Edimax IGS-1005, Switch, 5 x 10/100/1000, DIN rail mountable, wall-mountable
$183.51 inc GST
✓ In Stock - 6 available
✓ Free NZ Delivery
6 in stock
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The Edimax IGS-1005 is designed for reliable networking with five 1000Base-T ports, supporting high-performance connections in various environments. Its rugged metal housing enables operation within extreme temperature ranges from -20°C to 70°C, making it suitable for challenging conditions. Equipped with features like Energy Efficient Ethernet and Quality of Service (QoS), it ensures optimal data handling and energy conservation.
With a switching capacity of 10 Gbps and a forwarding rate of 7.44 Mpps, the IGS-1005 meets the demands of modern network requirements. Its fanless design combined with over-current and surge protection enhances durability, while compliance with multiple standards such as IEEE 802.3 ensures compatibility and performance reliability. The IGS-1005 is ideal for both DIN rail and wall mounting, providing flexible installation options for various setups.
- Rugged metal housing for durability in challenging environments
- Supports up to five 1000Base-T ports for high-performance networking
- Energy Efficient Ethernet for reduced power consumption
- 10 Gbps switching capacity for efficient data handling
- Fanless design for silent operation
- Reliable performance
With a forwarding rate of 7.44 Mpps, the Edimax IGS-1005 delivers efficient data transmission to meet the needs of various network applications. - Flexible temperature range
Designed to operate in temperatures from -20°C to 70°C, this switch offers reliable performance in harsh environments. - Robust protection measures
Featuring 6 kV surge protection and reverse polarity protection, the IGS-1005 ensures enhanced stability and reliability in demanding network scenarios. - Versatile installation options
The device is mountable on DIN rails or walls, providing flexible installation choices to fit various space requirements. - Energy efficient design
The Energy Efficient Ethernet technology minimizes power usage without compromising performance, making it a sustainable networking solution.
Main Specifications
Product Description | Edimax IGS-1005 – switch – 5 ports |
Device Type | Switch – 5 ports |
Subtype | Gigabit Ethernet |
Ports | 5 x 10/100/1000 |
Performance | Switching capacity: 10 Gbps Forwarding rate: 7.44 Mpps |
MAC Address Table Size | 2K entries |
Jumbo Frame Support | 9KB |
Features | 6KV Surge protection, QoS, fanless, rugged, metal housing, store and forward, 2MB packet buffer, reverse polarity protection, over-current protection, Energy Efficient Ethernet |
Compliant Standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az |
Power Redundancy | Yes |
Dimensions (WxDxH) | 8.36 cm x 3 cm x 12.75 cm |
Weight | 387 g |
Extended Specifications
General
Device Type | Switch – 5 ports |
|---|---|
Enclosure Type | DIN rail mountable, wall-mountable |
Subtype | Gigabit Ethernet |
Ports | 5 x 10/100/1000 |
Performance | Switching capacity: 10 Gbps Forwarding rate: 7.44 Mpps |
MAC Address Table Size | 2K entries |
Jumbo Frame Support | 9KB |
Features | 6KV Surge protection, QoS, fanless, rugged, metal housing, store and forward, 2MB packet buffer, reverse polarity protection, over-current protection, Energy Efficient Ethernet |
Compliant Standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az |
Status Indicators | Link/activity, power 1, power 2, fail |
Expansion / Connectivity
Interfaces | 5 x 1000Base-T RJ-45 |
|---|
Power
Power Device | External power adapter |
|---|---|
Power Redundancy | Yes |
Power Provided | 12 – 48 V – 2.5 A |
Miscellaneous
MTBF | 1,000,000 hours |
|---|---|
Compliant Standards | IP30, FCC, BSMI |
Dimensions & Weight
Width | 8.36 cm |
|---|---|
Depth | 3 cm |
Height | 12.75 cm |
Weight | 387 g |
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|---|
Max Operating Temperature | 70 °C |
Humidity Range Operating | 10 – 95% (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 85 °C |
Humidity Range Storage | 10 – 95% (non-condensing) |
