Onkyo TX-NR7100, AV network receiver, 8K, 60 fps, HDR, 9.2 channel, black
$2,063.97 inc GST
✓ In Stock - 9 available
✓ Free NZ Delivery
9 in stock
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Onkyo TX-NR7100 9.2-channel THX-certified AV receiver brings advanced meaning to the phrase, “home movie night.” The DIRAC Live Room Correction offers improved musical staging, clarity, dialog, and deeper bass, while the additional two channels create a 5.1.4 Dolby Atmos immersive surround sound experience. Featuring three HDMI-out options, the TX-NR7100 AV receiver delivers uncompressed HDMI 8K/4K transfer at 40Gbps. Put through thousands of tests to obtain the coveted THX Certification, this smart AV receiver delivers an unparalleled movie, music, and gaming experience to your home.
- DIRAC Live Room Correction
- Discrete zone 2 HDMI switching
- IMAX enhanced
- Enhanced gaming
- THX-certified select theater-reference sound
- Voice control
- Stereo height channel flexibility
- DIRAC Live Room Correction
Built-in, state-of-the-art digital room correcting technology improves overall audio performance. Dirac Live automatically calibrates sound in your room using smartphone app and included microphone or the Dirac Live desktop or laptop application. Dirac Live unlocks your loudspeakers’ full potential in any listening space and delivers a uniquely pristine listening experience. - Discrete Zone 2 HDMI switching
Set up different high-definition entertainment options with advanced resolution. - IMAX-enhanced
Bring larger-than-life home. Using DTS: X technology, IMAX mode delivers lMAX-enhanced content as the filmmakers intended. IMAX-enhanced films are available to stream or own on Ultra HD Blu-ray. - Enhanced gaming
Own your opponents with HDMI 2.1 enhancements for gamers: 4K/120Hz HDR pass-through enables ultra-fast motion -VRR eliminates lag, stutter, and frame-tearing for fluid gameplay. - THX-certified select theater-reference sound
Guarantees the same reference volume of a commercial theater in rooms where the screen-to-seat distance is about 12ft. - Voice control
Work with your digital assistant in any room with easy Google and Amazon Alexa smart home ecosystem integrations. - Stereo height channel flexibility
Set the mood for your next gathering by using height or surround speakers to ensure sound is distributed evenly throughout the room. By being able to move the stereo sound to height speakers, it blankets the space more evenly, giving everyone a better experience.
Main Specifications
Product Description | Onkyo TX-NR7100 – AV network receiver – 9.2 channel |
Product Type | AV network receiver |
Enclosure Colour | Black |
Resolution | 8K – 60 fps – HDR |
Audio Channels | Surround Sound |
Audio Specifications | Amplifier – 10 – 100000 Hz – 106 dB 0.08% |
Decoders | DTS-ES decoder, DTS 96/24, DTS decoder, DTS Express, Dolby TrueHD, DTS-HD Master Audio, DTS-HD High Resolution, aptX, Dolby Atmos, DTS:X, Dolby Audio, DTS Neural:X, DTS Virtual:X, aptX HD |
THX certified | Yes |
HDMI Switching | Yes |
Surround Sound Effects | 3D Surround, Theatre-Dimensional Virtual Surround, Dolby Atmos Height Virtualisation Technology |
Sound Effects | DoubleBass |
Surround System Class | 9.2 channel |
Source | Network, USB-host, Bluetooth |
Audio Formats | WAV, WMA, AAC, AIFF, MP3, FLAC, Apple Lossless, LPCM, DSD, ALAC |
Radio System | AM/FM – 40 preset stations |
Built-in Phono Preamplifier | Yes |
Platform | Roon, Sonos |
Intelligent Assistant | Siri, Google Assistant, Alexa – indirect |
Streaming Services | Pandora, Deezer, Spotify, TuneIn, TIDAL, Chromecast, Amazon Music |
Interfaces | Ethernet, Fast Ethernet, Wi-Fi, Bluetooth |
Display | Fluorescent display |
Power | AC 120 V (60 Hz) |
Dimensions (WxDxH) | 43.5 cm x 37.95 cm x 17.35 cm |
Weight | 10.4 kg |
Extended Specifications
General
Product Type | AV network receiver |
|---|---|
Enclosure Colour | Black |
Resolution | 8K – 60 fps |
HDR Capable | Yes |
HDR Technology | Dolby Vision, Hybrid Log-Gamma (HLG), HDR10+ |
Audio System
Audio Channels | Surround Sound |
|---|---|
