Description
The TP-Link Tapo C222 V1 is a versatile network surveillance camera designed to enhance security and provide peace of mind. This camera features a 2K QHD digital video capture resolution, delivering clear and detailed footage with a frame rate of up to 30 frames per second. Its pan and tilt design allows for a flexible viewing range, ensuring that any desired area is monitored. With support for infrared night vision and smart AI detection capabilities, the Tapo C222 V1 ensures reliable surveillance both day and night.
The camera incorporates features such as two-way audio for seamless communication, privacy zones for customized monitoring, and a built-in siren to deter potential intruders. Compatible with the Tapo application and intelligent assistants like Google Assistant and Alexa, the Tapo C222 V1 can be integrated into your smart home ecosystem. This camera provides monitoring capabilities and an array of security features designed to keep your space safe.
- 2K QHD digital video capture resolution for detailed images
- Pan and tilt functionality for flexible monitoring
- Smart AI detection for proactive security alerts
- Two-way audio for easy communication
- Infrared night vision to ensure visibility in low light
- High-Resolution Imaging
With a total of 4,000,000 pixels, this surveillance camera ensures clear and high-quality video, allowing detailed observation of monitored areas. - Wide Field of View
The camera features an angular field of view of 90 degrees, allowing for extensive coverage of spaces without the need for multiple cameras. - Enhanced Night Vision
The infrared LEDs provide night vision capability up to 12 meters, ensuring that areas remain visible even in complete darkness. - Robust Security Features
Equipped with SSL and AES encryption protocols, the camera secures video streams, enhancing privacy and protection against unauthorized access. - Versatile Mounting Options
With both ceiling and table mount options, this camera can be installed in various locations according to user preference and security needs.
What’s in the Box
- Tapo C222 V1
- Power adapter, camera mount base, screws, mounting template, anchors
Main Specifications
Product Description | Tapo C222 V1 – network surveillance camera |
Device Type | Network surveillance camera – pan / tilt |
Audio | Yes: two-way audio capability, built-in microphone, built-in speaker |
Camera Mount Type | Table mount, ceiling mount |
Dimensions (WxDxH) | 8.205 cm x 8.2 cm x 11.26 cm |
Connectivity Technology | Wireless, wired |
Camera | Colour – Day&Night |
Max Resolution | 2560 x 1440 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Video Modes | 2K |
Optical Sensor Type | Progressive Scan CMOS – 1/3″ – 4 MP |
Focal Length Control | Fixed focal |
Focal Length | 4 mm |
Lens Iris | F/2.2 |
Panning Range (degree) | 360 |
Tilting Range (degree) | 110 |
Interfaces | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax, 2.4GHz radio, Ethernet 10Base-T/100Base-TX |
Intelligent Assistant | Alexa, Google Assistant – indirect |
Voltage | AC 100 -240 V, DC 9 V |
Features | Video Streaming 2K QHD, Smart AI Detection, Smart AI Notification, sound and light alarm, customised activity zone, privacy zones, reset button, Full-time Live View, 3D digital noise reduction (DNR), Backlight Compensation (BLC), noise-cancellation microphone, built-in siren (99 dB), ONVIF support, infrared-cut filter, Wide Dynamic Range (WDR), LED indicator |
Environmental Parameters (operating) | 0 °C – 40 °C; 10 – 90% RH (non-condensing) relative humidity |
Documents
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: two-way audio capability, built-in microphone, built-in speaker |
|---|
Camera Mount Type | Table mount, ceiling mount |
|---|
Connectivity Technology | Wireless, wired |
|---|
Width | 8.205 cm |
|---|
Depth | 8.2 cm |
|---|
Height | 11.26 cm |
|---|
Camera
Type | Colour – Day&Night – pan / tilt |
|---|
Digital Video Format | H.264 |
|---|
Max Digital Video Resolution | 2560 x 1440 |
|---|
Motion Detection | Yes |
|---|
Video Modes | 2K |
|---|
Infrared LEDs | Yes |
|---|
Infrared Distance | 12 m |
|---|
Digital Video Capture Resolution | 2560 x 1440 |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Features | Video Streaming 2K QHD, Smart AI Detection, Smart AI Notification, sound and light alarm, customised activity zone, privacy zones, reset button, Full-time Live View, 3D digital noise reduction (DNR), Backlight Compensation (BLC), noise-cancellation microphone, built-in siren (99 dB), ONVIF support, infrared-cut filter, Wide Dynamic Range (WDR), LED indicator |
|---|
Image Sensor
Type | 4 MP Progressive Scan CMOS 1/3″ |
|---|
Lens Construction
Type | Fixed focal |
|---|
Focal Length | 4 mm |
|---|
Lens Iris | F/2.2 |
|---|
Horizontal Field of View (degree) | 76.2 |
|---|
Vertical Field of View (degree) | 41.8 |
|---|
Diagonal Field of View (degree) | 90 |
|---|
Panning
Tilting
Interfaces
Network Interface | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax, 2.4GHz radio, Ethernet 10Base-T/100Base-TX |
|---|
Network Protocols | RTSP, TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, UDP/IP, SSL, TLS, ONVIF |
|---|
Expansion / Connectivity
Ports | LAN – RJ-45 |
|---|
Supported Memory Cards | microSD Card |
|---|
Encryption Algorithm | 128-bit AES, SSL, TLS, WPA, WPA2-PSK |
|---|
Miscellaneous
Included Accessories | Screws, anchors, mounting template, camera mount base |
|---|
Compliant Standards | NCC, BSMI |
|---|
Power
Power Requirements | DC 9 V |
|---|
Power Device | Power adapter – external AC 100 -240 V (50/60 Hz) 3 Watt |
|---|
Internet of Things (IoT)
Internet of Things (IoT) Compatible | Yes |
|---|
Compatible Application | Tapo app |
|---|
Communications Type | Cloud |
|---|
Communications Technology | Wi-Fi |
|---|
Intelligent Assistant | Alexa, Google Assistant |
|---|
Voice Controlled | Indirect |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Relative Humidity (operating) | 10 – 90% RH (non-condensing) |
|---|
