Description
The Zebra ZD230 label printer is a robust solution designed to streamline operations across various industries. With its support for an extensive range of barcode formats, including QR codes, UPC, EAN, and more, it caters to the diverse needs of retail, healthcare, and logistics sectors. This printer is versatile in its connectivity options, featuring Bluetooth 4.1, USB 2.0, and Wi-Fi(ac), and efficient, boasting a maximum printing speed of 152 mm/s and a resolution of 203 DPI for clear, fast outputs.
Its ability to handle different media sizes and types, combined with adjustable sensors, makes it a flexible choice for customized printing tasks. The Zebra ZD230 operates reliably in a wide range of environmental conditions, thanks to its compliance with ENERGY STAR standards for energy efficiency and its robust design. Whether for creating labels, receipts, or tags, this printer is engineered to enhance productivity and streamline workflows, making it a valuable asset for any business looking to optimize its printing solutions.
- Supports a wide array of barcode formats for versatile application
- Bluetooth 4.1, USB 2.0, and Wi-Fi(ac) for flexible connectivity options
- ENERGY STAR certified for energy-efficient operation
- Direct thermal printing technology for reliable monochrome output
- Adjustable sensors and support for various media types enhance printing flexibility
- Versatile connectivity
Equipped with Bluetooth 4.1, USB 2.0, and Wi-Fi(ac), the Zebra ZD230 ensures seamless integration into existing systems, offering flexibility for various workplace setups. - Wide range of barcode support
The Zebra ZD230 is designed to meet diverse industry needs, supporting a comprehensive array of barcodes including QR codes, UPC, EAN, and more, making it ideal for retail, healthcare, and logistics. - Efficient media handling
Capable of handling rolls up to 12.7 cm with adjustable sensors for black mark and gap detection, the printer accommodates various media types and sizes for customized printing solutions. - High-quality printing
With a maximum resolution of 203 DPI and speeds up to 152 mm/s, the Zebra ZD230 delivers clear, fast monochrome printing, optimizing productivity for business operations. - Robust environmental adaptability
Designed to operate within a wide temperature range and humidity, coupled with ENERGY STAR certification, the Zebra ZD230 is built for reliability and efficiency in any work environment.
Main Specifications
Product Description | Zebra ZD230 – label printer – B/W – direct thermal |
Printer Type | Label printer – direct thermal – B/W |
Weight | 1.1 kg |
Max Media Size | Roll (12.7 cm) |
Min Media Size (Custom) | 25.4 mm |
Max Media Size (Custom) | 112 mm |
Max Resolution (B&W) | 203 dpi |
Cutter | Yes |
Interface | USB 2.0, LAN |
RAM Installed (Max) | 128 MB SDRAM |
Flash Memory Installed (Max) | 128 MB |
Language Simulation | ZPL II, EPL2, Extensible Mark-up Language (XML), EPL, EZPL |
Barcodes | Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, Aztec code, LOGMARS, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, Plessey, Standard 2 of 5, EAN-8, EAN-13, MSI |
Media Type | Receipt paper, tag stock, continuous labels, die cut labels, wristband labels, fanfold labels |
Features | Black Mark sensor, gap sensor |
Networking | Print server |
Power | AC 100-240 V |
Dimensions (WxDxH) | 17.6 cm x 22 cm x 15.1 cm |
Documents
Extended Specifications
General
Printer Type | Label printer – direct thermal – monochrome |
|---|
Printer
Connectivity Technology | Wireless |
|---|
Interface | USB 2.0, LAN |
|---|
Max Resolution (B&W) | 203 dpi |
|---|
Language Simulation | ZPL II, EPL2, Extensible Mark-up Language (XML), EPL, EZPL |
|---|
Features | Black Mark sensor, gap sensor |
|---|
Cutter | Yes |
|---|
Fonts Included | 16 x bitmapped ZPL II
2 x scalable ZPL
5 x expandable EPL2 |
|---|
Barcodes | Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, Aztec code, LOGMARS, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, Plessey, Standard 2 of 5, EAN-8, EAN-13, MSI |
|---|
RAM
RAM Installed (Max) | 128 MB |
|---|
Technology / Form Factor | SDRAM |
|---|
Flash Memory
Media Handling
Media Type | Receipt paper, tag stock, continuous labels, die cut labels, wristband labels, fanfold labels |
|---|
Max Media Size | Roll (12.7 cm) |
|---|
Min Media Size (Custom) | 25.4 mm |
|---|
Max Media Size (Custom) | 112 mm |
|---|
Media Sizes | Roll (2.54 – 11.2 cm) |
|---|
Max Printing Width | 104 mm |
|---|
Max Printing Length | 991 mm |
|---|
Media Thickness Range | 0.08 mm – 0.1905 mm |
|---|
Roll Maximum Outer Diameter | 127 mm |
|---|
Roll Core Diameter | 12.7 mm, 25.4 mm, 37.1 mm |
|---|
Media Feeders | 1 x manual – 1 roll – Roll (11.2 cm) |
|---|
Networking
Expansion / Connectivity
Connections | 1 x USB 2.0 – 4 pin USB Type B
LAN – RJ-45 |
|---|
Miscellaneous
Features | Adjustable black line sensor |
|---|
Compliant Standards | MFI, FCC Class B certified, VCCI, C-Tick, BSMI, ICES-003, NOM, SABS, EN 61000-3-3, EN55024, EN55022 Class B, FCC Part 15.247, CCC, IEC 60950-1, KCC, FCC Part 15.209, S Mark, cTUVus, EN 62311, EN 300 328, BIS, INMETRO, CU, RSS-247, EN 301 893 |
|---|
Power
Power Device | Power supply |
|---|
Voltage Required | AC 100-240 V |
|---|
Frequency Required | 50/60 Hz |
|---|
Power Factor Correction | Yes |
|---|
Software / System Requirements
Environmental Standards
Environmental Parameters
Min Operating Temperature | 4.4 °C |
|---|
Max Operating Temperature | 41 °C |
|---|
Humidity Range Operating | 10 – 90% (non-condensing) |
|---|
Dimensions & Weight
Width | 17.6 cm |
|---|
Depth | 22 cm |
|---|
Height | 15.1 cm |
|---|
Weight | 1.1 kg |
|---|
