection
The UniFi video cameras handle motion detection instead of the server, relieving the workload on the server and ensuring that compression and noise won’t affect motion detection. Additional live views playlists can be created with a configurable live camera feed rotation. Define the cameras you want included in the playlist and how long you want them to appear on the screen before moving on to the next live feed. - Additional live views playlists
Additional live views playlists can be created with a configurable live camera feed rotation. Define the cameras you want included in the playlist and how long you want them to appear on the screen before moving on to the next live feed. - Disk management features
UniFi video has automatic recording management to free up disk space. User-definable disk space and date-based auto purge allow users to keep a set amount of free disk space or automatically delete recordings after a certain number of days. Another storage feature is the ability to map external USB or network storage drives.
What’s in the Box
- Ubiquiti UniFi AI Dome
- Network cable – 30 cm
- Mounting hardware
Main Specifications
Product Description | Ubiquiti UniFi AI Dome – network surveillance camera – dome |
Device Type | Network surveillance camera – fixed – dome – outdoor – vandal / weatherproof |
Audio | Yes: built-in microphone |
Camera Mount Type | Ceiling mount, wall mount, pendant mount |
Dimensions (WxDxH) | 11.8 cm x 11.8 cm x 9.08 cm |
Weight | 700 g |
Colour | Black |
Connectivity Technology | Wired |
Camera | Colour – Day&Night |
Max Resolution | 3840 x 2160 |
Frame Rate (max) | 30 frames per second |
Video Modes | 4K |
Optical Sensor Type | 1/1.8″ – 8 MP |
Focal Length Control | Fixed focal |
Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
Cables Included | 1 – network cable – integrated – 30 cm |
Voltage | DC 42.5 – 57 V, PoE |
Features | Face Recognition, License Plate Recognition, Smart Detection, IR-cut filter, aluminum alloy/polycarbonate housing, reset button, sharpness control, brightness control, contrast control, white balance, colour control, exposure control, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), noise reduction by motion, masking, text overlay, HDR, 16:9 aspect ratio |
Environmental Parameters (operating) | -30 °C – 50 °C; 0 – 90% (non-condensing) relative humidity |
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: built-in microphone |
|---|
Form Factor | Dome |
|---|
Camera Mount Type | Ceiling mount, wall mount, pendant mount |
|---|
Connectivity Technology | Wired |
|---|
Width | 11.8 cm |
|---|
Depth | 11.8 cm |
|---|
Height | 9.08 cm |
|---|
Weight | 700 g |
|---|
Camera
Type | Colour – Day&Night – fixed – outdoor – vandal / weatherproof |
|---|
Max Digital Video Resolution | 3840 x 2160 |
|---|
Video Modes | 4K |
|---|
Infrared LEDs | Yes |
|---|
Infrared Distance | 40 m |
|---|
Digital Video Capture Resolution | 3840 x 2160 |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Features | Face Recognition, License Plate Recognition, Smart Detection, IR-cut filter, aluminum alloy/polycarbonate housing, reset button, sharpness control, brightness control, contrast control, white balance, colour control, exposure control, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), noise reduction by motion, masking, text overlay, HDR, 16:9 aspect ratio |
|---|
Image Sensor
Lens Construction
Type | Fixed focal |
|---|
Horizontal Field of View (degree) | 109.9 |
|---|
Vertical Field of View (degree) | 56.7 |
|---|
Diagonal Field of View (degree) | 134.1 |
|---|
Interfaces
Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
|---|
Expansion / Connectivity
Ports | LAN/power – RJ-45 |
|---|
Supported Memory Cards | microSD Card |
|---|
Miscellaneous
Included Accessories | Mounting hardware |
|---|
Cables Included | 1 x network cable – integrated – 30 cm |
|---|
Compliant Standards | IP66, IK10, FCC, IC |
|---|
Colour | Black |
|---|
Power
Power Requirements | PoE |
|---|
Power Device | DC 42.5 – 57 V |
|---|
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|
Max Operating Temperature | 50 °C |
|---|
Relative Humidity (operating) | 0 – 90% (non-condensing) |
|---|
