Description
The Brother TJ-4020TN industrial label printer offers performance you can rely on when keeping up with increasing demand.
The high-volume thermal label printer has been designed to ensure minimal downtime and maximum productivity through fast print speeds, large ribbon capacity and in-built durability.
With ZPL2 emulation compatibility and multiple connectivity options, the TJ-4020TN has been built with you in mind.
- Fast print speeds of up to 10 ips with 203 dpi resolution
- LED notification to indicate printer status
- Print width of up to 107 mm
- FBPL-EZD (EPL2, ZPL2, DPL) printer command languages supported
- High-capacity thermal transfer ribbon means fewer consumable changes
- Connectivity as standard
USB, USB Host, Serial and Ethernet are included as standard for the industrial printers. - In-built durability
The TJ industrial printer series offers performance you can rely on, even in the toughest production environments. The reliable thermal barcode printer has been built with you in mind and built to last, ensuring you enjoy years of hassle-free label printing. - Integrate with ease
With the Brother TJ series, there is no need to worry about integration. The industrial printers support various printer command languages, including ZPL2 emulation, making printer replacements as easy as possible – with minimal disruption. - Maximize productivity
The TJ-4020TN label machine offers fast print speeds to help you keep up with increasing demand. The high-volume label printer is perfect for manufacturing and transport and logistics environments.
What’s in the Box
- Brother TJ-4020TN Industrial Label Printer
- USB cable
- 1″ ribbon paper core
Main Specifications
Product Description | Brother TJ-4020TN – label printer – B/W – direct thermal / thermal transfer |
Printer Type | Label printer – direct thermal / thermal transfer – B/W |
Weight | 9.2 kg |
Max Media Size | Roll (12 cm) |
Min Media Size (Custom) | 20 mm |
Max Media Size (Custom) | 120 mm |
Print Speed | Up to 254 mm/sec – max speed |
Max Resolution (B&W) | 203 dpi |
Interface | LAN, serial, USB host, USB 2.0 |
RAM Installed (Max) | 128 MB |
Flash Memory Installed (Max) | 128 MB |
Language Simulation | DPL, EPL2, ZPL II |
Barcodes | Code 128, EAN-128, Interleaved 2 of 5, Industrial 2 of 5, Code 39, EAN-13, EAN-8, Code 93, UPC-A, UPC-E, Postnet, MSI, Plessey, China Post, ITF-14, EAN-14, Code 11, Telepen, PLANET, Code 49, LOGMARS, CODABLOCK, GS1 DataBar, MaxiCode, Aztec code, PDF417, QR code, MicroPDF417, TLC39 |
Media Type | Continuous labels |
Features | Label detection sensor |
Networking | Print server |
System Requirements | Linux, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Windows 8, Windows 8.1, Apple iOS 9 or later, Android 5.0 or later, Apple macOS 10.12.x, Apple macOS 10.13.x, Apple macOS 10.14.x, Apple macOS 10.15.x, CentOS 7.2, Linux Fedora 24, Red Hat Enterprise Linux 7.3, SuSE Linux Enterprise Server 12, Ubuntu 11.04 – 16.04 |
Dimensions (WxDxH) | 24.8 cm x 43.6 cm x 27.4 cm |
Documents
Extended Specifications
General
Printer Type | Label printer – direct thermal / thermal transfer – monochrome |
|---|
Printer
Print Speed | Up to 254 mm/sec – max speed |
|---|
Connectivity Technology | Wired |
|---|
Interface | LAN, serial, USB host, USB 2.0 |
|---|
Max Resolution (B&W) | 203 dpi |
|---|
Language Simulation | DPL, EPL2, ZPL II |
|---|
Features | Label detection sensor |
|---|
Barcodes | Code 128, EAN-128, Interleaved 2 of 5, Industrial 2 of 5, Code 39, EAN-13, EAN-8, Code 93, UPC-A, UPC-E, Postnet, MSI, Plessey, China Post, ITF-14, EAN-14, Code 11, Telepen, PLANET, Code 49, LOGMARS, CODABLOCK, GS1 DataBar, MaxiCode, Aztec code, PDF417, QR code, MicroPDF417, TLC39 |
|---|
RAM
RAM Installed (Max) | 128 MB |
|---|
Flash Memory
Media Handling
Media Type | Continuous labels |
|---|
Max Media Size | Roll (12 cm) |
|---|
Min Media Size (Custom) | 20 mm |
|---|
Max Media Size (Custom) | 120 mm |
|---|
Media Sizes | Roll (4cm), Roll (11 cm), Roll (2 cm), Roll (12 cm) |
|---|
Max Printing Width | 107 mm |
|---|
Max Printing Length | 25400 mm |
|---|
Roll Maximum Outer Diameter | 203 mm |
|---|
Roll Core Diameter | 76.2 mm, 25.4 mm |
|---|
Networking
Expansion / Connectivity
Connections | 1 x RS-232 – 9 pin D-Sub (DB-9)
1 x USB 2.0
1 x LAN – RJ-45
1 x USB host |
|---|
Miscellaneous
Included Accessories | 1″ ribbon paper core |
|---|
Cables Included | 1 x USB cable |
|---|
Features | 4 LED indicators |
|---|
Software / System Requirements
Software Included | Software Development Kit (SDK) |
|---|
OS Required | Linux, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Windows 8, Windows 8.1, Apple iOS 9 or later, Android 5.0 or later, Apple macOS 10.12.x, Apple macOS 10.13.x, Apple macOS 10.14.x, Apple macOS 10.15.x, CentOS 7.2, Linux Fedora 24, Red Hat Enterprise Linux 7.3, SuSE Linux Enterprise Server 12, Ubuntu 11.04 – 16.04 |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 40 °C |
|---|
Humidity Range Operating | 25 – 85% (non-condensing) |
|---|
Dimensions & Weight
Width | 24.8 cm |
|---|
Depth | 43.6 cm |
|---|
Height | 27.4 cm |
|---|
Weight | 9.2 kg |
|---|
