Description
j5create’s JCE133G is a simple, one-piece external adapter that plugs into the USB-C port on your Ultrabook or MacBook. The JCE133G is the ultimate solution if you do not have an Ethernet port or if you just want to increase your speed. The elegantly designed JCE133G uses an RJ-45 connector that supports 10/100/1000 Mbps Ethernet performance. The JCE133G allows you to add networking capabilities to a computer without them through a Wi-Fi connection.
- Quickly add a Gigabit Ethernet port over USB-C
- USB Plug-and-Play
- USB 3.1 Gen1 and backwards compatible with USB 2.0/1.1
- Transfer all of your files almost instantly over a true Gigabit network
- USB bus-powered
- Compatible with Windows and macOS
- Activity and link LED indicators
- Plug and Play
Native driver support, no additional driver needed in Windows 10/macOS 10.6 and later/Chrome OS. - Small reversible USB-C connector
High durability and versatility. USB-C is a user-friendly reversible connector that allows you to connect your cable to your device in any direction. - Surge protection
Protection components prevent “surge overload,” protecting the network card and extending the product’s life. - Universal compatibility
Compatible with devices running Windows, macOS, Chrome OS and Linux.
Main Specifications
Product Description | j5create JCE133G – network adapter – USB-C 3.1 Gen 1 – Gigabit Ethernet x 1 |
Device Type | Network adapter |
Form Factor | External |
Interface (Bus) Type | USB-C 3.1 Gen 1 |
Ports | Gigabit Ethernet x 1 |
Dimensions (WxDxH) | 6.8 cm x 1.45 cm x 2.3 cm |
Weight | 33 g |
Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
Data Transfer Rate | 1 Gbps |
Network / Transport Protocol | TCP/IP, UDP/IP |
Compliant Standards | IEEE 802.3az-2010, USB 3.1 Gen 1, USB 1.1, USB 2.0, USB 3.0 |
System Requirements | Apple MacOS, Microsoft Windows, Microsoft Windows XP / Vista / 7 / 8.1 / 10, Apple MacOS X 10.6 or later, Linux Kernel 4.15, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Google Chrome OS |
Extended Specifications
General
Device Type | Network adapter |
|---|
Form Factor | External |
|---|
Interface (Bus) Type | USB-C 3.1 Gen 1 |
|---|
Networking
Ports | Gigabit Ethernet x 1 |
|---|
Connectivity Technology | Wired |
|---|
Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
|---|
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
Data Transfer Rate | 1 Gbps |
|---|
Network / Transport Protocol | TCP/IP, UDP/IP |
|---|
Status Indicators | Link/activity |
|---|
Features | WOL, EEE, IPv6 support, IPv4 support, USB powered, aluminium housing |
|---|
Compliant Standards | IEEE 802.3az-2010, USB 3.1 Gen 1, USB 1.1, USB 2.0, USB 3.0 |
|---|
Expansion / Connectivity
Interfaces | 1 x Ethernet 1000 – RJ-45 – female |
|---|
Miscellaneous
Cables Included | 1 x USB-C cable (integrated) – 10 cm |
|---|
Compliant Standards | Plug and Play |
|---|
Software / System Requirements
OS Required | Apple MacOS, Microsoft Windows, Microsoft Windows XP / Vista / 7 / 8.1 / 10, Apple MacOS X 10.6 or later, Linux Kernel 4.15, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Google Chrome OS |
|---|
Dimensions & Weight
Width | 6.8 cm |
|---|
Depth | 1.45 cm |
|---|
Height | 2.3 cm |
|---|
Weight | 33 g |
|---|
Environmental Parameters
Min Operating Temperature | -10 °C |
|---|
Max Operating Temperature | 65 °C |
|---|
Humidity Range Operating | 0 – 85% (non-condensing) |
|---|
