Description
The Z2 Tower is engineered to seamlessly run multi-threaded apps for fast rendering, simulation, and now real-time ray tracing. And when your demands change, you have expandability to upgrade.
Experience a whole new level of performance for your professional workflow. The Z2 Tower is engineered to seamlessly run multi-threaded apps for fast rendering, simulation, and now real-time ray tracing. And when your demands change, you have impressive expandability to upgrade.
- Your new benchmark for entry workstation power. Designed for zero throttling so you can render, simulate, and real-time ray trace without overheating or lags.
- Built to expand. Power to grow. With room to expand and tool-less access, you can easily upgrade and add components as your needs evolve.
- ISV Certified. Work with confidence knowing your PC is certified with leading software applications to ensure peak performance
- Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP’s collaboration and connectivity technology. - Intel Core i7 processor
Run several CPU–heavy programs simultaneously without sacrificing performance with an Intel Core i7 processor. - Smaller, Functional Design
The stunning new design features front and rear ledges, so you can easily move your system from location to location. - Tool-less Access
Evolve your work. Evolve your rig. With a tool-less sliding access cover, you can easily get into the the interior, and customize your Z to fit your needs. - Thermal Management
Innovatively designed to keep hardware components cool and quiet no matter how hard you push it. Have confidence to run your system at max load 24/7. - Unthrottled Performance
Z’s industry-leading thermals keep the processor and graphics card cool, so they can run at max performance for extended periods of time.
Main Specifications
Hard Drive | SSD 512 GB – PCI Express – M.2 2280 – NVM Express (NVMe) |
Hard Drive (2nd) | HDD 1 TB – SATA – 7200 rpm |
Optical Storage | No optical drive |
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
Graphics Controller | PCIe 3.0 x16 – NVIDIA T1000 / Intel UHD Graphics 770 |
Video Memory | 8 GB GDDR6 SDRAM |
Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Wi-Fi 6E, Bluetooth 5.3 |
Power | (50/60 Hz) |
OS Provided | Windows 10 Pro (downgrade from Windows 11 Pro) + Windows 11 Pro Licence |
Software Included | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7 |
Colour | Black |
Dimensions (WxDxH) | 16.9 cm x 38.5 cm x 35.6 cm |
Weight | 7.2 kg |
Environmental Standards | ENERGY STAR Qualified |
Product Description | HP Workstation Z2 G9 – tower – AI Workstation – Core i7 13700 2.1 GHz – 16 GB – SSD 512 GB, HDD 1 TB |
Type | Workstation – tower – AI Workstation |
Height (Rack Units) | 4U |
Processor | 1 x Intel Core i7 (13th Gen) 13700 / 2.1 GHz (up to 5.2 GHz, (16-core) |
Processor Socket | LGA1700 Socket |
Processor Main Features | Intel Turbo Boost Technology |
Cache Memory | 30 MB L3 Cache |
Cache Per Processor | 30 MB |
RAM | 16 GB (installed) / 128 GB (max) – DDR5 SDRAM – non-ECC |
Storage Controller | SATA/NVMe (SATA 6Gb/s / PCIe 4.0 x4 (NVMe)) |
Documents
Extended Specifications
General
Product Form Factor | Tower – 4U |
|---|
Sensors | HP Tamper Lock |
|---|
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
|---|
Colour | Black |
|---|
Processor / Chipset
CPU | Intel Core i7 (13th Gen) 13700 |
|---|
Clock Speed | 2.1 GHz (P-core) / 1.5 GHz (E-core) |
|---|
Max Turbo Speed | 5.2 GHz (P-core) / 4.1 GHz (E-core) |
|---|
Number of Cores | 16-core |
|---|
CPU Qty | 1 |
|---|
Max CPU Qty | 1 |
|---|
L2 cache | 24 MB |
|---|
CPU Upgradability | Upgradable |
|---|
Processor Main Features | Intel Turbo Boost Technology |
|---|
CPU Socket | LGA1700 Socket |
|---|
