Description
Add eight RS-232 DB9 serial ports to your desktop computer, through a PCIe expansion card slots. This PCI express serial card, with 8-port breakout cable, provides you with multiple ports to connect a wide variety of serial peripherals, at speeds of up to 921.4Kbps.
- Connect your peripherals with 8 serial ports
- Maximum compatibility
- Connect your peripherals with 8 serial ports
The PCI express serial port card makes it easy to add serial ports to connect your peripherals including printers, scanners, credit/debit card readers, PIN pads and modems, industrial controls and more. The 8 port PCIe serial card includes a breakout cable – with 8 DB9 connectors. - Maximum compatibility
With broad OS support, including for Windows and Linux, this PCI Express card is easy to integrate into mixed environments.
Main Specifications
Product Description | Startech 8-Port PCI Express RS232 Serial Adapter Card, PCIe RS232 Serial Card, 16C1050 UART, Multiport Serial DB9 Controller/Expansion Card, 15kV ESD Protection, Windows & Linux – Up to 921.6 Kbps Baud – serial adapter – PCIe – RS-232 x 8 – TAA Compliant |
Device Type | Serial adapter |
Form Factor | Plug-in card |
Interface (Bus) Type | PCI Express |
PCI Specification Revision | PCIe 1.1 |
Ports | RS-232 x 8 |
Dimensions (WxDxH) | 1.6 cm x 10.5 cm x 12 cm |
Weight | 74 g |
Cabling Type | Serial RS-232 |
Processor | ASMedia ASM1083 |
Colour | Yellow |
System Requirements | Microsoft Windows 98 Second Edition / Windows 2000, Microsoft Windows Server 2003, Microsoft Windows CE 5.0, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows XP / 7 / 8.1 / 10, Microsoft Windows Server 2016, Linux 2.4.x to 4.11.x LTS versions only, Microsoft Windows Server 2019 |
TAA Compliant | Yes |
Extended Specifications
General
Device Type | Serial adapter |
|---|
Form Factor | Plug-in card |
|---|
Interface (Bus) Type | PCI Express |
|---|
PCI Specification Revision | PCIe 1.1 |
|---|
Networking
Ports | RS-232 x 8 |
|---|
Connectivity Technology | Wired |
|---|
Cabling Type | Serial RS-232 |
|---|
Features | Flow control, 16550 UART support, 256-byte FIFO, 1.5KV ESD Protector |
|---|
Processor / Memory
Expansion / Connectivity
Interfaces | 8 x RS-232 – 9 pin D-Sub (DB-9) |
|---|
Miscellaneous
Included Accessories | 8 x hex nuts |
|---|
Cables Included | 1 x DB-62 to DB-9 breakout cable – 48 cm |
|---|
MTBF | 160,013 hours |
|---|
Compliant Standards | RoHS, WEEE |
|---|
Colour | Yellow |
|---|
TAA Compliant | Yes |
|---|
Software / System Requirements
OS Required | Microsoft Windows 98 Second Edition / Windows 2000, Microsoft Windows Server 2003, Microsoft Windows CE 5.0, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows XP / 7 / 8.1 / 10, Microsoft Windows Server 2016, Linux 2.4.x to 4.11.x LTS versions only, Microsoft Windows Server 2019 |
|---|
Dimensions & Weight
Width | 1.6 cm |
|---|
Depth | 10.5 cm |
|---|
Height | 12 cm |
|---|
Weight | 74 g |
|---|
Dimensions & Weight (Shipping)
Shipping Width | 19 cm |
|---|
Shipping Depth | 2.9 cm |
|---|
Shipping Height | 6.5 cm |
|---|
Shipping Weight | 700 g |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 55 °C |
|---|
Humidity Range Operating | 5 – 95% |
|---|
