TP-Link VIGI C240 V1, Network surveillance camera, pan / tilt, dome, vandal / waterproof, colour (Day&Night), 4 MP, 2560 x 1440, M12 mount, fixed focal, audio, LAN 10/100, H.265+, H.265, H.264+, H.264, DC 12 V / PoE
$109.12 inc GST
✓ In Stock - 6 available
✓ Free NZ Delivery
6 in stock
Ships from: Auckland
- Allow 1–2 days for delivery to the North Island
- Allow 2–3 days for delivery to the South Island
- Add 1–2 days if you are rural
- Collection can be arranged
Description
The VIGI C240I camera comes with 4MP – more than enough pixels to pick up some of the more discrete details.
- 4MP super-high definition
- Human and vehicle classification
- Smart detection
- IK10 vandal-proof and IP67 waterproof
- H.265+
- Smart video enhancement
- PoE/12V DC
- 2.8/4 mm lens
- Flexible management
- 4MP super-high definition
The VIGI C240I camera comes with 4MP – more than enough pixels to pick up some of the more discrete details. - Human and vehicle classification
Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications. - Smart detection
Receive notifications and check feeds when someone crosses a boundary, enters an area you’ve set, obstructs the camera, or removes/abandons objects. - IK10 vandal-proof and IP67 waterproof
With vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime. - H.265+
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality. - Smart video enhancement
VIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision. - PoE/12V DC
Two types of power supply not only give you more convenience but also make your wiring remarkably easy. - 2.8/4 mm lens
Whether you need a wide-angle lens to cover enclosed spaces or a higher millimeter lens for longer distances in open spaces, C240I comes with two different lens types to better suit your security needs. - Flexible management
Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manger.
Main Specifications
Product Description | TP-Link VIGI C240 V1 – network surveillance camera – dome |
Device Type | Network surveillance camera – pan / tilt – dome – vandal / waterproof |
Audio | Yes: built-in microphone |
Camera Mount Type | Ceiling mount, wall mount |
Dimensions (WxDxH) | 11.5 cm x 11.5 cm x 8.6 cm |
Connectivity Technology | Wired |
Camera | Colour – Day&Night |
Max Resolution | 2560 x 1440 |
Frame Rate (max) | 30 frames per second |
Motion Detection | Yes |
Optical Sensor Type | CMOS – 1/2.7″ – 4 MP |
Minimum Illumination | 0.005 lux – colour 0 lux – white light 0 lux – IR |
Focal Length Control | Fixed focal |
Focal Length | 4 mm |
Lens Mounting | M12 mount |
Lens Iris | F/1.6 |
Panning Range (degree) | 0 to 360 |
Tilting Range (degree) | 0 to 85 |
Interfaces | Ethernet 10Base-T/100Base-TX |
Voltage | DC 12 V / PoE |
Features | Infrared cut filter, 3D digital noise reduction (DNR), Digital Wide Dynamic Range (D-WDR), human detection, intrusion detection, Line Crossing Detection, Vehicle Detection, Camera Tampering Detection, Backlight Compensation (BLC), Highlight Compensation (HLC), Smart IR, brightness control, contrast control, exposure control, image mirror, saturation control, sharpness control, white balance, Wide Dynamic Range (WDR), 2 video streams, password reset via e-mail, Privacy Mask Function, reset button, Smart Detection, human and vehicle filtering, object removal detection, Abandoned Object Detection, region entrance detection, region exiting detection, Open Network Video Interface Forum (ONVIF), HTTPs encryption, IP address filtering, digest authentication, plastic housing |
Environmental Parameters (operating) | -30 °C – 60 °C |
Documents
Extended Specifications
General
Device Type | Network surveillance camera |
|---|---|
Audio Support | Yes: built-in microphone |
Form Factor | Dome |
Camera Mount Type | Ceiling mount, wall mount |
Connectivity Technology | Wired |
Width | 11.5 cm |
Depth | 11.5 cm |
Height | 8.6 cm |
Camera
Type | Colour – Day&Night – pan / tilt – vandal / waterproof |
|---|---|
Digital Video Format | H.265+, H.265, H.264+, H.264 |
Max Digital Video Resolution | 2560 x 1440 |
Motion Detection | Yes |
Minimum Illumination | 0.005 lux – colour 0 lux – white light 0 lux – IR |
Infrared LEDs | Yes |
Infrared Distance | 30 m |
Digital Video Capture Resolution | 2560 x 1440, 2304 x 1296, 2048 x 1280, 1920 x 1080, 1280 x 1720, 704 x 576, 640 x 480, 352 x 288, 320 x 240 |
Frame Rate (max) | 30 frames per second |
Features | Infrared cut filter, 3D digital noise reduction (DNR), Digital Wide Dynamic Range (D-WDR), human detection, intrusion detection, Line Crossing Detection, Vehicle Detection, Camera Tampering Detection, Backlight Compensation (BLC), Highlight Compensation (HLC), Smart IR, brightness control, contrast control, exposure control, image mirror, saturation control, sharpness control, white balance, Wide Dynamic Range (WDR), 2 video streams, password reset via e-mail, Privacy Mask Function, reset button, Smart Detection, human and vehicle filtering, object removal detection, Abandoned Object Detection, region entrance detection, region exiting detection, Open Network Video Interface Forum (ONVIF), HTTPs encryption, IP address filtering, digest authentication, plastic housing |
Image Sensor
Type | 4 MP CMOS 1/2.7″ |
|---|
Lens Construction
Type | M12 mount – fixed focal |
|---|---|
Focal Length | 4 mm |
Lens Iris | F/1.6 |
Horizontal Field of View (degree) | 79.7 |
Vertical Field of View (degree) | 42.9 |
Diagonal Field of View (degree) | 93.9 |
Panning
Range (degree) | 0 to 360 |
|---|
Tilting
Range (degree) | 0 to 85 |
|---|
Interfaces
Network Interface | Ethernet 10Base-T/100Base-TX |
|---|---|
Network Protocols | TCP/IP, UDP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, SSL, TLS |
Expansion / Connectivity
Ports | LAN – RJ-45 |
|---|---|
Supported Memory Cards | microSD Card |
Miscellaneous
Included Accessories | Mounting hardware, waterproof cable attachments |
|---|---|
Compliant Standards | IP67, IK10, VCCI, BSMI, KC, IEEE 802.3af, IEEE 802.3at |
Power
Power Requirements | DC 12 V / PoE |
|---|
Environmental Parameters
Min Operating Temperature | -30 °C |
|---|---|
Max Operating Temperature | 60 °C |
