Description
The TP-Link VIGI C340 V1 is designed to provide reliable outdoor surveillance with a robust weatherproof construction. It operates efficiently in extreme temperatures ranging from -30°C to 60°C, ensuring continuous monitoring even under harsh conditions. Featuring a high-resolution video capture of up to 2560 x 1440 and advanced digital video formats such as H.265 and H.264, this camera delivers clear images day and night. With its 30 m infrared distance and Smart IR capability, it captures motion in low-light environments, making it suitable for any outdoor setting. This network surveillance camera includes a wide range of features such as 2-way voice communication, motion detection, and instant notifications. It supports multiple network protocols including DHCP, HTTPS, and TCP/IP, allowing for seamless connectivity and control. The TP-Link VIGI C340 V1 also includes functions like Line Crossing Detection and Camera Tampering Detection, enhancing security measures. With an IP66 rating, this surveillance solution offers durability and reliability, tailored for comprehensive outdoor monitoring needs.
- Outdoor PoE connection, simple wiring
- Clarity and colors, all in one
- Smart detection
- Active defense
- Discover the best way to power your camera
- Outdoor PoE connection, simple wiring
Just connect your camera via an RJ45 cable, then power supply and data transmission are all settled. Waterproof hardware protect stable performance in outdoor scenarios. - Clarity and colors, all in one
Monitor 24-hour clear and colorful details even in pitch dark night. VIGI’s Full-Color camera provides maximum 4MP resolutions and ensures colorful monitoring with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights. - Smart detection
Receive notifications and check feeds when someone crosses a boundary, enters an area you’ve set, or obstructs the camera. - Active defense
Warn potential intruders instantly with sound and light when abnormal events - Discover the best way to power your camera
Two power supply ways not only give you more convenience but also make your wiring remarkably easy.
Main Specifications
Product Description | TP-Link VIGI C340 V1 – network surveillance camera – bullet |
Device Type | Network surveillance camera – fixed – bullet – outdoor – weatherproof |
Audio | Yes: built-in speaker, built-in microphone |
Dimensions (WxDxH) | 7 cm x 17.4 cm x 7.8 cm |
Weight | 195 g |
Connectivity Technology | Wired |
Camera | Colour – Day&Night |
Max Resolution | 2560 x 1440 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Optical Sensor Type | CMOS – 1/3″ |
Focal Length Control | Fixed focal |
Focal Length | 4 mm |
Lens Mounting | M12 mount |
Lens Iris | F/1.6 |
Interfaces | Ethernet 10Base-T/100Base-TX |
Voltage | DC 12 V |
Features | Backlight Compensation (BLC), IR filter, sharpness control, saturation control, brightness control, contrast control, image mirror, ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), Live View Control, programmable white balance, Camera Tampering Detection, Smart IR, reset button, password protection, 2-way voice communication, Region of Interest (ROI), exposure control, plastic housing, digest authentication, Line Crossing Detection, IP address filtering, 3D digital noise reduction (DNR), HTTPs encryption, human detection, Smart Detection, instant notification, object enter area detection, MiMo WiFi connectivity, Active Defense, password reset via e-mail, 2 video streams, video tampering detection |
Environmental Parameters (operating) | -30 °C – 60 °C |
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: built-in speaker, built-in microphone |
|---|
Form Factor | Bullet |
|---|
Connectivity Technology | Wired |
|---|
Width | 7 cm |
|---|
Depth | 17.4 cm |
|---|
Height | 7.8 cm |
|---|
Weight | 195 g |
|---|
Camera
Type | Colour – Day&Night – fixed – outdoor – weatherproof |
|---|
Digital Video Format | H.264, H.265, H.265+, H.264+ |
|---|
Max Digital Video Resolution | 2560 x 1440 |
|---|
Motion Detection | Yes |
|---|
Infrared LEDs | Yes |
|---|
Infrared Distance | 30 m |
|---|
Digital Video Capture Resolution | 640 x 480, 320 x 240, 352 x 288, 1920 x 1080, 2304 x 1296, 2560 x 1440, 2048 x 1280 |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Features | Backlight Compensation (BLC), IR filter, sharpness control, saturation control, brightness control, contrast control, image mirror, ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), Live View Control, programmable white balance, Camera Tampering Detection, Smart IR, reset button, password protection, 2-way voice communication, Region of Interest (ROI), exposure control, plastic housing, digest authentication, Line Crossing Detection, IP address filtering, 3D digital noise reduction (DNR), HTTPs encryption, human detection, Smart Detection, instant notification, object enter area detection, MiMo WiFi connectivity, Active Defense, password reset via e-mail, 2 video streams, video tampering detection |
|---|
Image Sensor
Lens Construction
Type | M12 mount – fixed focal |
|---|
Focal Length | 4 mm |
|---|
Lens Iris | F/1.6 |
|---|
Horizontal Field of View (degree) | 79 |
|---|
Vertical Field of View (degree) | 43 |
|---|
Diagonal Field of View (degree) | 93 |
|---|
Interfaces
Network Interface | Ethernet 10Base-T/100Base-TX |
|---|
Network Protocols | DHCP, DNS, HTTP, NTP, TCP/IP, UDP/IP, ICMP, RTSP, HTTPS, UPnP, TLS, SSL |
|---|
Expansion / Connectivity
Ports | LAN – RJ-45 |
|---|
Supported Memory Cards | microSD Card |
|---|
Miscellaneous
Included Accessories | Mounting hardware, waterproof cable attachments |
|---|
Compliant Standards | VCCI, BSMI, RoHS, NTRA, IP66, KC, RCM, IEEE 802.3af, IEEE 802.3at |
|---|
Power
Power Requirements | DC 12 V |
|---|
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
