Edimax IGS-1105P, Switch, 4 x 10/100/1000 (PoE+) + 1 x Gigabit SFP, DIN rail mountable, wall-mountable, PoE+ (120 W)
$293.12 inc GST
✓ In Stock - 10 available
✓ Free NZ Delivery
10 in stock
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
Main Specifications
Product Description | Edimax IGS-1105P – switch – 5 ports |
Device Type | Switch – 5 ports |
Subtype | Gigabit Ethernet |
Ports | 4 x 10/100/1000 (PoE+) + 1 x Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 120 W |
Performance | Switching capacity: 10 Gbps Forwarding rate: 7.44 Mpps |
MAC Address Table Size | 2K entries |
Jumbo Frame Support | 9KB |
Features | Store and forward, QoS, fanless, over-current protection, Energy Efficient Ethernet, rugged, 2MB packet buffer, metal housing, 6KV Surge protection, reverse polarity protection |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az |
Power Redundancy | Yes |
Dimensions (WxDxH) | 13 cm x 3.2 cm x 18 cm |
Weight | 675 g |
Extended Specifications
General
Device Type | Switch – 5 ports |
|---|---|
Enclosure Type | DIN rail mountable, wall-mountable |
Subtype | Gigabit Ethernet |
Ports | 4 x 10/100/1000 (PoE+) + 1 x Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 120 W |
Performance | Switching capacity: 10 Gbps Forwarding rate: 7.44 Mpps |
MAC Address Table Size | 2K entries |
Jumbo Frame Support | 9KB |
Features | Store and forward, QoS, fanless, over-current protection, Energy Efficient Ethernet, rugged, 2MB packet buffer, metal housing, 6KV Surge protection, reverse polarity protection |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az |
Status Indicators | Fail, PoE, link/activity, power 1, power 2 |
Expansion / Connectivity
Interfaces | 4 x 1000Base-T RJ-45 PoE+ – 30 W 1 x 1000Base-X SFP |
|---|
Power
Power Device | External power adapter |
|---|---|
Power Redundancy | Yes |
Power Provided | 48 – 55 V |
Miscellaneous
MTBF | 1,000,000 hours |
|---|---|
Compliant Standards | BSMI, FCC, IP30 |
Dimensions & Weight
Width | 13 cm |
|---|---|
Depth | 3.2 cm |
Height | 18 cm |
Weight | 675 g |
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|---|
Max Operating Temperature | 70 °C |
Humidity Range Operating | 10 – 95% (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 85 °C |
Humidity Range Storage | 10 – 95% (non-condensing) |
