Description
The 5 GHz super high power wireless card for long range links and powerful access points. This is the professional choice for reaching the last mile – 800 mW transmit power will give you the ability to reach even further than before.
The card features built-in LED indicators for wireless mode, connection status (connected, searching, disabled), TX and RX activity and wireless signal strength – just looking at the card will help with installation and alignment. The card comes with a preinstalled industrial grade heatsink, one MMCX connector and nine LED indicator lights.
Main Specifications
Product Description | MikroTik RouterBOARD R5SHPn – network adapter – mini PCI |
Device Type | Network adapter |
Form Factor | Plug-in card |
Interface (Bus) Type | Mini PCI |
Dimensions (WxDxH) | 6 cm x 6 cm x 1.9 cm |
Data Link Protocol | 802.11a, 802.11b/g/n |
Frequency Band | 5 GHz |
Processor | 1 x Atheros AR9220 |
Compliant Standards | IEEE 802.11a, IEEE 802.11n |
Extended Specifications
General
Device Type | Network adapter |
|---|
Form Factor | Plug-in card |
|---|
Interface (Bus) Type | Mini PCI |
|---|
Networking
Connectivity Technology | Wireless |
|---|
Data Link Protocol | IEEE 802.11a, IEEE 802.11n |
|---|
Frequency Band | 5 GHz |
|---|
Status Indicators | Transmit, receive, signal strength |
|---|
Compliant Standards | IEEE 802.11a, IEEE 802.11n |
|---|
Processor / Memory
Processor | 1 x Atheros AR9220 |
|---|
Expansion / Connectivity
Interfaces | 1 x aerial – MMCX |
|---|
Power
Power Consumption Operational | 10 watt |
|---|
Dimensions & Weight
Width | 6 cm |
|---|
Depth | 6 cm |
|---|
Height | 1.9 cm |
|---|
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|
Max Operating Temperature | 65 °C |
|---|
