Thermalright TG-1200, Power supply (internal), ATX12V 3.0, 80 PLUS Gold, AC 100-240 V, 1200 Watt
$240.75 inc GST
✓ In Stock - 1 available
✓ Free NZ Delivery
1 in stock (can be backordered)
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Thermalright TG-1200 power supply offers a robust solution for powering demanding systems with its capacity of 1200 W and comprehensive modular cable management. Featuring a fully modular design, this power supply allows for easy installation and improved airflow, ensuring that only the necessary cables are connected to your system. The included cables, such as the 24 pin ATX and 8 pin PCI Express, support a variety of setups, while the detachable sections provide flexibility for those who want to customize their connections based on individual needs.
Equipped with a reliable 120 mm fan, the TG-1200 maintains optimal cooling for both performance and longevity. With an MTBF of 100,000 hours, it is designed to endure a wide operating temperature range, from 0°C to 40°C. The power supply complies with ATX12V 3.0 specifications, featuring several safety features including overcurrent, overvoltage, overpower, undervoltage, and short-circuit protection, making it a dependable choice for any computer enthusiast or professional setup.
- 1200 W total power output for high-performance systems
- Fully modular design for improved cable management
- Comprehensive protection features for safe operation
- MTBF of 100,000 hours for extended reliability
- 80 PLUS Gold certification for enhanced energy efficiency
- Reliable power output
Provides a stable 1200 W of power to support high-performance components including CPUs and GPUs. - Advanced protection mechanisms
Incorporates overcurrent, overvoltage, overpower, undervoltage, and short-circuit protection to ensure the safety of connected devices. - Fully modular cable design
Allows users to connect only the required cables, optimizing airflow and reducing clutter within the casing. - High efficiency rating
Achieves an 80 PLUS Gold certification, translating to lower power consumption and reduced heat generation. - Effective cooling system
Features a 120 mm fan that adapts to load demands, providing efficient cooling while maintaining quieter operation.
Main Specifications
Product Description | Thermalright TG-1200 – power supply – 1200 Watt |
Device Type | Power supply – internal |
Specification Compliance | ATX12V 3.0 |
80 PLUS Certification | 80 PLUS Gold |
Input Voltage | AC 100-240 V |
Output Voltage | +3.3, +5, ±12 V, -12V, +5Vsb V |
Power Capacity | 1200 Watt |
Output Current | +3.3V – 20 A +5V – 20 A +12V – 100 A -12V – 0.3 A +5VSB – 2.5 A |
Output connectors | 1 x power 24 pin ATX with detachable 4 pin section 1 x power 8 pin cpu with detachable 4 pin 4 x 8 pin PCI Express power with detachable 2 pin section 4 x 6 pin Serial ATA power with detachable 3 pin 1 x 12VHPWR |
Modular Cable Management | Yes |
Cooling System | 120 mm fan |
Dimensions (WxDxH) | 15 cm x 14 cm x 8.6 cm |
Extended Specifications
General
Device Type | Power supply – internal |
|---|---|
Specification Compliance | ATX12V 3.0 |
PSU Form Factor | ATX |
Power Device
Input Voltage | AC 100-240 V |
|---|---|
Frequency Required | 47 – 63 Hz |
Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section 1 x power 8 pin cpu with detachable 4 pin 4 x 8 pin PCI Express power with detachable 2 pin section 4 x 6 pin Serial ATA power with detachable 3 pin 1 x 12VHPWR |
Output Voltage | +3.3, +5, ±12 V, -12V, +5Vsb V |
Max Electric Current | 100 A |
Power Capacity | 1200 Watt |
Output Current | +3.3V – 20 A +5V – 20 A +12V – 100 A -12V – 0.3 A +5VSB – 2.5 A |
Modular Cable Management | Yes |
80 PLUS Certification | 80 PLUS Gold |
Miscellaneous
Cables Included | AC power cable Power 24 pin ATX with detachable 4 pin section Power 8 pin CPU with 4 detachable 4 pin 2 x 8 pin PCI Express power with detachable 2 pin section 16-pin 12VHPWR power modular cable 2 x 6 pin Serial ATA power with detachable 3 pin 4 pin Parallel ATA power 2 x Serial ATA / 2 x Parallel ATA |
|---|---|
MTBF | 100,000 hours |
Cooling System | 120 mm fan |
Features | Fully modular, LLC resonant converter technology, Smart Zero Fan, overpower protection, over voltage protection, over current protection, short-circuit protection, undervoltage protection |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 40 °C |
Dimensions & Weight
Width | 15 cm |
|---|---|
Depth | 14 cm |
Height | 8.6 cm |
