Description
Are you looking for a compact and versatile 1U server that supports edge workloads like security monitoring in a variety of environments? The reliable HPE ProLiant DL20 Gen11 server delivers a compact and versatile server with enhanced security at an affordable price. Deploy the short-depth rack form factor in small, remote, or branch offices, as a powerful point of sale platform in transport, retail, and hospitality environments or as a flexible configuration for customization in space constrained environments of military and government customers. Blending performance, reliability, and manageability, this one-socket, 1U server featuring Intel Xeon E processors provide unique enterprise-class capabilities at a great value-making it an ideal rack server platform for growing businesses, enterprises, and service providers. Outstanding configuration flexibility caters to a variety of business requirements and a wide range of qualified options fits a variety of needs.
- HPE ProLiant DL20 Gen11 server is a short-depth chassis of 15.05 inches, providing mobility and easy deployment in a wide variety of environments.
- HPE ProLiant DL20 Gen11 server offers a wide choice of dual-core, quad-core, hexa-core or octa-core Intel Xeon E processors with up to 128 GB of DDR5 ECC memory to handle your workload demands.
- Only Hewlett Packard Enterprise offers industry-standard servers, such as the HPE ProLiant DL20 Gen11server, with major firmware anchored directly into the silicon and with security protection built in across the server life-cycle, starting with Silicon Root of Trust from HPE.
- HPE ProLiant DL20 Gen11 server comes standard with a complete set of services from HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability.
- Compact, Secure, and Reliable Design for an Affordable Solution
HPE ProLiant DL20 Gen11 server is a short-depth chassis of 15.05 inches, providing mobility and easy deployment in a wide variety of environments.
HPE ProLiant DL20 Gen11 server has great quality and design features that are a hallmark of the HPE ProLiant family such as tool-less access to system components and enhanced serviceability.
Handle a range of light workloads to more demanding requirements with affordable configuration choices and a wide variety of Hewlett Packard Enterprise qualified options. - Right Balance of Performance, Flexibility, Reliability, and Manageability for Growing Business Needs
HPE ProLiant DL20 Gen11 server offers a wide choice of dual-core, quad-core, hexa-core or octa-core Intel Xeon E processors with up to 128 GB of DDR5 ECC memory to handle your workload demands.
Experience outstanding configuration flexibility with support for up to two large form factor (LFF) or six small form factor (SFF) drives, four DDR5 ECC UDIMMs, 290W, 500W, 800W or 1000W power supplies, and a more efficient deployment of options via HPE PCIe and OCP slots – now supporting PCIe 5.0.
The reliable HPE ProLiant DL20 Gen11 server combines a dense and compact form factor with redundant power supply capability, which keeps your business running and provides data protection and accessibility even in the event of a power supply failure.
Along with an embedded 4 x 1GbE, you have a choice of HPE PCIe standup adapters that offer a choice of networking bandwidth (1GbE to 10GbE) and fabric, so you can adapt and grow to changing business needs.
HPE iLO6 provides a more efficient and easier server management. It enables large-scale firmware deployment, improved GUI to simplify management with industry-standard APIs, and easy system debug access. - Security Innovations
Only Hewlett Packard Enterprise offers industry-standard servers, such as the HPE ProLiant DL20 Gen11server, with major firmware anchored directly into the silicon and with security protection built in across the server life-cycle, starting with Silicon Root of Trust from HPE.
Millions of lines of firmware code run before the server operating system boots. With Runtime Firmware Verification, enabled by the optional HPE iLO Advanced Premium Security Edition, the server’s firmware is checked every 24 hours, verifying validity and credibility of essential system firmware.
Secure Recovery allows server firmware to roll back to the last known good state or factory settings after detection of compromised server.
Additional security options are available with Trusted Platform Module (TPM) to avoid unauthorized access to the server and store artifacts used to authenticate the server platforms, while the Intrusion Detection Kit logs and alerts when the server hood is removed for further protection. - Industry-leading Services and Ease of Deployment
HPE ProLiant DL20 Gen11 server comes standard with a complete set of services from HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability.
HPE Services simplify the stages of your IT journey. Advisory and Transformation Services professionals understand customer challenges and design an ideal solution. Professional Services enables rapid deployment of solutions.
Operational Services from HPE Services includes: HPE Complete Care, HPE Tech Care and project-based services, such as Integration and Performance services. Additional services can be added to customize your experience at any stage of your IT lifecycle.
HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.
