Description
Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen11 delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency, the HPE ProLiant DL360 Gen11 is ideal for IT infrastructure, either physical, virtual, or containerized.
The HPE ProLiant DL360 Gen11 supports the Intel Xeon, plus 4800 MT/s HPE DDR5 SmartMemory. Introducing PCIe Gen5 and Intel Software Guard Extensions (SGX) support on the dual-socket segment, the HPE ProLiant DL360 Gen11 complements Gen10 Plus reach by delivering premium compute, memory, networking communication, discrete graphic, I/O, and security capabilities for customers focused on performance at any cost. DL360 Gen11 server is an execellent choice of daily business and workloads in General Compute, Database Management, Virtual Desktop Infrastructure, Content Delivery Network, Edge Acceleration and Intelligent Video Analytics.
- ENERGY STAR certified for operational efficiency
- Supports up to 2 Intel Xeon Silver processors for performance scalability
- Integrated Lights-Out 6 remote management for simplified server management
- DDR5 SDRAM with HPE SmartMemory technology for enhanced memory speed and reliability
- Hot-swap server storage bays for easy maintenance and upgrades
- Energy-efficient design
Certified by ENERGY STAR, this server exemplifies efficiency in operation, reducing power consumption and lowering operational costs. - Advanced connectivity
Equipped with a variety of interfaces including USB 3.2 Gen 1, VGA, and HPE iLO for comprehensive connectivity options, ensuring seamless integration into any IT environment. - Robust security features
Comes with a suite of security standards including FIPS 140-2 and TLS v1.2, providing a secure foundation for your data and ensuring compliance with regulations. - High-performance processing
Powered by an Intel Xeon Silver processor with the capability to scale up to 2 processors, offering robust performance for demanding applications. - Flexible storage solutions
Features hot-swap server storage bays, allowing for easy maintenance and upgrades without system downtime, ensuring continuous operation.
What’s in the Box
- HPE ProLiant DL360 Gen11 Network Choice
- 7 x standard fans, HPE Easy Install Rail 3 Kit, 2 x CPU standard heatsink
Main Specifications
Product Description | HPE ProLiant DL360 Gen11 Network Choice – rack-mountable Xeon Silver 4514Y 2 GHz – 64 GB – HDD 2 x 600 GB |
Type | Server – rack-mountable |
Height (Rack Units) | 1U |
Server Scalability | 2-way |
Processor | 2 x Intel Xeon Silver 4514Y / 2 GHz (up to 3.4 GHz, (16-core) |
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology |
Cache Memory | 60 MB L3 Cache |
Cache Per Processor | 30 MB |
RAM | 64 GB (installed) / 8 TB (max) – DDR5 SDRAM |
Storage Controller | RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) – OCP (HPE MR408i-o Gen11 SPDM) |
Server Storage Bays | Hot-swap 2.5″ |
Hard Drive | 2 x HDD 600 GB – SAS 12Gb/s – 10000 rpm |
Optical Storage | No optical drive |
Video Memory | 16 MB |
Networking | 1GbE |
Power Redundancy | Yes |
OS Provided | No operating system |
Software Included | HPE Server UEFI |
Dimensions (WxDxH) | 43.46 cm x 75.31 cm x 4.29 cm |
Weight | 14.56 kg |
Manufacturer Selling Program | HPE Smart Choice |
Environmental Standards | ENERGY STAR Qualified |
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 1U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 2-way |
|---|
Hot-Swap Bays Qty | 8 |
|---|
Processor / Chipset
CPU | Intel Xeon Silver 4514Y |
|---|
Clock Speed | 2 GHz |
|---|
Max Turbo Speed | 3.4 GHz |
|---|
Number of Cores | 16-core |
|---|
CPU Qty | 2 |
|---|
Max CPU Qty | 2 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology 2, Hyper-Threading Technology |
|---|
Chipset Type | Intel C741 |
|---|
Cache Memory
Installed Size | L3 Cache – 60 MB |
|---|
Cache Per Processor | 30 MB |
|---|
RAM
Installed Size | 64 GB (installed) / 8 TB (max) |
|---|
Technology | DDR5 SDRAM |
|---|
Effective Memory Speed | 2200 MHz |
|---|
Rated Memory Speed | 2800 MHz |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 32 (Total) / 28 (empty) |
|---|
Features | HPE SmartMemory, registered |
|---|
Configuration Features | 4 x 16 GB |
|---|
Hard Drive
Type | HDD |
|---|
Capacity | 2 x 600 GB |
|---|
Interface Type | SAS 12Gb/s |
|---|
Spindle Speed | 10000 rpm |
|---|
Features | Mission critical, HPE Multi Vendor |
|---|
Storage Controller
Type | 1 x RAID – OCP |
|---|
Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
|---|
Storage Controller Name | HPE MR408i-o Gen11 SPDM |
|---|
Channel Qty | 8 |
|---|
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
|---|
Buffer Size | 4 GB |
|---|
Optical Storage
Monitor
Graphics Controller
Video Memory | 16 MB |
|---|
Video Interfaces | VGA |
|---|
Networking
Interface (Bus) Type | Open Compute Project mezzanine (OCP) 3.0 |
|---|
Ethernet Ports | 4 x Gigabit Ethernet |
|---|
Ethernet Controller | Broadcom BCM5719 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Remote Management Protocol | SNMP 3, IPMI 2.0, SMASH CLP |
|---|
Remote Management Controller | Integrated Lights-Out 6 |
|---|
Features | Wake on LAN (WoL), PXE support |
|---|
Compliant Standards | OCP 3.0 |
|---|
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x external Universal Media Bay
8 (total) / 6 (free) x hot-swap 2.5″ SFF |
|---|
Slots | 2 (total) / 0 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode) |
|---|
Interfaces | 1 x HPE iLO – Type A (1 in front)
1 x HPE iLO – RJ-45
4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal)
1 x VGA
4 x LAN (Gigabit Ethernet) – RJ-45
1 x USB 2.0 |
|---|
Miscellaneous
Included Accessories | 7 x standard fans, 2 x CPU standard heatsink, HPE Easy Install Rail 3 Kit |
|---|
Compliant Standards | ASHRAE Class A3, ASHRAE Class A4, TLS v1.2, AES, FIPS 140-2, IPv6 Ready, PCI DSS, WEEE 2002/95/EC, ACPI 6.4 |
|---|
Manufacturer Selling Program | HPE Smart Choice |
|---|
Power
Device Type | Power supply – hot-plug |
|---|
Power Redundancy | Yes |
|---|
Power Redundancy Scheme | 1+1 |
|---|
Installed Qty | 2 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-240 V |
|---|
Power Provided | 800 watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
OS Certified | VMware vSphere 6.0 (ESXi), SuSE Linux Enterprise Server 11 SP4 |
|---|
Software | HPE Server UEFI |
|---|
Sustainability Information
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 43.46 cm |
|---|
Depth | 75.31 cm |
|---|
Height | 4.29 cm |
|---|
Weight | 14.56 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
