Description
Keep the project momentum. With radically simple solutions and the easiest PDF printing, it’s easy for everyone to get great results every time. Meet deadlines with the fastest print speed in the most compact, quiet printer.
Dynamic security enabled printer
Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges.
- Adopt a smart workstyle with the easiest PDF printing using HP Click software.
- Showcase design versatility from precise line drafts to boldly colored 3D renders, with HP Bright Office Inks.
- Rely on the best network protection with features like HP Secure Boot and whitelisting.
- Discover maximum simplicity
Adopt smart ways of working, thanks to simple PDF printing. Give your teams more effective tools. Easily print and share jobs from the cloud with mobiles and the HP Smart app. Equip your working environment with a compact design and quiet operation, with up to 87% less noise. - Enhanced performance
Highlight the versatility of your designs, from precise lines to vividly colored 3D renderings, with HP Bright Office inks. Deliver high precision and visualize subtle details with the Adobe PDF Print Engine. Meet deadlines with equipment that delivers incredibly fast speeds. Reduce unproductive tasks with the integrated automatic stacker. - A secure large-format printer
Benefit from perfect network protection with features such as HP Secure Boot and whitelisting. Control who accesses the printer and its confidential documents with secure user authentication. Protect your printer fleet at all times with HP JetAdvantage Security Manager.
What’s in the Box
- HP DesignJet T1600 Printer, printer stand and media bin, spindle, printheads, introductory ink cartridges, user guide, power cords
Main Specifications
Product Description | HP DesignJet T1600 – large-format printer – colour – ink-jet |
Printer Type | 36″ large-format printer – ink-jet – colour |
Weight | 82 kg |
Inkjet Technology | HP Thermal Inkjet |
Ink Palette Supported (Colours) | 6-ink – cyan, magenta, yellow, photo black, pigment matte black, grey |
Max Media Size | Roll (91.4 cm x 91.4 m), 914 x 1219 mm |
Min Media Size (Custom) | 210 mm x 279 mm |
Max Media Size (Custom) | 914 mm x 1219 mm |
Print Speed | Up to 0.33 min/page – A1 (594 x 841 mm)
Up to 0.33 min/page – ANSI D (559 x 864 mm) |
Max Resolution (B&W) | 2400 x 1200 dpi |
Max Resolution (Colour) | 2400 x 1200 dpi |
Cutter | Yes |
Interface | Gigabit LAN, USB |
AirPrint Enabled | Yes |
RAM Installed (Max) | 128 GB |
Hard Drive | 500 GB |
Language Simulation | PostScript 3, HP RTL, CALS G4, HP GL/2, TIFF, PDF 1.7, JPEG |
Media Type | Photo paper, vinyl, bond paper, film, backlit paper, translucent bond paper, photographic paper, glossy paper, matte paper, semi-gloss paper, coloured paper, polyester paper |
Total Media Capacity | 1 roll |
Networking | Print server |
Printer Features | Print from mobile device, Hard Disk Drive Encryption |
Power | AC 100-240 V |
Dimensions (WxDxH) | 1.39 m x 76 cm x 1.08 m |
Documents
Extended Specifications
General
Printer Type | 36″ large-format printer – ink-jet – colour |
|---|
Printer
Inkjet Technology | HP Thermal Inkjet |
|---|
Ink Palette Supported (Colours) | 6-ink – cyan, magenta, yellow, photo black, pigment matte black, grey |
|---|
Ink Cartridge Configuration | 6 cartridges (1 each: cyan, magenta, yellow, grey, photo black, pigment matte black) |
