Description
The SFPSXMM is a TAA compliant MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 1000BASE-SX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 550 m (1804 ft) and delivers dependable 10 GbE connectivity over fiber cabling.
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
Main Specifications
Product Description | Startech MSA Uncoded Compatible SFP Module, 1000BASE-SX, 1GbE Multi Mode (MMF) Fiber Optic Transceiver, 1GE Gigabit Ethernet SFP, LC Connector, 550m, 850nm, DDM, 1Gbps Mini GBIC Module – Lifetime Warranty (SFPSXMM) – SFP (mini-GBIC) transceiver module – 1GbE |
Device Type | SFP (mini-GBIC) transceiver module – LC multi-mode |
Form Factor | Plug-in module |
Cabling Type | 1000Base-SX |
Data Transfer Rate | 1 Gbps |
Optical Wave Length | 850 nm |
Data Link Protocol | 1GbE |
Max Transfer Distance | 550 m |
Dimensions (WxDxH) | 1.3 cm x 5.5 cm x 0.9 cm |
Weight | 18 g |
Designed For | P/N: MCM1110SFP |
Extended Specifications
General
Device Type | SFP (mini-GBIC) transceiver module |
|---|
Form Factor | Plug-in module |
|---|
Networking
Connectivity Technology | Wired |
|---|
Cabling Type | 1000Base-SX |
|---|
Data Link Protocol | 1GbE |
|---|
Data Transfer Rate | 1 Gbps |
|---|
Optical Wave Length | 850 nm |
|---|
Max Transfer Distance | 550 m |
|---|
Features | Full duplex capability |
|---|
Compliant Standards | IEEE 802.3z |
|---|
Expansion / Connectivity
Interfaces | 1 x Ethernet 1000Base-SX – LC multi-mode x 2 |
|---|
Compatible Slots | 1 x SFP (mini-GBIC) |
|---|
Miscellaneous
Compliant Standards | CSA, UL, TUV, FCC, RoHS |
|---|
Dimensions & Weight
Width | 1.3 cm |
|---|
Depth | 5.5 cm |
|---|
Height | 0.9 cm |
|---|
Weight | 18 g |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 70 °C |
|---|
Humidity Range Operating | 5 – 95% |
|---|
Compatibility Information
Designed For | P/N: MCM1110SFP |
|---|