Decoders | DTS-ES decoder, DTS 96/24, DTS decoder, DTS Express, Dolby TrueHD, DTS-HD Master Audio, DTS-HD High Resolution, aptX, Dolby Atmos, DTS:X, Dolby Audio, DTS Neural:X, DTS Virtual:X, aptX HD |
3D Technology | Yes |
Functions | Digital player, AV network receiver, network audio player |
Built-in Phono Preamplifier | Yes |
Source | Network, USB-host, Bluetooth |
Audio Formats | WAV, WMA, AAC, AIFF, MP3, FLAC, Apple Lossless, LPCM, DSD, ALAC |
Audio D/A Converter | 24bit / 192kHz |
Bluetooth Audio Codec | SBC, AAC, aptX, aptX HD |
THX certified | Yes |
High-Resolution Audio | Yes |
Surround Sound Effects | 3D Surround, Theatre-Dimensional Virtual Surround, Dolby Atmos Height Virtualisation Technology |
Sound Effects | DoubleBass |
Multiroom | Yes |
Digital Sound Processor (DSP) | Yes |
DSP Presets | Movie, Game, Music |
Virtual Surround Sound Modes | Virtual Surround Back |
Surround System Class | 9.2 channel |
Audio Specifications | Amplifier – Response Bandwidth – 10 – 100000 Hz – SNR – 106 dB – THD – 0.08% |
Input Impedance | 47 kOhm |
Input Sensitivity | 200 mV |
Amplifier Output details | 220 Watt – 6 Ohm – at 1 kHz – THD 10% – 1 channels 100 Watt – 8 Ohm – 20 – 20000 kHz – THD 0.08% – 2 channels |
Built-in clock | Sleep timer |
Bass Control | Yes |
Treble Control | Yes |
Tone Control | Yes |
Digital Content Protection | HDCP 2.3 |
Features | Source direct, three-zone capability, Bluetooth Audio Streaming, PureAudio, smartphone remote controlled, rack mountable, x.v.Color, Deep Colour, AccuEQ room acoustic calibration, BT.2020 Support, Dirac Live room correction, Enhanced Audio Return Channel (eARC), IMAX Enhanced, Apple AirPlay 2 support, variable refresh rate (VRR), quick frame transport (QFT), auto low latency mode (ALLM), display stream compression (DSC), quick media switching (QMS), Lipsync, Klipsch Optimize Mode |
Signal Processing Features
HDMI Switching | Yes |
|---|---|
HDMI Pass-Through | Up to 8K |
Upscaling via HDMI | Up to 8K |
Radio System
Type | AM/FM – digital radio tuner |
|---|---|
Tuner Frequency Range | FM: 87.5 – 107.9 MHz, AM: 530 – 1710 kHz |
Tuning Display | Fluorescent display |
Preset Station Qty | 40 preset stations |
Aerial Form Factor | Loop AM / wire FM |
Auto Preset Memory | Yes |
Network & Internet Multimedia
Interfaces | Ethernet, Fast Ethernet, Wi-Fi, Bluetooth |
|---|---|
Streaming Services | Pandora, Deezer, Spotify, TuneIn, TIDAL, Chromecast, Amazon Music |
AirPlay | Yes |
Play-Fi | Yes |
Display
Display Type | Fluorescent display |
|---|
Remote Control
Battery Form Factor | AAA type |
|---|---|
Battery Included Qty | 2 |
Battery Required Qty | 2 |
Connections
Connectors | Headphones (phone stereo 6.3 mm) – front Microphone (mini-phone stereo 3.5 mm) – front AUX input (mini-phone stereo 3.5 mm) – front HDMI input (19 pin HDMI Type A) – front Digital audio input (coaxial) (RCA) – rear Digital audio input (optical) (TOS Link) – rear Tuner – rear Component video input (RCA x 3) – rear 2 x composite video input (RCA) – rear 2 x HDMI output (19 pin HDMI Type A) – rear 6 x HDMI input (19 pin HDMI Type A) – rear RS-232 (9 PIN D-Sub) – rear Infrared input – rear Network (RJ-45) – rear USB (4 PIN USB Type A) – rear 6 x audio line-in (RCA x 2) – rear Phono input (RCA x 2) – rear Trigger – rear 9 x speaker output (banana x 2) – rear 2 x subwoofer output (RCA) – rear Audio output (multi-zone) (RCA x 2) – rear |
|---|
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|---|
Platform | Roon, Sonos |
Intelligent Assistant | Siri, Google Assistant, Alexa |
Voice Controlled | Indirect |
Miscellaneous
Included Accessories | AM antenna, remote control, FM antenna, speaker setup microphone, power cord |
|---|---|
Bluetooth Profiles | Advanced Audio Distribution Profile (A2DP), Audio/Video Remote Control Profile (AVRCP) |
Power
Voltage Required | AC 120 V (60 Hz) |
|---|---|
Power Consumption Operational | 750 Watt |
Power Consumption Stand by | 0.1 Watt |
Power Consumption Idle | 75 Watt |
Dimensions & Weight
Width | 43.5 cm |
|---|---|
Depth | 37.95 cm |
Height | 17.35 cm |
Weight | 10.4 kg |
Dimensions & Weight (Shipping)
Width (Shipping) | 53.4 cm |
|---|---|
Depth (Shipping) | 46.8 cm |
Height (Shipping) | 26.5 cm |
Weight (Shipping) | 13.517 kg |