What’s in the Box
- HPE ProLiant DL20 Gen11
- 3 high performance fans
Main Specifications
Product Description | HPE ProLiant DL20 Gen11 – rack-mountable Xeon E-2414 2.6 GHz – 16 GB – HDD 2 x 2 TB |
Type | Server – rack-mountable |
Height (Rack Units) | 1U |
Server Scalability | 1-way |
Processor | 1 x Intel Xeon E-2414 / 2.6 GHz (up to 4.5 GHz, (Quad-Core) |
Processor Main Features | Intel Turbo Boost Technology 2, Intel Smart Cache, 55W TDP |
Cache Memory | 12 MB L3 Cache |
Cache Per Processor | 12 MB |
RAM | 16 GB (installed) / 128 GB (max) – DDR5 SDRAM – ECC |
Storage Controller | SATA (SATA 6Gb/s) (Intel VROC SATA Software RAID) |
Server Storage Bays | Hot-swap 3.5″ |
Hard Drive | 2 x HDD 2 TB – SATA 6Gb/s – 7200 rpm |
Optical Storage | No optical drive |
Graphics Controller | Matrox G200 |
Video Memory | 16 MB |
Networking | 1GbE |
Power | (50/60 Hz) |
OS Provided | No operating system |
Software Included | HPE iLO Management, HPE Intelligent Provisioning |
Dimensions (WxDxH) | 43.46 cm x 38.22 cm x 4.32 cm |
Weight | 11.52 kg |
Environmental Standards | ENERGY STAR Qualified |
Documents
Extended Specifications
General
Type | Server |
|---|
Product Form Factor | Rack-mountable – 1U |
|---|
Built-in Devices | Led panel |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Server Scalability | 1-way |
|---|
Hot-Swap Bays Qty | 2 |
|---|
Processor / Chipset
CPU | Intel Xeon E-2414 |
|---|
Clock Speed | 2.6 GHz |
|---|
Max Turbo Speed | 4.5 GHz |
|---|
Number of Cores | Quad-Core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology 2, Intel Smart Cache, 55W TDP |
|---|
Chipset Type | Intel C262 |
|---|
Cache Memory
Installed Size | L3 Cache – 12 MB |
|---|
Cache Per Processor | 12 MB |
|---|
RAM
Installed Size | 16 GB (installed) / 128 GB (max) |
|---|
Technology | DDR5 SDRAM – ECC |
|---|
Effective Memory Speed | 2200 MHz |
|---|
Rated Memory Speed | 2400 MHz |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 4 (Total) / 3 (empty) |
|---|
Features | HPE Standard Memory, unbuffered |
|---|
Configuration Features | 1 x 16 GB |
|---|
Hard Drive
Type | HDD |
|---|
Capacity | 2 x 2 TB |
|---|
Interface Type | SATA 6Gb/s |
|---|
Spindle Speed | 7200 rpm |
|---|
Features | Business critical, HPE Multi Vendor |
|---|
Storage Controller
Type | SATA |
|---|
Controller Interface Type | SATA 6Gb/s |
|---|
Storage Controller Name | Intel VROC SATA Software RAID |
|---|
RAID Level | RAID 1, RAID 0, RAID 5, RAID 10 |
|---|
Optical Storage
Monitor
Graphics Controller
Graphics Processor | Matrox G200 |
|---|
Video Memory | 16 MB |
|---|
Video Interfaces | DisplayPort, VGA |
|---|
Networking
Ethernet Ports | 4 x Gigabit Ethernet |
|---|
Ethernet Controller | Broadcom BCM5719 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Remote Management Protocol | IPMI 2.0, SNMP 3 |
|---|
Features | ACPI support, PXE support, Wake on LAN (WoL) |
|---|
Expansion / Connectivity
Bays | 2 (total) / 0 (free) x hot-swap 3.5″ LFF
1 (total) / 1 (free) x external |
|---|
Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 – half-length, full-height (x16 mode)
1 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0 |
|---|
Interfaces | 1 x HPE iLO – Type A (1 in front) (service port)
5 x USB 3.2 Gen 1×1 – Type A (1 front, 4 rear)
2 x USB 3.2 Gen 2×1 (2 internal)
1 x DisplayPort (1 rear)
1 x VGA (1 rear)
4 x LAN (Gigabit Ethernet) – RJ-45 (4 rear) (one of them is sideband iLO management port) |
|---|
Miscellaneous
Included Accessories | 3 high performance fans |
|---|
Compliant Standards | AES, Triple DES, ACPI 6.3, SMBIOS 3.2, Redfish API, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Active Directory v1.0, UEFI 2.9, PCI DSS, FIPS 140-2, IPv6 Ready, WEEE 2002/95/EC |
|---|
Power
Device Type | Power supply |
|---|
Installed Qty | 1 |
|---|
Max Supported Qty | 2 |
|---|
Voltage Required | AC 100-120/200-240 V (50/60 Hz) |
|---|
Power Provided | 290 watt |
|---|
80 PLUS Certification | 80 PLUS Platinum |
|---|
Operating System / Software
OS Provided | No operating system |
|---|
OS Certified | Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 8.0 update 2 |
|---|
Software | HPE iLO Management, HPE Intelligent Provisioning |
|---|
Sustainability Information
ENERGY STAR Certified | Yes |
|---|
ENERGY STAR Version | 4.0 |
|---|
Dimensions & Weight
Width | 43.46 cm |
|---|
Depth | 38.22 cm |
|---|
Height | 4.32 cm |
|---|
Weight | 11.52 kg |
|---|
Environmental Parameters
Min Operating Temperature | 10 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 8 – 90% RH (non-condensing) |
|---|
