Cisco Integrated Services Router 1111, Router, WWAN 8-port switch, 1GbE, Wi-Fi 5, WAN ports: 2
$3,474.20 inc GST
Available on back-order
Ships from Auckland or Christchurch
- Allow 1-2 days for delivery
- add 1-2 days if you are rural
- No Collections
Description
The Cisco ISR 1111 8-port router with LTE (LATAM and APAC) with a small form factor is best suited for small and midsize businesses, enterprise branches, and as customer premises equipment in managed services environments; it can be used in ATMs, retail stores, and kiosks. The C1111-8PLTELA model comes with eight LAN ports and supports Power over Ethernet (PoE) and PoE+ to power branch devices such as IP phones and cameras. It has high performance with Gigabit Ethernet packet forwarding capabilities and the multicore architecture has separate cores for the data plane and control plane so your network ensures an optimized user experience. You can easily deploy this router with zero-touch provisioning using the plug-and-play capability. This model is configured for LATAM and APAC.
- Consistent, high application performance levels
- USB-based console access
- Consistent, high application performance levels
The router can run multiple services simultaneously with minimal performance degradation. - USB-based console access
A micro USB console port supports management connectivity when traditional serial ports are not available.
Main Specifications
Product Description | Cisco Integrated Services Router 1111 – router – WWAN – desktop |
Device Type | Router – wireless cellular modem – 8-port switch (integrated) |
Enclosure Type | Desktop |
Mobile Communication Protocol | UMTS, TD-SCDMA, HSPA+, DC-HSPA+, LTE Advanced, FDD LTE, TDD LTE |
WAN Ports Qty | 2 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ac Wave 2 |
Performance | Encryption throughput: 250 Mbps |
Network / Transport Protocol | IPSec, PPPoE, DHCP, DNS, L2TPv3 |
Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), RSVP |
Remote Management Protocol | SNMP, RMON, CLI, TR-069 |
Features | DHCP support, PoE, load balancing, MPLS support, VLAN support, Syslog support, IPv6 support, Dying Gasp support, CBWFQ, WRED, VRRP support, ACL support, QoS, DMVPN, SMS alert, BFD, IPv4 support, NetFlow, MRC, HSRP support, Call Home function support, IPFIX, GRE, automatic Internet Key Exchange, CSD, LISP, packet aggregation A-MPDU, packet aggregation A-MSDU, AVC, 3G MIB, failover protection, Field Programmable Gate Array, AES encryption, policy based routing, AAA, DFS, HQoS, L3VPN support, EEM, MHSRP, EVC, Cisco IPSLA, NBAR, MIP, dual SIM support |
Compliant Standards | IEEE 802.3af, IEEE 802.11i, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at, IEEE 802.11r, IEEE 802.11ac Wave 2 |
Power | AC 120/230 V (50/60 Hz) |
Dimensions (WxDxH) | 32.3 cm x 24.4 cm x 4.4 cm |
Weight | 2.59 kg |
Documents
Extended Specifications
General
Device Type | Router – 8-port switch (integrated) |
|---|---|
Enclosure Type | Desktop |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ac Wave 2 |
Performance | Encryption throughput: 250 Mbps |
Network / Transport Protocol | IPSec, PPPoE, DHCP, DNS, L2TPv3 |
Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), RSVP |
Remote Management Protocol | SNMP, RMON, CLI, TR-069 |
Encryption Algorithm | Triple DES, SHA, MD5, AES, WPA2, 128-bit AES, 256-bit AES, 1024-bit RSA, 2048-bit RSA, 384-bit SHA-2, 256-bit SHA, 512-bit SHA, 748-bit AES, ECDSA 256-bit, ECDSA 384-bit |
Authentication Method | RADIUS |
Features | DHCP support, PoE, load balancing, MPLS support, VLAN support, Syslog support, IPv6 support, Dying Gasp support, CBWFQ, WRED, VRRP support, ACL support, QoS, DMVPN, SMS alert, BFD, IPv4 support, NetFlow, MRC, HSRP support, Call Home function support, IPFIX, GRE, automatic Internet Key Exchange, CSD, LISP, packet aggregation A-MPDU, packet aggregation A-MSDU, AVC, 3G MIB, failover protection, Field Programmable Gate Array, AES encryption, policy based routing, AAA, DFS, HQoS, L3VPN support, EEM, MHSRP, EVC, Cisco IPSLA, NBAR, MIP, dual SIM support |
Compliant Standards | IEEE 802.3af, IEEE 802.11i, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at, IEEE 802.11r, IEEE 802.11ac Wave 2, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, CB, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-11, FCC CFR47 Part 15, UL 60950-1 Second Edition, VCCI V-3, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS CISPR 22, CNS 13438, EN 301 489-7, EN 301 489-1, FCC CFR47 Part 22, FCC CFR47 Part 24, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 386, EN 301 489-24, EN 301 908-1, EN 301 908-2, EN 301 511, EN 301 908-13 |
RAM | 4 GB |
Flash Memory | 4 GB |
Status Indicators | Status |
Communications
Type | Wireless cellular modem |
|---|---|
Mobile Communication Protocol | UMTS, TD-SCDMA, HSPA+, DC-HSPA+, LTE Advanced, FDD LTE, TDD LTE |
Internet of Things (IoT)
Communications Technology | LTE Cat 6 |
|---|
Expansion / Connectivity
Interfaces | WAN: 1 x 1000Base-T/1000Base-X – RJ-45/SFP WAN: 1 x 1000Base-T – RJ-45 LAN: 4 x 10Base-T/100Base-TX/1000Base-T – RJ-45 LAN: 2 x 10Base-T/100Base-TX/1000Base-T (PoE) – RJ-45 LAN: 2 x 10Base-T/100Base-TX/1000Base-T (PoE+) – RJ-45 USB 3.0: 1 x console Antenna: 1 x GPS connector |
|---|---|
Expansion Slots | 1 (total) / 1 (free) x SIM |
Power
Voltage Required | AC 120/230 V (50/60 Hz) |
|---|---|
Power Consumption Operational | 66 Watt |
Software / System Requirements
OS Provided | Cisco IOS XE Universal |
|---|
Dimensions & Weight
Width | 32.3 cm |
|---|---|
Depth | 24.4 cm |
Height | 4.4 cm |
Weight | 2.59 kg |
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|---|
Max Operating Temperature | 65 °C |
Humidity Range Operating | 5 – 95% (non-condensing) |