Chipset Type | Intel W680 |
|---|
Cache Memory
Installed Size | L3 Cache – 30 MB |
|---|
Cache Per Processor | 30 MB |
|---|
RAM
Installed Size | 16 GB (installed) / 128 GB (max) |
|---|
Technology | DDR5 SDRAM – non-ECC |
|---|
Effective Memory Speed | 4800 MHz |
|---|
Rated Memory Speed | 4800 MHz |
|---|
Form Factor | DIMM 288-pin |
|---|
Slots | 4 (Total) / 3 (empty) |
|---|
Features | Unbuffered, dual channel memory architecture |
|---|
Configuration Features | 1 x 16 GB |
|---|
Hard Drive
Type | SSD – M.2 2280 |
|---|
Capacity | 1 x 512 GB |
|---|
Interface Type | PCI Express |
|---|
Features | NVM Express (NVMe) |
|---|
Hard Drive (2nd)
Type | HDD |
|---|
Interface Class | Serial ATA |
|---|
Capacity | 1 x 1 TB |
|---|
Spindle Speed | 7200 rpm |
|---|
Storage Controller
Type | 1 x SATA/NVMe |
|---|
Controller Interface Type | SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
|---|
Channel Qty | 4 |
|---|
RAID Level | RAID 0, RAID 1 |
|---|
Optical Storage
Monitor
Graphics Controller
Interface Type | PCIe 3.0 x16 |
|---|
Multi-GPU Configuration | 1 single GPU card / integrated GPU |
|---|
Graphics Processor | NVIDIA T1000 / Intel UHD Graphics 770 |
|---|
Video Memory | 8 GB GDDR6 SDRAM |
|---|
Bandwidth | 160 GBps |
|---|
Video Interfaces | DisplayPort |
|---|
Max Monitors Supported | 4 |
|---|
Audio Output
Compliant Standards | High Definition Audio |
|---|
Input Device
Keyboard
Mouse
Networking
Ethernet Controller | Intel I219-LM |
|---|
Wireless LAN Supported | Yes |
|---|
Wireless NIC | Intel Wi-Fi 6E AX 211 |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
|---|
Remote Management Protocol | SNMP 2 |
|---|
Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2×2), Intel Active Management Technology (AMT) 15 |
|---|
Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
|---|
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x external 5.25″
1 (total) / 1 (free) x external 5.25″ Slim Line
2 (total) / 1 (free) x internal 3.5″
1 (total) / 1 (free) x internal 2.5″ |
|---|
Slots | 1 (total) / 0 (free) x PCIe 5.0 x16
1 (total) / 1 (free) x PCIe 3.0 x4 (x1 mode)
1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode)
1 (total) / 1 (free) x PCIe 3.0 x4
3 (total) / 2 (free) x M.2 Card – 2280 (PCIe 4.0 x4 mode)
1 (total) / 1 (free) x M.2 Card – 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module) |
|---|
Interfaces | 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support)
6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging)
1 x audio line-in
1 x audio line-out
2 x DisplayPort 1.4
1 x LAN (Gigabit Ethernet)
1 x USB 3.2 Gen 1
1 x LAN (Gigabit Ethernet)
4 x Mini DisplayPort 1.4 |
|---|
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor |
|---|
Security Slot Type | Kensington security slot |
|---|
Compliant Standards | RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen |
|---|
Power
Device Type | Power supply |
|---|
Voltage Required | AC 90-269 V (50/60 Hz) |
|---|
Power Provided | 500 watt |
|---|
Efficiency | 90% |
|---|
Power Factor Correction | Yes (active) |
|---|
Operating System / Software
OS Provided | Windows 10 Pro (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro Licence |
|---|
Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7 |
|---|
Sustainability Information
Dimensions & Weight
Width | 16.9 cm |
|---|
Depth | 38.5 cm |
|---|
Height | 35.6 cm |
|---|
General
Type | Workstation |
|---|
AI Level | AI Workstation |
|---|
Dimensions & Weight
Dimensions & Weight (Shipping)
Shipping Width | 29.5 cm |
|---|
Shipping Depth | 49 cm |
|---|
Shipping Height | 51.8 cm |
|---|
Environmental Parameters
Min Operating Temperature | 5 °C |
|---|
Max Operating Temperature | 35 °C |
|---|
Humidity Range Operating | 10 – 85% RH (non-condensing) |
|---|
