Description
The 5 m LSZH CAT6 Ethernet Cable from StarTech.com is designed to deliver reliable network performance for various applications. With its patch cable configuration and UTP technology, this cable supports high-speed connections. The low smoke zero halogen jacket ensures safety in case of fire, making it suitable for a range of environments. Both ends feature male RJ-45 connectors that are snagless, allowing for easy installation without the worry of damaging the connectors.
- 100% copper for outstanding value
- 24-gauge wire for high-performance network connections
- 50-micron gold connectors provide peak conductivity
- 100% copper for outstanding value
Get the highest value for your cable investment with StarTech Cat 6 cables, each one manufactured using high-quality copper conductors. - 24-gauge wire for high-performance network connections
Ensure high-performance capability for your demanding Ethernet applications, such as Power over Ethernet, using cables that include 24 AWG copper. - 50-micron gold connectors provide peak conductivity
Rely on RJ45 connectors to deliver optimum conductivity while eliminating signal loss due to oxidation or corrosion.
Main Specifications
Product Description | Startech 5m LSZH CAT6 Ethernet Cable, 10 Gigabit Snagless RJ45 100W PoE Network Patch Cord with Strain Relief, CAT 6 10GbE UTP, Grey, Individually Tested/ETL, Low Smoke Zero Halogen – Category 6 – 24AWG (N6LPATCH5MGR) – patch cable – 5 m – grey |
Type | Patch cable – CAT 6 |
Technology | Unshielded twisted pair (UTP) |
Wiring Scheme | T568B |
Wires per Cable | 8 wires |
Features | Snagless, strain relief, PoE ready |
Cable Length | 5 m |
Diameter | 6 mm |
Connector | RJ-45 – male |
Connector (Second End) | RJ-45 – male |
Colour | Grey |
Extended Specifications
General
Plated Connector | Gold |
|---|
Features | Snagless, strain relief, PoE ready |
|---|
Cable Length | 5 m |
|---|
Diameter | 6 mm |
|---|
Colour | Grey |
|---|
Connectivity
Connector | RJ-45 – male |
|---|
Connector (Second End) | RJ-45 – male |
|---|
Miscellaneous
Compliant Standards | RoHS, ETL, WEEE, TIA/EIA-568-B.1-2001 – up to 650 MHz |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 80 °C |
|---|
General
Network Cable Type | Patch cable – CAT 6 |
|---|
Technology | Unshielded twisted pair (UTP) |
|---|
Wiring Scheme | T568B |
|---|
Jacket Material | Low Smoke Zero Halogen (LSZH) |
|---|
American Wire Gauge (AWG) | 24 |
|---|
Wires per Cable | 8 wires |
|---|
Pairs per Cable | 4 pairs |
|---|
