Description
D-Link’s 25G SFP28 Module series are hot-swappable SFP28 transceivers that are plugged into SFP28 slots on switches and support 25G Ethernet. The transceivers use the Small Form-factor Pluggable 28 format (SFP28) connectors. The D-Link 25G SFP28 Module Series transceivers offer customers a wide variety of 25G Ethernet connectivity options for data centers, enterprise wiring closets, and service provider transport applications.
- Hot pluggable
- 25G Ethernet speeds
- Hot pluggable
All D-Link transceivers are hot pluggable. You can connect a transceiver while the system is powered on without causing any issues, and easily swap one for another without having to reboot the switch each time. This permits modules to be added or removed without interrupting the network, facilitating maintenance and greatly reducing downtime. - 25G Ethernet speeds
The transceivers support 25G Ethernet, which results in very fast data transmissions of up to 25 Gbit/s. This is 25 times faster than Gigabit Ethernet and enables the switch to handle faster and higher data transmissions, making it very suitable for business needs.
Main Specifications
Product Description | D-Link DEM S2801SR – SFP28 transceiver module – 25GbE |
Device Type | SFP28 transceiver module – LC multi-mode |
Form Factor | Plug-in module |
Cabling Type | 25GBase-SR |
Data Transfer Rate | 25 Gbps |
Optical Wave Length | 850 nm |
Data Link Protocol | 25GbE |
Max Transfer Distance | 100 m |
Dimensions (WxDxH) | 5.73 cm x 1.37 cm x 0.85 cm |
Weight | 25 g |
Extended Specifications
General
Device Type | SFP28 transceiver module |
|---|
Form Factor | Plug-in module |
|---|
Networking
Connectivity Technology | Wired |
|---|
Cabling Type | 25GBase-SR |
|---|
Data Link Protocol | 25GbE |
|---|
Data Transfer Rate | 25 Gbps |
|---|
Optical Wave Length | 850 nm |
|---|
Max Transfer Distance | 100 m |
|---|
Features | Hot swappable |
|---|
Compliant Standards | IEEE 802.3by |
|---|
Expansion / Connectivity
Interfaces | 1 x Ethernet 25GBase-SR – LC multi-mode female x 2 |
|---|
Miscellaneous
Compliant Standards | OM4, OM3, MSA, RoHS, FCC, VCCI, LVD, EN 60825-1, EN 60825-2 |
|---|
Dimensions & Weight
Width | 5.73 cm |
|---|
Depth | 1.37 cm |
|---|
Height | 0.85 cm |
|---|
Weight | 25 g |
|---|
Environmental Parameters
Min Operating Temperature | 0 °C |
|---|
Max Operating Temperature | 70 °C |
|---|
Humidity Range Operating | 5 – 95% |
|---|
