Description
The TP-Link VIGI C440 V2 network surveillance camera is engineered for precision and reliability, offering high-definition video capture in resolutions up to 2560 x 1440. With its robust environmental adaptability, it operates flawlessly in temperatures ranging from -30 °C to 60 °C and humidity up to 95%, ensuring performance in any weather condition.
Equipped with advanced surveillance features such as Active Defense, Line Crossing Detection, and Human Detection, this camera is designed to provide comprehensive security solutions. Night vision capability extends up to 30 m, ensuring clear images even in complete darkness, while the built-in microphone and speaker facilitate direct communication through the camera.
The TP-Link VIGI C440 V2 is not only powerful but also flexible, supporting a wide range of network protocols and ONVIF for easy integration into existing systems. Its durable turret form factor, along with ceiling and wall mount options, offers versatile installation possibilities. Whether for home security or business surveillance, the TP-Link VIGI C440 V2 stands out as a reliable choice.
- High-definition video capture up to 2560 x 1440 resolution
- Night vision capability with a 30 m range for round-the-clock surveillance
- Active Defense and smart detection features for enhanced security
- Built-in microphone and speaker for 2-way voice communication
- Supports a wide range of network protocols for easy system integration
- Robust environmental adaptability
Designed to withstand extreme temperatures ranging from -30 °C to 60 °C and humidity up to 95% (non-condensing), ensuring reliable operation in any weather condition. - High-definition video quality
Equipped with a CMOS optical sensor and capable of capturing video in resolutions up to 2560 x 1440, this camera delivers crisp, clear images for precise monitoring. - Advanced surveillance features
Features like Active Defense, Line Crossing Detection, and Human Detection, combined with 2-way voice communication and night vision up to 30 m, provide comprehensive security solutions. - Easy integration and operation
Supports a wide range of network protocols and ONVIF support for easy integration into existing systems, while the built-in microphone and speaker enable direct communication through the camera. - Durable and versatile design
The turret form factor with ceiling and wall mount options, along with a plastic housing, offers flexibility in installation and ensures durability against physical tampering.
What’s in the Box
- TP-Link VIGI C440 V2
- Mounting hardware
Main Specifications
Product Description | TP-Link VIGI C440 V2 – network surveillance camera – turret |
Device Type | Network surveillance camera – pan / tilt – turret |
Audio | Yes: built-in speaker, built-in microphone |
Camera Mount Type | Wall mount, ceiling mount |
Dimensions (WxDxH) | 12.3 cm x 8.3 cm x 12.3 cm |
Weight | 250 g |
Connectivity Technology | Wired |
Camera | Colour – Day&Night |
Max Resolution | 2560 x 1440 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Optical Sensor Type | CMOS – 1/3″ – 4 MP |
Minimum Illumination | 0 lux – white light |
Focal Length Control | Fixed focal |
Focal Length | 4 mm |
Lens Mounting | M12 mount |
Lens Iris | F/1.6 |
Panning Range (degree) | 0 to 360 |
Tilting Range (degree) | 0 to 85 |
Interfaces | Ethernet 10Base-T/100Base-TX |
Voltage | DC 12 V / PoE |
Features | Backlight Compensation (BLC), IR filter, sharpness control, saturation control, brightness control, contrast control, image mirror, ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), Live View Control, programmable white balance, Camera Tampering Detection, Smart IR, reset button, password protection, 2-way voice communication, Region of Interest (ROI), exposure control, plastic housing, digest authentication, Line Crossing Detection, IP address filtering, 3D digital noise reduction (DNR), HTTPs encryption, human detection, Smart Detection, instant notification, object enter area detection, MiMo WiFi connectivity, Active Defense, password reset via e-mail, 2 video streams, video tampering detection, slow shutter |
Environmental Parameters (operating) | -30 °C – 60 °C; up to 95% (non-condensing) relative humidity |
Extended Specifications
General
Device Type | Network surveillance camera |
|---|
Audio Support | Yes: built-in speaker, built-in microphone |
|---|
Audio Formats | G.711 A-law |
|---|
Form Factor | Turret |
|---|
Camera Mount Type | Wall mount, ceiling mount |
|---|
Connectivity Technology | Wired |
|---|
Width | 12.3 cm |
|---|
Depth | 8.3 cm |
|---|
Height | 12.3 cm |
|---|
Weight | 250 g |
|---|
Camera
Type | Colour – Day&Night – pan / tilt |
|---|
Digital Video Format | H.264, H.265, H.265+, H.264+ |
|---|
Max Digital Video Resolution | 2560 x 1440 |
|---|
Motion Detection | Yes |
|---|
Exposure Range | 1/3 sec – 1/10000 sec |
|---|
Minimum Illumination | 0 lux – white light |
|---|
Infrared LEDs | Yes |
|---|
Infrared Distance | 30 m |
|---|
Digital Video Capture Resolution | 640 x 480, 320 x 240, 352 x 288, 1920 x 1080, 2304 x 1296, 2560 x 1440, 2048 x 1280 |
|---|
Frame Rate (max) | 30 frames per second |
|---|
Features | Backlight Compensation (BLC), IR filter, sharpness control, saturation control, brightness control, contrast control, image mirror, ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), Live View Control, programmable white balance, Camera Tampering Detection, Smart IR, reset button, password protection, 2-way voice communication, Region of Interest (ROI), exposure control, plastic housing, digest authentication, Line Crossing Detection, IP address filtering, 3D digital noise reduction (DNR), HTTPs encryption, human detection, Smart Detection, instant notification, object enter area detection, MiMo WiFi connectivity, Active Defense, password reset via e-mail, 2 video streams, video tampering detection, slow shutter |
|---|
Image Sensor
Lens Construction
Type | M12 mount – fixed focal |
|---|
Focal Length | 4 mm |
|---|
Lens Iris | F/1.6 |
|---|
Horizontal Field of View (degree) | 79 |
|---|
Vertical Field of View (degree) | 43 |
|---|
Diagonal Field of View (degree) | 93 |
|---|
Panning
Tilting
Interfaces
Network Interface | Ethernet 10Base-T/100Base-TX |
|---|
Network Protocols | DHCP, DNS, HTTP, NTP, TCP/IP, UDP/IP, ICMP, RTSP, HTTPS, UPnP, TLS, SSL |
|---|
Expansion / Connectivity
Ports | LAN/power – RJ-45 |
|---|
Supported Memory Cards | SD Memory Card |
|---|
Miscellaneous
Included Accessories | Mounting hardware |
|---|
Compliant Standards | VCCI, BSMI, RoHS, RCM, IEEE 802.3af, IEEE 802.3at |
|---|
Power
Power Requirements | DC 12 V / PoE |
|---|
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|
Max Operating Temperature | 60 °C |
|---|
Relative Humidity (operating) | Up to 95% (non-condensing) |
|---|
