Raspberry Pi 5 Model B, Single-board computer, Broadcom BCM2712 / 2.4 GHz, RAM 4 GB, 802.11a/b/g/n/ac, Bluetooth 5.0
$242.12 inc GST
Available on back-order
Ships from Auckland or Christchurch
- Allow 1-2 days for delivery
- add 1-2 days if you are rural
- No Collections
Description
Featuring a 64-bit quad-core processor running at 2.4 GHz, Raspberry Pi 5 delivers an increase in CPU performance. Alongside a substantial uplift in graphics performance from an 800 MHz VideoCore VII GPU; dual 4Kp60 display output over HDMI; and state-of-the-art camera support from a rearchitected Raspberry Pi Image Signal Processor, it provides a smooth desktop experience for consumers, and opens the door to more applications for industrial customers.
This is a full-size Raspberry Pi computer using silicon built in-house at Raspberry Pi. The RP1 “southbridge” provides the bulk of the I/O capabilities for Raspberry Pi 5 and delivers a step change in peripheral performance and functionality. Aggregate USB bandwidth is more than doubled, yielding faster transfer speeds to external UAS drives and other high-speed peripherals; the dedicated two-lane 1Gbps MIPI camera and display interfaces present on earlier models have been replaced by a pair of four-lane 1.5Gbps MIPI transceivers, tripling total bandwidth, and supporting any combination of up to two cameras or displays; peak SD card performance is doubled, through support for the SDR104 high-speed mode; and for the first time the platform exposes a single-lane PCI Express 2.0 interface, providing support for high-bandwidth peripherals.
- RP1 controller
- Fast and infinitely smooth
- All aboard the PCI express
- RP1 controller
Raspberry Pi 5 is built using the RP1 I/O controller, a package containing silicon designed in-house at Raspberry Pi. USB 3 has more total bandwidth, for much faster transfer speeds. Camera and DSI display connectors are interchangeable, so you can have one of each, or two the same. - Fast and infinitely smooth
Raspberry Pi 5 features the Broadcom BCM2712 quad-core Arm Cortex A76 processor at 2.4 GHz, making it up to three times faster than the previous generation. With 4 GB RAM, it is a fast and smooth Pi experience. - All aboard the PCI express
You can connect an M.2 SSD to your Raspberry Pi, giving you speedy data transfer and super-fast boot.
Main Specifications
Product Description | Raspberry Pi 5 Model B – single-board computer |
Product Type | Single-board computer |
Parameters | OpenGL ES 3.1, H.265 (4Kp60 decode), up to 4kp60 graphics output, Vulkan 1.2 |
Processor | Broadcom BCM2712 / 2.4 GHz (Quad-Core) – 64-bit |
Memory | microSD – RAM 4 GB |
Wireless Protocol | 802.11a/b/g/n/ac, Bluetooth 5.0 |
Wired Protocol | Gigabit Ethernet |
Power Source | AC power adapter, GPIO |
Warranty | 1 year |
Extended Specifications
General
Product Type | Single-board computer |
|---|---|
Parameters | OpenGL ES 3.1, H.265 (4Kp60 decode), up to 4kp60 graphics output, Vulkan 1.2 |
Processor
Type | Broadcom |
|---|---|
Processor Number | BCM2712 |
Clock Speed | 2.4 GHz |
Number of Cores | Quad-Core |
64-bit Architecture | Yes |
RAM
Technology | LPDDR4X SDRAM |
|---|---|
Installed Size | 4 GB |
Flash Memory
Supported Flash Memory Cards | microSD |
|---|
Networking
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
|---|---|
Wireless Protocol | 802.11a/b/g/n/ac, Bluetooth 5.0 |
Wired Protocol | Gigabit Ethernet |
Interface Provided
Interface Provided | LAN (Gigabit Ethernet) – RJ-45 CSI – ZIF 2 x USB 2.0 – Type A GPIO – 40 pin IDC DSI – ZIF 2 x HDMI output – micro HDMI 2 x USB 3.0 – Type A USB-C (power only) PCIe Gen2x1 UART RP1 I/O |
|---|
Power Device
Power Source | AC power adapter, GPIO |
|---|
