Lenkeng LKV582KVM, KVM / audio extender, HDMI, over CAT 6/6a/7, up to 120 m
$602.44 inc GST
✕ Backorder - Email us for a lead time or ETA
✓ Free NZ Delivery
Available on back-order
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
This KVM/audio extender kit comprises a transmitter and a receiver, utilizing Ipcolor technology for high-definition, low-latency transmission. The HDMI signal at 4K/60 Hz can be extended up to 120 m through CAT 6 and higher grade network cables. It supports one-to-one connections, one-to-many connections via a gigabit switch, or switch cascading. Additionally, it features HDMI loop out, KVM, and RS-232 passthrough capabilities, making it suitable for various applications such as meetings, home entertainment, educational presentations, and more.
Main Specifications
Product Description | Lenkeng LKV582KVM – KVM / audio extender – HDMI |
Device Type | KVM / audio extender |
Form Factor | External |
Data Transfer Rate | 18 Gbps |
Data Link Protocol | HDMI |
Transmission Medium | CAT 6/6a/7 |
Max Transfer Distance | 120 m |
Dimensions (WxDxH) | 10.3 cm x 10.6 cm x 2.06 cm |
Extended Specifications
General
Device Type | KVM / audio extender |
|---|---|
Form Factor | External |
Colour | Black |
Networking
Connectivity Technology | Wired |
|---|---|
Data Link Protocol | HDMI |
Data Transfer Rate | 18 Gbps |
Max Resolution | 3840 x 2160 @ 60 Hz |
Max Transfer Distance | 120 m |
Status Indicators | Power, KVM, signal |
Features | HDCP compliant, reset button, cascadable, HDMI loop out, iron housing, ESD Protector, Ipcolour technology, LPCM support, One-to-Many, One-to-One, LED status indicators |
Expansion / Connectivity
Interfaces | 1 x RS-232 (transmitter) – terminal block 1 x management (transmitter) – micro-USB Type B female 1 x audio line-in (transmitter) – mini jack female 1 x HDMI output (transmitter) – 19 pin HDMI Type A female 1 x HDMI input (transmitter) – 19 pin HDMI Type A female 1 x USB (transmitter) – Type A 1 x (transmitter) – RJ-45 female 1 x RS-232 (receiver) – terminal block 1 x management (receiver) – micro-USB Type B female 2 x KVM (receiver) – Type A female 1 x audio line-out (receiver) – mini jack female 1 x (receiver) – RJ-45 female 1 x HDMI output (receiver) – 19 pin HDMI Type A female |
|---|
Miscellaneous
Compliant Standards | Plug and Play, IEC 61000-4-2, HDCP 2.2, HDCP 1.4 |
|---|
Power
Power Device | External power adapter |
|---|---|
Power Consumption Operational | 5.5 Watt |
Dimensions & Weight
Width | 10.3 cm |
|---|---|
Depth | 10.6 cm |
Height | 2.06 cm |
Environmental Parameters
Min Operating Temperature | -20 °C |
|---|---|
Max Operating Temperature | 60 °C |
Humidity Range Operating | 0 – 90% RH (non-condensing) |
