Teltonika RUT200, Wireless router, WWAN 2.4 GHz, 4G, 2G, 3G, DIN rail mountable
$284.09 inc GST
✓ In Stock - 50 available
✓ Free NZ Delivery
50 in stock
Ships from: Christchurch
- Allow 2–3 days for delivery to the North Island
- Allow 1–2 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
RUT200 is a compact industrial cellular router that provides reliable, mission-critical connectivity in rigorous conditions common in industries like automation, transportation, and manufacturing. This model is equipped with 4G LTE, Wi-Fi, and two Ethernet ports, making it ideal for quickly setting up primary and backup connectivity with remote management capabilities.
- 4G/LTE (Cat 4), 3G, 2G
- Wireless access point with Hotspot functionality
- Automatic switching to available backup connection
- For remote management, access and VPN services
- Robust connectivity options
The RUT200 features support for GSM, WCDMA, and LTE cellular protocols, ensuring stable Internet access under varying conditions. It is designed for both wired and wireless connections, allowing for seamless integration into existing networks. - Enhanced security protocols
This router includes a wide range of security options, including firewall protection, NAT support, and various encryption algorithms like AES and WPA2. These features help protect data integrity and ensure secure network communication. - Efficient remote management
Remote management options such as SNMP and TR-069 enable users to monitor and control device settings efficiently. This feature simplifies network administration and enhances operational efficiency. - Versatile installation options
The DIN rail mountable design of the RUT200 facilitates easy installation in various environments. Its compact form factor is suitable for space-constrained setups while maintaining high-performance functionality. - Advanced data handling capabilities
With a maximum transfer rate of 150 Mbps, the RUT200 effectively manages data traffic for reliable online experiences. Its diverse networking protocols ensure compatibility with a wide range of applications and services.
What’s in the Box
- Teltonika RUT200
- External power adapter
- Software
Main Specifications
Product Description | Teltonika RUT200 – wireless router – WWAN – Wi-Fi – 4G, 2G, 3G – DIN rail mountable |
Device Type | Wireless router – wireless cellular modem |
Enclosure Type | DIN rail mountable |
Mobile Communication Protocol | GSM, WCDMA, LTE |
Generation | 4G, 2G, 3G |
WAN Ports Qty | 1 |
Data Link Protocol | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Frequency Band | 2.4 GHz |
Data Transfer Rate | 100 Mbps |
Capacity | Simultaneous connections: 50 |
Network / Transport Protocol | TCP/IP, UDP/IP, IPv4, IPv6, ICMP/IP, NTP, DNS, HTTP, HTTPs, FTP, SMTP, ARP, PPPoE, DHCP, Telnet, DDNS, L2TPv3, WireGuard |
Routing Protocol | VRRP, GRE |
Platform | Azure IoT Hub |
Remote Management Protocol | SSH, DHCP, Telnet, SMNP, SMPP, MQTT, Modbus, SSH-2, TR-069, SNMP 1, SNMP 2, SNMP 3, JSON-RPC |
VoIP Protocols | H.323, SIP |
Features | SMS remote control, USSD support, black list, white list, multiple PDN, band management, auto APN, bridge mode, Access Point operational mode, Auto Cipher modes, client separation, Stealth Mode, MAC address filtering, Captive Portal, RADIUS Server, auto-uplink (auto MDI/MDI-X), PPP, WOL, VoIP passthrough support, NAT support, firewall protection, DHCP relay, QoS, SQM, WMM support, automated failover, load balancing, SSHFS support, PSK, digital certificates, DMZ support, CLI management, IPSec NAT-T, DDoS Protection, VLAN support, ICMP, OpenVPN client, OpenVPN server, DMVPN, SSTP client instance support, FOTA, Teltonika RMS, passive PoE supported, aluminium housing |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11e |
Dimensions (WxDxH) | 8.3 cm x 7.4 cm x 2.5 cm |
Weight | 125 g |
Documents
Extended Specifications
General
Device Type | Wireless router |
|---|---|
Enclosure Type | DIN rail mountable |
Connectivity Technology | Wireless, wired |
Data Link Protocol | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Frequency Band | 2.4 GHz |
Data Transfer Rate | 100 Mbps |
Capacity | Simultaneous connections: 50 |
Network / Transport Protocol | TCP/IP, UDP/IP, IPv4, IPv6, ICMP/IP, NTP, DNS, HTTP, HTTPs, FTP, SMTP, ARP, PPPoE, DHCP, Telnet, DDNS, L2TPv3, WireGuard |
Routing Protocol | VRRP, GRE |
Remote Management Protocol | SSH, DHCP, Telnet, SMNP, SMPP, MQTT, Modbus, SSH-2, TR-069, SNMP 1, SNMP 2, SNMP 3, JSON-RPC |
Encryption Algorithm | WPA2-Enterprise, PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK, AES-CCMP, TKIP, SSL 3.0, TLS, IKEv1, IKEv2, DES, 3DES, 128-bit AES, 192-bit AES, 256-bit AES, MODBUS |
Authentication Method | X.509 certificates |
Features | SMS remote control, USSD support, black list, white list, multiple PDN, band management, auto APN, bridge mode, Access Point operational mode, Auto Cipher modes, client separation, Stealth Mode, MAC address filtering, Captive Portal, RADIUS Server, auto-uplink (auto MDI/MDI-X), PPP, WOL, VoIP passthrough support, NAT support, firewall protection, DHCP relay, QoS, SQM, WMM support, automated failover, load balancing, SSHFS support, PSK, digital certificates, DMZ support, CLI management, IPSec NAT-T, DDoS Protection, VLAN support, ICMP, OpenVPN client, OpenVPN server, DMVPN, SSTP client instance support, FOTA, Teltonika RMS, passive PoE supported, aluminium housing |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11e, IP30, CB, IEC 62368-1:2018 |
Processor | 1 x MediaTek MIPS 24KC 560 MHz |
RAM | 128 MB DDR2 SDRAM |
Flash Memory | 16 MB |
Status Indicators | Signal strength, power, status, connection type status |
Communications
Type | Wireless cellular modem |
|---|---|
Mobile Communication Protocol | GSM, WCDMA, LTE |
Generation | 4G, 2G, 3G |
Max Transfer Rate | 150 Mbps |
IP Telephony
VoIP Protocols | H.323, SIP |
|---|
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|---|
Platform | Azure IoT Hub |
Expansion / Connectivity
Interfaces | 1 x DI 1 x DO LAN: 1 x 10Base-T/100Base-TX – RJ-45 Antenna: 1 x RP-SMA Antenna: 2 x SMA WAN: 1 x 10Base-T/100Base-TX – RJ-45 |
|---|---|
Expansion Slots | 1 (total) / 1 (free) x Mini-SIM |
Aerial
Aerial | External detachable |
|---|---|
Antenna Qty | 3 |
Power
Power Device | External power adapter |
|---|---|
Power Consumption Operational | 6.5 Watt |
Software / System Requirements
OS Provided | RutOS |
|---|---|
Software Included | ZeroTier VPN |
Dimensions & Weight
Width | 8.3 cm |
|---|---|
Depth | 7.4 cm |
Height | 2.5 cm |
Weight | 125 g |
Environmental Parameters
Min Operating Temperature | -40 °C |
|---|---|
Max Operating Temperature | 75 °C |
Humidity Range Operating | 10 – 90% (non-condensing) |
