Honeywell PX65 – Label printer – direct thermal / thermal transfer – Roll (17 cm) – 203 dpi – up to 225 mm/sec – USB 2.0, LAN, USB 2.0 host, Wi-Fi(ac), RS232 – rewinder

Manufacturer:Honeywell
Part Number:PX65A00000010200
Warranty:2 Years
PPID:AB32136

$6,070.41 inc GST

Free Delivery

Available on back-order

Out of Stock! Contact us for a lead time or ETA

Ships from Auckland or Christchurch

Ships from Auckland or Christchurch

  • Allow 1-2 days for delivery
  • add 1-2 days if you are rural
  • No Collections

Description

The rugged, all-metal PX65 printer delivers outstanding performance and incorporates features that reduce downtime and minimize maintenance costs. It is ideal for compliance labeling applications with variable data requiring immediate results.
The PX65 printer’s smart design features support increased productivity in demanding environments. As Smart Printer, it can host stand-alone applications, developed through the Fingerprint and C# programming languages, helping reduce errors and streamline operational processes.
The printer’s device management and diagnostic capabilities – provided in web-based PrintSet 5 Configuration Management tool, configuration tool PrintSet MC for mobile devices and cloud-based Operational Intelligence – reduce downtime and simplify deployment. Replacing printheads is fast and easy, thanks to the magnetic QuickMount printhead design. The PX65 printer is co-engineered and tested with Honeywell labels and other media products, optimizing performance when used with genuine Honeywell media.

Main Specifications

Product DescriptionHoneywell PX65 – label printer – B/W – direct thermal / thermal transfer
Printer TypeLabel printer – direct thermal / thermal transfer – B/W
Weight14.1 kg
Max Media SizeRoll (17 cm)
Min Media Size (Custom)76 mm
Max Media Size (Custom)170 mm
Print SpeedUp to 225 mm/sec – max speed
Up to 100 mm/sec
Max Resolution (B&W)203 dpi
InterfaceUSB 2.0, LAN, USB 2.0 host, Wi-Fi(ac), RS232
RAM Installed (Max)256 MB SDRAM
Flash Memory Installed (Max)512 MB
Language SimulationZPL II, Intermec Printer Language (IPL), PDF, Intermec Fingerprint, Intermec Direct Protocol, Extensible Mark-up Language (XML), DPL, ZSim2, C#
BarcodesUCC/EAN-128, ISBT 128, HIBCC, UPC, Postnet, AIAG, OGMARS, GM1724
Media TypeLabels, continuous labels, tags, black mark labels, ribbon, notch, gap
FeaturesRewinder, Label Taken Sensor (LTS), realtime clock, ribbon end sensor, open head sensor
NetworkingPrint server
PowerAC 90-265 V
Dimensions (WxDxH)33.5 cm x 48.2 cm x 23.8 cm

Extended Specifications

General

Printer TypeLabel printer – direct thermal / thermal transfer – monochrome

Printer

Print SpeedUp to 225 mm/sec – max speed – 203 dpi
Up to 100 mm/sec – 203 dpi
Built-in DevicesLCD touch screen
Connectivity TechnologyWireless
InterfaceUSB 2.0, LAN, USB 2.0 host, Wi-Fi(ac), RS232
Max Resolution (B&W)203 dpi
Language SimulationZPL II, Intermec Printer Language (IPL), PDF, Intermec Fingerprint, Intermec Direct Protocol, Extensible Mark-up Language (XML), DPL, ZSim2, C#
FeaturesRewinder, Label Taken Sensor (LTS), realtime clock, ribbon end sensor, open head sensor
BarcodesUCC/EAN-128, ISBT 128, HIBCC, UPC, Postnet, AIAG, OGMARS, GM1724

RAM

RAM Installed (Max)256 MB
Technology / Form FactorSDRAM

Flash Memory

Flash Memory512 MB

Media Handling

Media TypeLabels, continuous labels, tags, black mark labels, ribbon, notch, gap
Max Media SizeRoll (17 cm)
Min Media Size (Custom)76 mm
Max Media Size (Custom)170 mm
Media SizesRoll (7.6 – 17 cm)
Max Printing Width167.4 mm
Media Thickness Range0.061 mm – 0.254 mm
Roll Maximum Outer Diameter213 mm
Roll Core Diameter76 mm, 38 mm
Media Feeders1 x manual – 1 roll – Roll (17 cm)

RFID

Compliant StandardsISO/IEC 18000-6C
Frequency865-928 MHz

Networking

NetworkingPrint server
Remote Management ProtocolSNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SFTP, ICMP, DHCP, TCP/IP, UDP, BOOTP
Security Protocols & FeaturesLEAP, WEP, WPA, WPA2, EAP-TTLS, PEAP, FAST

Expansion / Connectivity

Connections1 x USB 2.0 host
1 x USB 2.0
1 x LAN
1 x RS-232

Miscellaneous

Compliant StandardsFCC Class B certified, RoHS, EN 55032 Class B

Power

Power DevicePower supply – internal
Voltage RequiredAC 90-265 V
Frequency Required50/60 Hz
Power Consumption Operational400 Watt
Power Consumption Stand by5 Watt

Software / System Requirements

Software IncludedInterDriver Windows, CUPS driver for Linux, Honeywell Device Types, Honeywell Label Design and Print Package

Environmental Standards

ENERGY STARYes
ENERGY STAR Version3.0

Environmental Parameters

Min Operating Temperature5 °C
Max Operating Temperature40 °C
Humidity Range Operating10 – 90% (non-condensing)

Dimensions & Weight

Width33.5 cm
Depth48.2 cm
Height23.8 cm
Weight14.1 kg
