HPE Aruba AP-584 (RW) Unified – Radio access point – Wi-Fi 6 – Bluetooth – 2.4 GHz, 5 GHz

Manufacturer:HP
Part Number:R7T00A
Warranty:Lifetime
PPID:AB27072

$5,257.21 inc GST

Free Delivery

Available on back-order

Out of Stock! Contact us for a lead time or ETA

Ships from Auckland

Ships from Auckland

  • Allow 1-2 days for delivery to the North Island
  • Allow 2-3 days for delivery to the South Island
  • add 1-2 days if you are rural
  • Collection can be arranged

Description

Aruba 580 Series Outdoor Access Points are designed for high performance with multi-gigabit capacity, flexible connectivity, and power options. To meet Industrial IoT requirements, the weather-hardened Aruba 580 Series includes high power Bluetooth and Zigbee plus Target Wake Time (TWT) to extend device battery life. Weatherproof and temperature hardened, the Aruba 580 Series can handle temperatures ranging from -40C to +65˚C (including full sun) and is IP66/67 rated with industrial surge protection. Options include 5 Gbps SmartRate Ethernet ports or 10Gbps SFP+ ports and 802.3bt Class 6 power or AC power. With full support for Wi-Fi 6 (802.11ax), the Aruba 580 Series is backwards compatible and backed by our limited lifetime warranty.

  • Aruba 580 Series Outdoor Access Points offer 2.97 Gbps performance backed by a limited lifetime warranty.
  • Aruba 580 Series Outdoor Access Points can withstand extreme temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants.
  • Aruba 580 Series Outdoor Access Points include integrated, high power antennas for increased performance and coverage.

  • Achieve Impressive Performance with Outdoor Wi-Fi 6 APs
    Aruba 580 Series Outdoor Access Points offer 2.97 Gbps performance backed by a limited lifetime warranty.
    Includes options for 5G SmartRate, SFP+, and PSE out giving you flexible connectivity.
    Wi-Fi 6 support for OFDMA and UL/DL MU-MIMO to drive greater efficiency.
  • Weatherproof and Temperature Hardened
    Aruba 580 Series Outdoor Access Points can withstand extreme temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants.
    Ruggedized and tested for -40C to +65˚C, including full sun deployments. • Ruggedized and tested for -40C to +65˚C, including full sun deployments.
    IP66/67 rated with industrial surge protection.
  • Industrial IoT Ready
    Aruba 580 Series Outdoor Access Points include integrated, high power antennas for increased performance and coverage.
    Target Wake Time (TWT) improves battery life of IoT devices.
    Includes high power Bluetooth and 802.15.4/Zigbee radios for increased IoT coverage.

Main Specifications

Product DescriptionHPE Aruba AP-584 (RW) Unified – radio access point – Wi-Fi 6, Bluetooth, Wi-Fi 6
Device TypeRadio access point
Form FactorExternal – outdoor
Data Link ProtocolIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Frequency Band2.4 GHz, 5 GHz
PerformanceMaximum data rate (5 GHz): 2.4 Gbps
Maximum data rate (2.4 GHz): 574 Mbps
Aggregate data rate: 2.97 Gbps
CapacityAssociated client devices per radio: 1024
OS RequiredArubaOS, InstantOS
Power Over Ethernet (PoE) SupportedPoE Class 6
PowerAC 110/240 V
Dimensions (WxDxH)32.4 cm x 31.2 cm x 24.4 cm
Weight5.52 kg

Extended Specifications

General

Device TypeRadio access point
Ruggedized DesignOutdoor
Width32.4 cm
Depth31.2 cm
Height24.4 cm
Weight5.52 kg

Networking

Form FactorExternal
Connectivity TechnologyWireless
Data Transfer Rate2.4 Gbps
Line Coding FormatOFDM, OFDMA
Data Link ProtocolIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Spread Spectrum MethodDSSS
Frequency Band2.4 GHz, 5 GHz
PerformanceMaximum data rate (5 GHz): 2.4 Gbps
Maximum data rate (2.4 GHz): 574 Mbps
Aggregate data rate: 2.97 Gbps
CapacityAssociated client devices per radio: 1024
FeaturesDFS support, Trusted Platform Module (TPM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), cyclic shift diversity (CSD), Intelligent Power Monitoring (IPM), High-Throughput (HT) support, 4×4:4 MU-MIMO technology, Very High Throughput (VHT) support, Target Wait Time (TWT), Advanced IoT Coexistence (AIC), Policy Enforcement Firewall (PEF), Layer 7 Deep Packet Inspection (DPI), Passpoint Release 2
Encryption AlgorithmWPA3, WPA3-Enhanced Open, WPA2-MPSK

Aerial

AntennaExternal
Antenna Qty4

Internet of Things (IoT)

Internet of Things (IoT) CompatibleYes
Communications TechnologyBluetooth Low Energy (LE), Zigbee

Expansion / Connectivity

Interfaces1 x 5GBase-T – RJ-45
1 x 10GBASE-SR – SFP+
1 x 1000Base-T (PoE)
1 x console – USB-C

Miscellaneous

Compliant StandardsIEC 60601-1-2, FCC, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60601-1-2, IP67, IP66, IEC 60950-22, EMC 2014/30/EU, LVD 2014/35/EU, EN 50155, EN 62368-1, IEC 62368-1, ISED, UL 62368-1, RED 2014/53/EU, SIG

Power

Power Over Ethernet (PoE) SupportedPoE Class 6
Voltage RequiredAC 110/240 V
Power Consumption Operational71 Watt

Software / System Requirements

OS RequiredArubaOS, InstantOS

Dimensions & Weight (Shipping)

Shipping Width41 cm
Shipping Depth32.2 cm
Shipping Height43.3 cm
Shipping Weight7.56 kg

Environmental Parameters

Min Operating Temperature-40 °C
Max Operating Temperature65 °C
Humidity Range Operating5 – 93% (non-condensing)
