Fortinet FortiGate 600E, Security appliance, 10GbE, 1U, rack-mountable

$23,386.73 inc GST

✕  Backorder  -  Email us for a lead time or ETA

✓  Free NZ Delivery

Available on back-order

Ships from: Auckland
  • Allow 1–2 days for delivery to the North Island
  • Allow 2–3 days for delivery to the South Island
  • Add 1–2 days if you are rural
  • Collection can be arranged
Manufacturer:Fortinet
Part Number:FG-600E
Warranty:12 Months
PPID:AB37452

We are currently experiencing 1-2 day shipping delays from this supplier warehouse

Description

The FortiGate 600E series delivers next generation firewall (NGFW) capabilities for mid-sized to large enterprises deployed at the campus or enterprise branch level. Protects against cyber threats with high-powered security processors for optimized network performance, security efficacy, and deep visibility. Fortinet’s Security-Driven Networking securely integrates with the new generation of cybersecurity solutions.

  • Protects against known exploits, malware and malicious websites
  • Identify thousands of applications for deep inspection into network traffic
  • Protects against unknown attacks using dynamic analysis
  • Delivers extensive routing, switching, wireless controller capabilities
  • Network processor
    Fortinet’s advanced, breakthrough network processor works inline with FortiOS functions delivering superior firewall performance for IPv4/IPv6, SCTP and multicast traffic with ultra-low latency down to 2 microseconds, VPN, CAPWAP and IP tunnel acceleration, anomaly-based intrusion prevention, checksum offload and packet defragmentation. It also allows traffic shaping and priority queuing.
  • Content processor
    Fortinet’s powerful content processor works outside of the direct flow of traffic and accelerates the inspection of computationally intensive security features.
  • Security Fabric
    The Security Fabric allows security to dynamically expand and adapt as more and more workloads and data are added. Security seamlessly follows and protects data, users, and applications as they move between IoT, devices, and cloud environments throughout the network. FortiGates are the foundation of Security Fabric, expanding security via visibility and control by tightly integrating with other Fortinet security products and Fabric-ready Partner solutions.
  • FortiOS
    Control all the security and networking capabilities across the entire FortiGate platform with one intuitive operating system. Reduce operating expenses and save time with a truly consolidated next-generation security platform.
  • FortiGuard security services
    FortiGuard Labs offers real-time intelligence on the threat landscape, delivering comprehensive security updates across the full range of Fortinet’s solutions. Comprised of security threat researchers, engineers, and forensic specialists, the team collaborates with the outstanding threat monitoring organizations and other network and security vendors, as well as law enforcement agencies.
  • FortiCare support services
    The FortiCare customer support team provides global technical support for all Fortinet products. FortiCare offers services to meet the needs of enterprises of all sizes.

Main Specifications

Product Description

Fortinet FortiGate 600E – security appliance

Device Type

Security appliance

Form Factor

Rack-mountable – 1U

Processor

Fortinet FortiASIC CP8/NP6

Hard Drive

240 GB x 1

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet

Performance

Firewall throughput (1518-byte UDP): 36 Gbps
Firewall throughput (512-byte UDP): 36 Gbps
Firewall throughput (64-byte UDP): 24 Gbps
VPN throughput (512-bit IPSec): 20 Gbps
VPN throughput (SSL): 2.2 Gbps
Firewall latency (64-byte UDP): 3 µs
Firewall throughput: 36 Mpps
IPS throughput (optimal traffic mix): 7 Gbps
Application control (AVC) throughput: 9 Gbps
SSL inspection throughput: 3.5 Gbps
CAPWAP throughput: 10 Gbps
IPS throughput (enterprise traffic mix): 4 Gbps
NGFW throughput: 3.8 Gbps
Threat protection throughput: 3 Gbps

Capacity

Concurrent sessions: 5500000
New sessions per second: 270000
Firewall policies: 10000
Gateway to gateway IPSec VPN Tunnels: 2000
Client to gateway IPSec VPN tunnels: 50000
Concurrent SSL VPN users: 5000
Virtual domains: 10
Number of FortiAP devices: 1024
Number of FortiToken devices: 1000
Number of FortiClient devices: 2000

Included Accessories

2 SX SFP transceivers

Power

AC 120/230 V (50/60 Hz)

Dimensions (WxDxH)

43.2 cm x 38 cm x 4.45 cm

Weight

7.3 kg

Extended Specifications

General

Device Type

Security appliance

Height (Rack Units)

1U

Width

43.2 cm

Depth

38 cm

Height

4.45 cm

Weight

7.3 kg

Processor / Memory / Storage

Processors Installed

Fortinet FortiASIC CP8/NP6

Hard Drive

SSD 240 GB x 1

Networking

Form Factor

Rack-mountable

Connectivity Technology

Wired

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet

Network / Transport Protocol

TCP/IP, UDP/IP, IPSec

Remote Management Protocol

HTTP

Performance

Firewall throughput (1518-byte UDP): 36 Gbps
Firewall throughput (512-byte UDP): 36 Gbps
Firewall throughput (64-byte UDP): 24 Gbps
VPN throughput (512-bit IPSec): 20 Gbps
VPN throughput (SSL): 2.2 Gbps
Firewall latency (64-byte UDP): 3 µs
Firewall throughput: 36 Mpps
IPS throughput (optimal traffic mix): 7 Gbps
Application control (AVC) throughput: 9 Gbps
SSL inspection throughput: 3.5 Gbps
CAPWAP throughput: 10 Gbps
IPS throughput (enterprise traffic mix): 4 Gbps
NGFW throughput: 3.8 Gbps
Threat protection throughput: 3 Gbps

Capacity

Concurrent sessions: 5500000
New sessions per second: 270000
Firewall policies: 10000
Gateway to gateway IPSec VPN Tunnels: 2000
Client to gateway IPSec VPN tunnels: 50000
Concurrent SSL VPN users: 5000
Virtual domains: 10
Number of FortiAP devices: 1024
Number of FortiToken devices: 1000
Number of FortiClient devices: 2000

Status Indicators

Power, status, alarm, link/activity, HA

Features

Switching, routing, VPN support, IPv6 support, High Availability, IPv4 support

Encryption Algorithm

SSL, 128-bit AES, 256-bit AES, 256-bit SHA, TLS 1.2

Expansion / Connectivity

Interfaces

2 x 10Gb Ethernet – SFP+
10 x 1000Base-T – RJ-45
8 x Ethernet 1000 – SFP (mini-GBIC)
2 x 1000Base-T (management) – RJ-45
1 x console
2 x USB – Type A

Miscellaneous

Included Accessories

2 SX SFP transceivers

Compliant Standards

UL, VCCI, C-Tick, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 A, IPv6 Ready, USGv6, ICSA SSL-VPN, ICSA IPS

Power

Power Device

Internal power supply

Voltage Required

AC 120/230 V (50/60 Hz)

Power Consumption Operational

129 Watt

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 – 90% (non-condensing)
