Description
The Epson TM m30III (202) receipt printer is designed for efficiency and versatility in various business environments. With advanced connectivity options including USB 2.0 and USB-C, users can easily set up the printer in various configurations. It supports a wide range of barcodes, making it suitable for applications from retail to logistics. This printer features a compact design that is ideal for small spaces while delivering high printing speeds of 300 mm/s. The inclusion of a full cutter and a paper near end sensor enhances productivity, minimizing downtime during transactions. Operating efficiently in a range of environmental conditions, the Epson TM m30III (202) can function in temperatures from 5°C to 45°C and a humidity level of 10 to 90% RH. With a mean time between failures (MTBF) of 360,000 hours, businesses can rely on its durability. Additionally, the printer is equipped with an LED indicator and antibacterial features, ensuring it stays functional and hygienic.
- High printing speed of 300 mm/s
- Supports a wide range of barcodes including QR and Data Matrix
- Dual connectivity options with USB and LAN
- Compact design suitable for limited counter space
- Durable with an MTBF of 360,000 hours
- Efficient Connectivity
Offers multiple interfaces including USB 2.0, USB-C, and LAN for seamless integration into various environments. - High-speed Printing
Achieves a maximum printing speed of 300 mm/s, facilitating quick transaction processes in busy settings. - Versatile Media Handling
Supports various media sizes and types, chiefly thermal paper, with a maximum media size of 7.95 cm for different applications. - Reliable Performance
Designed to operate efficiently at temperatures ranging from 5°C to 45°C, ensuring consistent output in diverse environments. - Durable Design
Features an MTBF of 360,000 hours, indicating its robust build, ideal for high-demand scenarios.
What’s in the Box
- Epson TM m30III (202)
- 1 thermal roll paper
- Power adapter
- Paper roll spacer
Main Specifications
Product Description | Epson TM m30III (202) – receipt printer – B/W – thermal line |
Printer Type | Receipt printer – thermal line – B/W |
Weight | 1.3 kg |
Max Media Size | Roll (7.95 cm) |
Min Media Size (Custom) | 58 mm |
Max Media Size (Custom) | 80 mm |
Print Speed | Up to 300 mm/sec – max speed |
Max Resolution (B&W) | 203 x 203 dpi |
Max Resolution Class (B&W) | 203 x 203 dpi |
Cutter | Yes |
Interface | USB 2.0, LAN, USB-C, USB 2.0 host |
Barcodes | UPC-A, UPC-E, EAN/JAN-13, EAN/JAN-8, Code 39, Code 93, Code 128, ITF, Codabar, NW-7, GS1-128, GS1 DataBar, Code 128 Auto, PDF417, QR code, MaxiCode, Data Matrix, Aztec code, Composite |
Media Type | Thermal paper |
Fonts | Font A (12×24), Font B (10×24), Font C (9×17), Kanji Font B: 16 x 16, Font B (9×24), Kanji Font A (24×24), Kanji Font B: 20 x 24 |
Features | Full / partial cutter, paper near end sensor |
Networking | Print server |
Power | AC 100-230 V |
Enclosure Colour | Black |
Dimensions (WxDxH) | 12.7 cm x 12.7 cm x 13 cm |
Documents
Extended Specifications
Dimensions & Weight
General
Power
Power Device | Power adapter – external |
|---|
Environmental Parameters
Min Operating Temperature | 5 °C |
|---|
Power
Frequency Required | 50/60 Hz |
|---|
Dimensions & Weight
Environmental Parameters
Max Operating Temperature | 45 °C |
|---|
Networking
Dimensions & Weight
Printer
Media Handling
Media Type | Thermal paper |
|---|
Min Media Size (Custom) | 58 mm |
|---|
Roll Core Diameter | 18 mm |
|---|
Printer
Max Resolution (B&W) | 203 x 203 dpi |
|---|
Max Resolution Class (B&W) | 203 x 203 dpi |
|---|
Power
Power Consumption Operational | 30.6 Watt |
|---|
Media Handling
Max Media Size (Custom) | 80 mm |
|---|
Roll Maximum Outer Diameter | 83 mm |
|---|
Power
Power Consumption Stand by | 1.4 Watt |
|---|
Electric Current Required | 1.8 A |
|---|
Voltage Required | AC 100-230 V |
|---|
Media Handling
Max Media Size | Roll (7.95 cm) |
|---|
Printer
Connectivity Technology | Wired |
|---|
Print Speed | Up to 300 mm/sec – max speed |
|---|
Miscellaneous
Compliant Standards | IPX2 |
|---|
Included Accessories | Paper roll spacer |
|---|
Media Included | 1 thermal roll paper |
|---|
Media Handling
Media Sizes | Roll (7.95 cm), Roll (5.75 cm) |
|---|
Miscellaneous
Media Handling
Media Feeders | 1 x manual – 1 roll – Roll (7.95 cm) |
|---|
General
Printer Type | Receipt printer – thermal line – monochrome |
|---|
Environmental Parameters
Humidity Range Operating | 10 – 90% RH |
|---|
Printer
Features | Full / partial cutter, paper near end sensor |
|---|
Miscellaneous
Features | LED indicator, antibacterial |
|---|
Printer
Expansion / Connectivity
Connections | 1 x USB 2.0 – 4 pin USB Type B
1 x USB 2.0 host – 4 pin USB Type A
1 x LAN
1 x USB-C |
|---|
Printer
Interface | USB 2.0, LAN, USB-C, USB 2.0 host |
|---|
Fonts | Font A (12×24), Font B (10×24), Font C (9×17), Kanji Font B: 16 x 16, Font B (9×24), Kanji Font A (24×24), Kanji Font B: 20 x 24 |
|---|
Character Sizes (mm) | 1.25 x 3 mm, 1.13 x 3 mm, 0.88 x 2.13 mm, 0.88 x 3 mm, 3 x 3 mm, 2.26 x 3 mm, 2 x 2 mm |
|---|
Barcodes | UPC-A, UPC-E, EAN/JAN-13, EAN/JAN-8, Code 39, Code 93, Code 128, ITF, Codabar, NW-7, GS1-128, GS1 DataBar, Code 128 Auto, PDF417, QR code, MaxiCode, Data Matrix, Aztec code, Composite |
|---|