|---|
Print Speed | Up to 0.33 min/page – A1 (594 x 841 mm)
Up to 0.33 min/page – ANSI D (559 x 864 mm) |
|---|
Built-in Devices | Stacker |
|---|
Connectivity Technology | Wired |
|---|
Interface | Gigabit LAN, USB |
|---|
AirPrint Enabled | Yes |
|---|
Max Resolution (B&W) | 2400 x 1200 dpi |
|---|
Max Resolution (Colour) | 2400 x 1200 dpi |
|---|
PostScript Support | Standard |
|---|
Language Simulation | PostScript 3, HP RTL, CALS G4, HP GL/2, TIFF, PDF 1.7, JPEG |
|---|
Cutter | Yes |
|---|
Printer Features | Print from mobile device, Hard Disk Drive Encryption |
|---|
RAM
RAM Installed (Max) | 128 GB |
|---|
Storage
Media Handling
Media Type | Photo paper, vinyl, bond paper, film, backlit paper, translucent bond paper, photographic paper, glossy paper, matte paper, semi-gloss paper, coloured paper, polyester paper |
|---|
Max Media Size | Roll (91.4 cm x 91.4 m), 914 x 1219 mm |
|---|
Min Media Size (Custom) | 210 mm x 279 mm |
|---|
Max Media Size (Custom) | 914 mm x 1219 mm |
|---|
Media Sizes | ANSI A (Letter) (216 x 279 mm), A4 (210 x 297 mm), A3 (297 x 420 mm), A2 (420 x 594 mm), A1 (594 x 841 mm), A0 (841 x 1189 mm), ANSI B (Ledger) (279 x 432 mm), ANSI C (432 x 559 mm), ANSI E (864 x 1118 mm), ANSI D (559 x 864 mm), Roll (91.4 cm x 91.4 m), 914 x 1219 mm, 210 x 279 mm, 210 x 914 mm |
|---|
Max Printing Length | 91.4 m |
|---|
Media Thickness Range | Up to 0.5 mm |
|---|
Media Weight | 60 g/m² – 328 g/m² |
|---|
Total Media Capacity | 1 roll |
|---|
Media Feeders | 1 x manual – 1 roll – Roll (91.4 cm) weight: 60 g/m² – 328 g/m² |
|---|
Networking
Networking | Print server |
|---|
Remote Management Protocol | IPP, HTTP, HTTPS, TFTP, SMTP, DHCP, IPv4 |
|---|
Security Protocols & Features | Kerberos, LDAP, SSL, Apple Bonjour, LEAP, SMB authentication, TLS, IPsec, 802.1x, EAP-TLS, PEAP, SNMP 3 |
|---|
Expansion / Connectivity
Connections | 1 x Gigabit LAN – RJ-45
USB – 4 pin USB Type A |
|---|
Miscellaneous
Included Accessories | Spindle, stand, media bin |
|---|
Consumables Included | Printhead
Ink cartridge (matte black)
1 x ink cartridge (cyan)
1 x ink cartridge (magenta)
1 x ink cartridge (yellow)
1 x ink cartridge (grey)
1 x ink cartridge (photo black) |
|---|
Features | Trusted Platform Module (TPM), Self-Encrypting Drive (SED) support |
|---|
Compliant Standards | RoHS, EN 60950-1, WEEE, REACH, LVD, ERP, EMC Class B, EAC, Ukraine |
|---|
Power
Power Device | Power supply – internal |
|---|
Voltage Required | AC 100-240 V |
|---|
Frequency Required | 50/60 Hz |
|---|
Power Consumption Operational | 100 watt |
|---|
Power Consumption Stand by | 36 watt |
|---|
Power Consumption Sleep | 10 watt |
|---|
Software / System Requirements
Software Included | HP Web JetAdmin, HP Click, HP JetAdvantage Security Manager, Drivers & Utilities |
|---|
Environmental Standards
Environmental Parameters
Min Operating Temperature | 5 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 20 – 80% RH |
|---|
Sound Emission (Idle) | 32 dBA |
|---|
Sound Emission (Operating) | 42 dBA |
|---|
Dimensions & Weight
Width | 1.39 m |
|---|
Depth | 76 cm |
|---|
Height | 1.08 m |
|---|
Weight | 82 kg |
|---|
Dimensions & Weight (Shipping)
Width (Shipping) | 1.477 m |
|---|
Depth (Shipping) | 76.7 cm |
|---|
Height (Shipping) | 80 cm |
|---|
Weight (Shipping) | 113 kg |
|---|
